ARB AC08C Fitting Instructions Manual

AC08C– Mitsubishi Triton MQ
FITTING KIT: 6174003 with 664143 and 664144 Front Mount Rails
! PLEASE PROVIDE A COPY OF THESE INSTRUCTIONS TO THE CUSTOMER !
IMPORTANT:

Vehicle bodies and vehicle specific installation can vary, so please read the following
instructions as they refer to important information, which could affect the quality of the
final installation.

It is advisable to have the canopy fitted by an authorised dealer.

The majority of installation can be completed by one person, (however, at least 4 people
will be required to lift the canopy onto the vehicle).
FITMENT:

For Bed Liners refer to Section 6, additional time for fitting is required and trimming of bed
liners is required. Fitting with under rail bed liners is recommended (ARB part number
KUL2179). Tailgate liners must have the tailgate over rail portion trimmed off. ARB
Sport Guard (P/N:10052233) also requires additional trimming. For 2019 MR Model
the OEM bed liner part number is MZ330745TB

Cabin Guards and Sports bars must be removed prior to canopy fitment. These
components can be returned to the customer if required.
CARE OF YOUR CANOPY:
Please refer to the "owner's manual supplement" to be given to the purchaser on
installation, and to details referred to in the second last page of these fitting instructions.
15-02-2019
If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state.
Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807
WA:(08) 9244 3553 NSW: (02) 9821 3633 ACT: (02) 6280 7475 SA: (08) 8244 5001 QLD: (07) 3872 3872 NT: (08) 8947 2262 TAS: (03) 6331 4190
DUAL CAB ASCENT CANOPY
(2015 Vehicle Production Onwards)
Page 1 of 44 ARB Copyright 2019 3789507
