CAUTION
Do not look directly into the LED work lamp or the light
source.
1. The LED work lamp (10) lights up automatically as
soon as the product is switched on.
9.2 Setting the pressure
Notes:
The display and thus also the product switch off automati-
cally after approx. three minutes of inactivity.
By pressing the on/off button on the display, you can
change the pressure unit between "bar" and "psi".
1. Switch on the display indicator (4) as described under
Switching on/off.
2. Press and hold the "+" button (5) or the "-" button (7)
until the display flashes.
3. Press the "+" button (5) or the "-" button (7) to set the
desired pressure.
If you keep the "+" button (5) or the "-" button (7)
pressed for a long time, the value changes quickly.
4. After you have seen the desired pressure in the dis-
play (4), do not press any further buttons for approx. 3
sec.
5. Your desired pressure is now set.
9.3 Inflating
Note:
Do not overinflate inflatables! They could burst. Before in-
flating, determine the maximum permissible pressure.
1. Select the appropriate adapter (13-16) (see 8.2) and
insert it as described in 8.3.
2. Select the desired pressure as described in .
3. If present, open the closure of the inflatable.
4. Connect the selected adapter (13-16) to your inflat-
able.
5. Switch on the product as described in 9.1.
6. Now fill your inflatable with the preset air pressure.
ATTENTION
Danger of burning!
The accessories can become hot.
7. After the preset pressure has been reached and the
product has automatically switched off, disconnect the
inflatable.
8. Close the closure of the inflatable, if present.
18 | GB

10 Cleaning and maintenance

WARNING
Have maintenance and repair tasks that are
not described in this operating manual, car-
ried out by a specialist workshop. Use only
original spare parts.
There is a risk of accident! Always perform
maintenance and cleaning work with the bat-
tery removed. There is a danger of injury! Let
the Product cool down before all mainte-
nance and cleaning tasks. Elements of the
engine are hot. There is a danger of injury
and burning!
The product can start unexpectedly and cause injuries.
– Remove the battery.
– Allow the product to cool down.
– Remove the tool attachment.
10.1 Cleaning
1. Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub the
product clean with a clean cloth or blow it off with
compressed air at low pressure. We recommend that
you clean the product directly after every use.
2. Ventilation openings must always be free.
3. Do not use any cleaning products or solvents; they
could attack the plastic parts of the product. Make
sure that no water can penetrate the product interior.
4. Wipe any dirt off the lens with a dry cloth. Be careful
to avoid scratching the LED lamp as this can severely
reduce the light intensity.
10.2 Maintenance
The product is maintenance-free.

11 Storage

Preparation for storage
1. Remove the battery.
2. Clean and check the product for damage.
3. For easy storage, you can press the compressed air
hose (12) into the compressed air hose holder (2) on
the top side of the product (Fig. 4).
Store the product and its accessories in a dark, dry and
frost-free place that is inaccessible to children.
The optimum storage temperature is between 5°C and
30˚C.
Store the product in its original packaging.
Cover the product to protect it from dust or moisture.
Store the operating manual with the product.
12 Repair & ordering spare parts
With this product, it is necessary to note that the following
parts are subject to natural or usage-related wear, or that
the following parts are required as consumables.
