ARB 6174284 Fitting Instructions Manual

DUAL CAB CENTRAL LOCKING CANOPY
Ascent Canopy
FITTING KIT: 6174284 Carton Kit and 668PD105 Front Mount Rail
! PLEASE PROVIDE A COPY OF THESE INSTRUCTIONS TO THE CUSTOMER !
IMPORTANT:
•
Vehicle bodies and vehicle specific installation can vary, so please read the following instructions
as they refer to important information, which could affect the quality of the final installation.
•
It is advisable to have the canopy fitted by an authorised dealer.
•
The majority of installation can be completed by one person, (however, at least 4 people will be
required to lift the canopy onto the vehicle).
FITMENT:
•
For Bed Liners additional time for fitting is required and trimming of bed liners is required. Fitting
with under rail bed liners is recommended (ARB part number KUL2579) or Sport guard
(ARB part number 10053601). OEM over rail bed liners will require the over rail portion
trimmed off. Tailgate liners must have the tailgate over rail portion trimmed off.
•
Cabin Guards and Sports bars must be removed prior to canopy fitment. These components can
be returned to the customer if required.
CARE OF YOUR CANOPY:
Please refer to the "owner's manual supplement" to be given to the purchaser on installation, and to
details referred to in the second last page of these fitting instructions.
28/02/2020
If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state.
Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807
WA:(08) 9244 3553 NSW: (02) 9821 3633 ACT: (02) 6280 7475 SA: (08) 8244 5001 QLD: (07) 3872 3872 NT: (08) 8947 2262 TAS: (03) 6331 4190
AC10 – Toyota Hilux SR "J" Deck
(2015 Vehicle Production Onwards)
Page 1 of 45 ARB Copyright 2017 3789661
