ARB AC17C Manual

DUAL CAB CENTRAL LOCKING CANOPY
Ascent Canopy AC17C – VW Amarok
FITTING KIT: 6178034 & FRONT HEADER RAIL: 668PD179
! PLEASE PROVIDE A COPY OF THESE INSTRUCTIONS TO THE CUSTOMER!
IMPORTANT:
•
Vehicle bodies and vehicle specific installation can vary. Please read the following
instructions as they refer to important information which could affect the quality of the
final installation.
•
It is advisable to have the canopy fitted by an authorised dealer.
•
Most of the installation can be completed by one person (however 4 people will be
required to lift the canopy onto the vehicle).
FITMENT:
•
For Bed Liners and accessory Cargo Management Systems (with sliding tie down rail
cleats), additional time for fitting is required including partial trimming of bed liners.
•
All side tub rail plastic mouldings, Cabin Guards and Sports bars must be removed prior
to canopy fitment. These components can be returned to the customer if required. The
plastic cap on top of the tailgate is to remain assembled to the vehicle.
•
Specific to all Amarok models, fitting instruction 37801115 must be undertaken
first to prepare the vehicle for canopy fitment. Vehicle variants with roll top
tonneau covers should have the bed liner also removed. ARB Sport Guard liner
could be purchased separately. For all vehicles without a roll top tonneau cover
the canopy is compatible with the bed liner.
28-08-2023
If you have any queries regarding the installation of this product, please contact the distributor from whom it was purchased, or alternatively the ARB office in your state.
Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807
WA:(08) 9244 3553 NSW: (02) 9821 3633 ACT: (02) 6280 7475 SA: (08) 8244 5001 QLD: (07) 3872 3872 NT: (08) 8947 2262 TAS: (03) 6331 4190
(2023+ Vehicle Production Onwards)
Page 1 of 45 ARB Copyright 2023 37801254
