- Page 1 SB-244-111XXX Series SB-244-11115G4 SB-244-11135G7 Industrial Fanless PC w/ Intel ® Tiger Lake Core™ i5/i3 Processors User’s Manual Version 1.0 2024.04...
- Page 2 Revision History Version Date Description 2024.04 Initial release - II -...
-
Page 3: Table Of Contents
Contents Contents Revision History ................II Contents ....................i Preface....................iii Copyright Notice ..................iii Declaration of Conformity ...............iii CE ....................iii FCC Class A ..................iii RoHS ....................iv SVHC / REACH ................iv Important Safety Instructions ..............v Warning ....................vi Lithium Battery Replacement ..............vi Technical Support .................. - Page 4 This page is intentionally left blank. - ii -...
-
Page 5: Preface
Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages. -
Page 6: Rohs
(PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed... -
Page 7: Important Safety Instructions
Preface Important Safety Instructions Read these safety instructions carefully 1. Read all cautions and warnings on the equipment. 2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage 3. Make sure the correct voltage is connected to the equipment. 4. -
Page 8: Warning
Preface Warning The Box PC and its components contain very delicately Integrated Circuits (IC). To protect the Box PC and its components against damage caused by static electricity, you should always follow the precautions below when handling it: 1. Disconnect your Box PC from the power source when you want to work on the inside. -
Page 9: Warranty
Preface Warranty This product is warranted to be in good working order for a period of two year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms. - Page 10 This page is intentionally left blank. - viii -...
-
Page 11: Chapter 1 - Introduction
Chapter 1 Introduction Chapter 1 - Introduction - 1 -... -
Page 12: Features
Introduction 1.1. Features Intel Tiger Lake Core i5/i3 Processors • ® ™ 1 x SDRAM DDR4 3200 MHz (max. 32G) • Support 4 Gigabit LAN • Support DP/HDMI 3 independent video outputs • 1.2. About this Manual This manual is meant for the experienced users and integrators with hardware knowledge of personal computers. -
Page 13: Specifications
Introduction 1.3. Specifications System ® Intel Tiger Lake i3-1115G4 3.0G (6M Cache, up to 4.0GHz) (SB-244-11115G4) ® Intel Tiger Lake i5-1135G7 2.4G (8M Cache, up to 4.2GHz) (SB-244-11135G7) 1 x SDRAM DDR4 3200 MHz (max. 32G) Memory 4GB WT DDR4 SO-DIMM pre-installed*(CTOS) Graphics Intel Iris... - Page 14 Introduction Audio 1 x Audio(Line-out & Mic-in) Chip 888S/897 Type Mechanical Button 1 x Power button W/Led Chassis Aluminum Alloy Desk-Mount, Wall-Mount, DIN-Rail(optional) Mounting VESA-mount (75x75mm, 100x100mm optional) Dimension 224 x 140 x 49.2 mm (W x H x D) Weight (Net) 1.6kg Environmental...
-
Page 15: Inside The Package
Introduction 1.4. Inside the Package Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: 1 x SB-244-111XXX Series •... - Page 16 This page is intentionally left blank. - 6 -...
-
Page 17: Chapter 2 - Getting Started
Chapter 2 Getting Started Chapter 2 - Getting Started - 7 -... -
Page 18: Dimensions
Getting Started 2.1. Dimensions 2.2. Overview 2.2.1. Front side - 8 -... - Page 19 Getting Started Back Side View Left Side View - 9 -...
- Page 20 Getting Started Item Item Power button DP Port HDMI port HDMI 3x USB3.2 Gen. 2 1 x USB2.0 DC-IN Audio USB2.0 RS485/422/232 Remote control Antenna RS232 Pre-holes SIM card 2 x DB9 oDoor module 2.2.2 Power Button Function: Power Button Power LED Status Off: Power off or system is in hibernate mode Green LED permanently: System is working...
- Page 21 Getting Started 2.2.2 DC-IN Power Input Pin Definition Pin Definition +10~36V 2.2.3 HDMI/DP Input Description Status Figure HDMI 4Kx2Kx24bpp@24Hz 4096x2304x36bpp@60Hz 2.2.4 USB Ports Function: USB 3.2/2.0 Stacked Connectors Connector Type: USB 3.0/2.0 type A connectors Pin Assignment: The pin assignments conform to the industry standard. USB Ver.
- Page 22 Getting Started 2.2.6 DC-IN Power Connector The SB-244-111XXX Series device features a Phoenix connector and supports a wide range of voltage inputs, ranging from 10-36VDC. Additionally, it comes with reverse wiring protection, which ensures that the system will not be damaged even if the ground and power lines are connected in reverse.
- Page 23 Getting Started 2.2.9 Serial Port Connector RS-232/RS-422/RS-485 (COM1 ~ COM4) COM1, COM2 Function: RS-232/RS-422/RS-485 Selectable Serial Port Connector Type: External 9-pin D-sub male connector Pin Assignment: COM1~4 RS485/RS-422/RS-232 connector RS-232 RS-422 RS-485 Data- Data+ COM 5~6 RS232 connector RS-232 RS-232 Note1: COM 1~4 can be set as selection mode through BIOS mode and support RS-485/RS-422/RS-232 auto-flow.
- Page 24 Getting Started 2.2.10 3G/4G/5G Pre-Antenna Hole 2.2.11 SIM Card Socket Function: 3G/4G/SIM card Socket Connector Type: SIM Card Socket Pin Assignment: The pin assignments conform to the industry standard. 2.3 Internal Connector / Jumper Top Side: - 14 -...
- Page 25 Getting Started Pin Definition Printing SATA Power connector JSATAPWR1 Mini-PCIe slot(WIFI/CAN/mSATA/4G module) MINI_PCIE1 3G/4G SIM card JSIM1 AT/ATX Jumper ATX_AT SATA 3.1 connector SATA1 GPIO Jumper JGPIO_PWR1 Clear CMOS CMOS1 Battery connector JBAT1 GPIO PIN connector JGPIO1 M.2 2230 connector 2230 Internal USB pin head connector JUSB1...
- Page 26 Getting Started 2.3.1 Mini-PCIE Slot Function: Mini PCI-e Socket support WIFI/CAN/4G module Connector Type: Mini PCI-e 52-pin Socket Pin Assignment: The pin assignments conform to the industry standard. Note: M_PCIE1 support WIFI/CAN/4G module expansion(8/10/12/14/16 no PCIE signal) 2.3.2 8bit internal GPIO pin Pin Definition Pin Definition VCC_GPIO...
- Page 27 Getting Started 2.3.3 8bit GPIO power and jumper Function: JGPIO_PWR1 jumper Setting: Description Short 1-2 (Default) Short 2-3 3.3V 2.3.4 AT/ATX Selection Jumper This jumper supports two power-on modes: AT mode and ATX mode. When AT mode is selected, the system will automatically turn on after being connected to the power supply;...
- Page 28 Getting Started 2.3.6 SATA Power Connector Function: SATA Power Connector Connector Type: 2.54mm pitch 4-pin Wafer Description Pin Assignment: VCC5 +12V 2.3.7 COM5/6 Pin Function: COM5/6 Pin Connector Type: 2.54mm pitch 6-pin Description Pin Assignment: COM5_SOUT COM6_SOUT COM5_SIN COM6_SIN - 18 -...
-
Page 29: Chapter 3 - Engine Of The Computer
Chapter 3 Installation & Maintenance Chapter 3 - Engine of the Computer - 19 -... -
Page 30: Installation And Maintenance
Installation & Maintenance 3.1. Installation and Maintenance 1. Remove 6 screws from the bottom cover, as shown in 3.1-1. Figure 3.1-1 Installation and Maintenance - 20 -... - Page 31 Installation & Maintenance 2. Remove four M3x4 screws of the corner, disassembly schematic diagram as 3.1-2 3. Remove the two M3x6 spring screws in the middle of the motherboard and remove the aluminum extrusion. Figure 3.1-2 Disassembly Schematic Diagram - 21 -...
-
Page 32: Key Parts Installation And Removal
Installation & Maintenance 3.2 Key Parts installation and removal 1. Remove the memory module and M.2 2242 module then remove 1 pan-head M3x3 screw, as shown in Figure 3.2-1. Figure 3.2-1 Install and Remove key parts - 22 -... - Page 33 Installation & Maintenance 3. Remove the Mini-PCIE module: Remove 1 flat-head M2x3 screw and remove the M2-2230 WiFi module, as shown in Figure 3.2-2. Figure 3.2-2 Install and Remove key parts - 23 -...
- Page 34 Installation & Maintenance 4. Attach the CPU PAD to the CPU chip or remove it from the CPU chip; Figure: 3.2-3 Figure 3.2-3 Install and Remove CPU PAD - 24 -...
- Page 35 Installation & Maintenance 5. Apply the memory thermal PAD and M.2 thermal PAD to the chassis. / Remove the chassis from the aluminum extrusion as shown in 3.2-4. Figure 3.2-4 Install and Remove Memory/M.2 PAD - 25 -...
-
Page 36: Install/Remove Hdd
Installation & Maintenance 3.3 Install/Remove HDD 1. Remove six M3x4 screws and the bottom cover; 2. Place the HDD and bracket in the direction as shown in the figure, and secure them with four I-head M3*4 screws on the sides; 3. -
Page 37: Install/Remove Sim Card
Installation & Maintenance 3.4 Install/Remove SIM card 1. Remove the two M3*4 screws and remove the side cover; 2. Push/remove the SIM card into the card slot and lock the cover back, as shown in Figure 3.4-1. Figure 3.4-1 Install and Remove SIM card - 27 -... - Page 38 This page is intentionally left blank. - 28 -...
-
Page 39: Chapter 4 - Bios
Chapter 4 BIOS Chapter 5 - BIOS - 29 -... - Page 40 BIOS The BIOS Setup utility is to configure the system settings stored in the system’s BIOS ROM. The BIOS is activated once the computer powers on. When the computer is off, the battery on the main board supplies power to BIOS RAM. To enter the BIOS Setup utility, keep hitting the “Delete”...
- Page 41 BIOS Key Commands The BIOS Setup utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and use the utility. Hot-Key Function Description <Del> After System Open Enter BIOS mode Enter the boot up sequence menu <F7>...
-
Page 42: Main - Sets System Time & Date
BIOS 4.1. Main - Sets system Time & Date. The Main menu features the settings of System Date and System Time and displays some BIOS info. Note: Actual model name and board information varies according to your model. Setting Description System Date Sets system date. -
Page 43: Advanced
BIOS 4.2. Advanced - 33 -... -
Page 44: Turbo Mode Setting
BIOS 4.2.1. Turbo Mode Setting Enter Advanced menu, select "Power & Performance" -> "CPU-Power Management Control" -> "Turbo Mode". After that users can choose Enabled/ Disabled. After setting, press F4 to save and exit, the system will take effect after reboot. -
Page 45: Com Mode Setting
BIOS 4.2.2. COM Mode Setting - 35 -... - Page 46 BIOS Under the Advanced menu, select "IT8786 Super IO Configuration" -> "Serial Port X Configuration" -> "COM Mode Select". Users can select RS232, RS422 and RS485 for COM mode setting. After setting, press F4 to save and exit, the system will take effect after reboot. - 36 -...
-
Page 47: Chipset Menu
BIOS 4.3 Chipset Menu Use the arrow keys on the keyboard to move to the Chipset option. The submenu is detailed as shown. - 37 -... -
Page 48: Raid Setting
BIOS 4.4. Raid Setting 1. Enter the Chipset interface and select System Agent Configuration> VMD setup menu -> Enable VMD controller. You can set the Raid function to be turned on and off. After the settings are completed, press F4 to save and exit. It will take effect after the system restarts. - Page 49 BIOS 2. After enabling VMD, press F4 to save and restart. Press Delete to enter the BIOS interface and select Advanced->Intel(R) Rapid Storage Technology- >Create RAID Volume. The RAID Level option can select the required RAID level. - 39 -...
- Page 50 BIOS - 40 -...
- Page 51 BIOS 3. Under the Select Disks option, select the disks to be grouped into RAID, where "x" means selected, and "space" means unselected. - 41 -...
- Page 52 BIOS - 42 -...
- Page 53 BIOS 4. After selecting the disk, select "Create Volume" to complete the RAID configuration. - 43 -...
- Page 54 BIOS 5. If you need to delete the Raid function, select Delete - 44 -...
-
Page 55: Auto Turn-On (At/Atx)
BIOS 4.5. Auto TURN-ON (AT/ATX) Enter "Chipset" menu, and select "Chipset"->"PCH-IO Configuration"->"State After G3" in order. Users can select "S0 State/S5 State" for power mode on the system. "S0 State" is AT mode, it will power on the system automatically after connecting the power supply, and S5 State is ATX mode.Users need to press the power button to turn on the system after connecting the power supply. -
Page 56: Usb Power In S4/S5
BIOS 4.6. USB Power in S4/S5 Set whether the USB port is powered during sleep or shutdown. Enable: USB port with power in S4/S5 - 46 -... -
Page 57: Security
BIOS 4.7. Security Use the arrow keys on the keyboard to move to the Security option. The submenu has detailed option descriptions, including security settings. Administrator and user passwords can be set to protect the computer from infringement. Setting Description To set up an administrator password: Select Administrator Password. -
Page 58: Boot
BIOS 4.8. Boot "Boot" menu contains the boot settings above. Users can set the boot logo or select the bootup devices, etc. Setting Description Bootup ► Set NumLock on or off when booting. NumLock State ► Enabled: Logo will be displayed at boot up. Quiet Boot Disabled: Boot up the system and display the self-test screen, no logo, ►... -
Page 59: Save & Exit
BIOS 4.9. Save & Exit The Save & Exit menu displays the way to exit the BIOS setup utility. When users have completed the setup, users must save and exit for the changes to take effect. Setting Description Save Changes Saves the changes and quits the BIOS Setup utility.
