Scheppach C-AC20-X Original Operating Instructions page 13

Table of contents
1 Introduction ........................................................
2 Product description (fig. 1) .................................
3 Scope of delivery (Fig. 1) ...................................
4 Proper use..........................................................
5 Safety instructions..............................................
6 Technical data....................................................
7 Unpacking ..........................................................
8 Before commissioning........................................
9 Operation ...........................................................
10 Cleaning and maintenance ................................
11 Storage...............................................................
12 Repair & ordering spare parts ............................
13 Disposal and recycling .......................................
14 Troubleshooting .................................................
15 Warranty conditions - Scheppach 20V IXES se-
ries .....................................................................
16 EU Declaration of Conformity.............................
17 Exploded view .................................................... 202
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Attention! Failure to observe the safety signs
and warning information affixed to the prod-
uct and failure to observe the safety and op-
erating manual can result in serious injury or
even death.
Wear hearing protection.
Do not expose the product to rain. The prod-
uct may only be stationed, stored and oper-
ated in dry ambient conditions.
Guaranteed sound power level of the prod-
uct.
Lithium-ion battery
The product complies with the applicable
European directives.
1 Introduction
13 Manufacturer:
13 Scheppach GmbH
14 Günzburger Straße 69
14 D-89335 Ichenhausen
14 Dear Customer
16 We hope your new product brings you much enjoyment
and success.
16
Note:
17
In accordance with the applicable product liability laws,
17
the manufacturer of this product assumes no liability for
18
damage to the product or caused by the product arising
from:
18
• Improper handling
18
• Non-compliance with the operating manual
19
• Repairs carried out by third parties, unauthorised spe-
19
cialists
• Installing and replacing non-original spare parts
20
• Improper use
21
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2 Product description (fig. 1)
1. Union nut
2. Compressed air hose holder
3. Ventilation openings
4. Display indicator
5. "+" button (press to increase)
6. ON/OFF button
7. "-" button (press to decrease)
8. Handle
9. Battery mount
10. LED work lamp
11. On/off switch
12. Compressed air hose
12a. Adapter receptacle
12b. Fixing lever
12c. Connection
13. Ball needle
14. Universal valve adapter (2x)
15. Valve adapter for Dunlop/flash valves
16. Valve adapter for Sclaverand valves
17. Release button (battery)
18. Battery*
* = not included in the scope of delivery!
www.scheppach.com GB | 13
