- Page 1 SB-142-1J64 Industrial Fanless PC w/Intel Elkhart Lake ® Celeron J6412 Processor User’s Manual Version 1.0 2024.01...
- Page 2 Revision History Version Date Description 2024.01 Initial release - II -...
-
Page 3: Table Of Contents
Contents Contents Revision History ................II Contents ....................i Preface....................iii Copyright Notice ..................iii Declaration of Conformity ...............iii CE ....................iii FCC Class A ..................iii RoHS ....................iv SVHC / REACH ................iv Important Safety Instructions ..............v Warning ....................vi Lithium Battery Replacement ..............vi Technical Support .................. -
Page 4: Contents
Contents 3.2. Install M.2 2242 Storage/Thermal Pad .......... 17 3.3. Mounting ..................18 3.3.1 Wall mounting ............... 18 3.3.2 DIN-rail mounting ..............19 Chapter 4 - BIOS ................21 4.1. Main - Sets system Time & Date............ 24 4.2. Advanced ..................25 4.2.1. -
Page 5: Preface
Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages. -
Page 6: Rohs
(PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed... -
Page 7: Important Safety Instructions
Preface Important Safety Instructions Read these safety instructions carefully 1. Read all cautions and warnings on the equipment. 2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage 3. Make sure the correct voltage is connected to the equipment. 4. -
Page 8: Warning
Preface Warning The Box PC and its components contain very delicately Integrated Circuits (IC). To protect the Box PC and its components against damage caused by static electricity, you should always follow the precautions below when handling it: 1. Disconnect your Box PC from the power source when you want to work on the inside. -
Page 9: Warranty
Preface Warranty This product is warranted to be in good working order for a period of two year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms. - Page 10 This page is intentionally left blank. - viii -...
-
Page 11: Chapter 1 - Introduction
Chapter 1 Introduction Chapter 1 - Introduction - 1 -... -
Page 12: Features
Introduction 1.1. Features Intel Celeron J6412 CPU Elkhart Lake(2.0 GHz/2.6GHz) • ® ® 1 x SDRAM DDR4 3200 MHz (max. 32G) • Support 4 Gigabit LAN • Support DP/HDMI video output • • Support M.2 SSD 1.2. About this Manual This manual is meant for the experienced users and integrators with hardware knowledge of personal computers. -
Page 13: Specifications
Introduction 1.3. Specifications System ® ® Intel Celeron J6412 CPU Elkhart Lake (2.0 GHz/2.6GHz) 1 x SDRAM DDR4 3200 MHz SO-SIMM slot (max. 32G) Memory 4GB DDR4 SO-DIMM pre-installed*(CTOS) Graphics Intel UHD Graphics for 10 Gen Intel Processors ® ® 1 x RJ45 Intel I210AT for 10/100/1000 Mbps LAN Chipset 3 x RJ45 Intel I226-V for 10/100/1000 Mbps... -
Page 14: Inside The Package
1.4. Inside the Package Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: 1 x SB-142-1J64 • User’s manual •... -
Page 15: Chapter 2 - Getting Started
Chapter 2 Getting Started Chapter 2 - Getting Started - 5 -... -
Page 16: Dimensions
Getting Started 2.1. Dimensions 2.2. Overview 2.2.1. Front side View - 6 -... -
Page 17: Dc-In Power Input
Getting Started Front Side Panel List Item Item LAN3/4 DC-IN LAN1/2 Com1 HDMI Com2 POWER_LED USB2.0 HDD_LED USB3.0 2.2.2 DC-IN Power Input Pin Definition Pin Definition +12~24V 2.2.3 HDMI/DP Input Figure 2.2.2-1 HDMI / DP Connector - 7 -... -
Page 18: Serial Port Connector(Com1, Com2)
Getting Started 2.2.4 Serial Port Connector(COM1, COM2) COM1, COM2 Function: RS-232/422/485 Selectable Serial Port Connector Type: External 9-pin D-sub male connector Pin Assignment: Pin Desc. Pin Desc RS-232 RS-422 Data- RS-485 Data+ Note: COM1/2 support RS232/422/485. 2.2.5 USB Port Function: USB 3.1/3.0/2.0 Stacked Connectors Connector Type: USB 3.0/2.0 type A connectors Pin Assignment:... -
Page 19: Lan Port
Getting Started 2.2.6 LAN Port LAN Port Function: RJ-45 port for Giga Lan Connector Type: 4 x RJ-45 connectors that support 10/100/1000Mbps fast Ethernet Pin Assignment: The pin assignments conform to the industry standard. LED Indicators Indicator Function Status Off: not working Networking Status Green: Working Off: 10Mbps... -
Page 20: Antenna Hole
Getting Started 2.2.8 Antenna Hole There are 2 antenna reserved holes on the rear panel of the product to facilitate users to install the antenna of the wireless module. 2.3 Internal Connector / Jumper - 10 -... -
Page 21: 2242
Getting Started Pin Definition Printing M.2 2242 M.2 SSD DDR4 SO-DIMM socket DIMM1 AT/ATX selection mode ATX_AT Function Reset, LED, Power Button Pin Head JFP1 COM port, GPIO PIN head Clear Cmos Jumper JCMOS1 GPIO GPIO_V DC-IN DC-IN 2.3.1 M.2 2242 M.2_SSD Function: M.2 B-Key Connector... -
Page 22: Ddr4 So-Dimm Socket
Getting Started 2.3.2 DDR4 SO-DIMM socket Function: 260-pin DDR4 SO-DIMM memory socket Setting: The Pin assignment conform to the industry standard. 2.3.3 AT/ATX Selection Jumper(JP23) Function: AT/ATX selection mode Setting: Description Short 1-2 AT Mode Short 2-3 ATX mode 2.3.4 JFP1 Pin definition Description Description PWR_SW... -
Page 23: Clear Cmos
Getting Started 2.3.6 Clear CMOS Function: Clears/keeps CMOS Jumper Type: 2.00 mm pitch 1x2-pin header Setting: Description Short Clears CMOS Open Keeps CMOS (default) 2.3.7 GPIO Jump JGPIO Jump Default setting is 3.3V, users is able to set to 5V. Follow the table as below for the GPIO setting GPIO Memory GPO High... - Page 24 Getting Started Bit8=1 Bit8=0 JGPIO4 0xFD6D09B0 Bit 0=1 Bit 0=0 Bit9=0 Bit9=1 Bit8=1 Bit8=0 JGPIO5 0xFD6D0A10 Bit 0=1 Bit 0=0 Bit9=0 Bit9=1 Bit8=1 Bit8=0 JGPIO6 0xFD6D0A20 Bit 0=1 Bit 0=0 Bit9=0 Bit9=1 Bit8=1 Bit8=0 JGPIO7 0xFD6D0A30 Bit 0=1 Bit 0=0 Bit9=0 Bit9=1 Bit8=1...
-
Page 25: Chapter 3 - Engine Of The Computer
Chapter 3 Installation & Maintenance Chapter 3 - Engine of the Computer - 15 -... -
Page 26: Installation And Maintenance
Installation & Maintenance 3.1. Installation and Maintenance 1. Remove 2 screws from the bottom panel, as shown in 3.1-1. 2. Remove 3 screws on front panel, disassembly schematic diagram as 3.1-2 - 16 -... -
Page 27: Install M.2 2242 Storage/Thermal Pad
Installation & Maintenance 3. Remove 6 screws on the main board, disassemble as shown in 3.1-3. 3.2. Install M.2 2242 Storage/Thermal Pad 1. Remove 2 screws on the bottom cover from the computer as described in 3.1-1 2. Install/Remove the storage from the slot and attach the thermal pad to the storage. -
Page 28: Mounting
Installation & Maintenance 3.3. Mounting SB-142-1J64 can support wall mounting and DIN-Rail mounting. DIN-rail mounting require optional mounting brackets. 3.3.1 Wall mounting 1. Take the bracket from the box: 2. Install/Remove the storage from the slot and attach the thermal pad to the storage. -
Page 29: Din-Rail Mounting
Installation & Maintenance 3.3.2 DIN-rail mounting 1. Take the DIN-rail from the box and attach it with 2 screws as below. - 19 -... - Page 30 This page is intentionally left blank. - 20 -...
-
Page 31: Chapter 4 - Bios
Chapter 4 BIOS Chapter 5 - BIOS - 21 -... - Page 32 BIOS The BIOS Setup utility is featured by American Megatrends Inc to configure the system settings stored in the system’s BIOS ROM. The BIOS is activated once the computer powers on. When the computer is off, the battery on the main board supplies power to BIOS RAM.
- Page 33 BIOS Key Commands The BIOS Setup utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and use the utility. Keystroke Function Enter the boot up sequence menu After System Open Ctrl + Alt + DEL Restart the system ←...
-
Page 34: Main - Sets System Time & Date
BIOS 4.1. Main - Sets system Time & Date. The Main menu features the settings of System Date and System Time and displays some BIOS info. Note: Actual model name and board information varies according to your model. Setting Description System Date Sets system date. -
Page 35: Advanced
BIOS 4.2. Advanced - 25 -... -
Page 36: Turbo Mode Setting
BIOS 4.2.1. Turbo Mode Setting Enter Advanced menu, select "Power & Performance" -> "CPU-Power Mangement Control" -> "Turbo Mode". After that users can choose Enabled/ Disabled. After setting, press F4 to save and exit, the system will take effect after reboot. -
Page 37: Com Mode Setting
BIOS 4.2.2. COM Mode Setting - 27 -... - Page 38 BIOS Under the Advanced menu, select "IT8786 Super IO Configuration" -> "Serial Port X Configuration" -> "COM Mode Select". Users can select RS232, RS422 and RS485 for COM mode setting. After setting, press F4 to save and exit, the system will take effect after reboot. - 28 -...
-
Page 39: Usb Power Setting In Power Off / Hibernation Mode
BIOS 4.3 USB Power Setting in Power Off / Hibernation Mode Select "Chipset" menu->"PCH-IO Configuration"-> "USB Power in S5" in order. Users can set the USB power in S5 according to the actual application's requirements and select High or Low to turn it on or off. After setting, press F4 to save and exit, the system will take effect after reboot. -
Page 40: Gpio Setting
BIOS 4.4. GPIO Setting Select "Chipset" -> "PCH-IO Configuration", and select "Enable". Users can set a single GPIO pin as "GPI" or "GPO-High" or "GPO-Low". After setting, press F4 to save and exit, the system will take effect after reboot. - 30 -... -
Page 41: Auto Turn-On (At/Atx)
BIOS 4.5. Auto TURN-ON (AT/ATX) Enter "Chipset" menu, and select "Chipset"->"PCH-IO Configuration"->"State After G3" in order. Users can select "S0 State/S5 State" for power mode on the system. "S0 State" is AT mode, it will power on the system automatically after connecting the power supply, and S5 State is ATX mode.Users need to press the power button to turn on the system after connecting the power supply. -
Page 42: Security
BIOS 4.6. Security Setting Description To set up an administrator password: Select Administrator Password. An Create New Password dialog then pops up Adminstration Password onscreen. Enter your desired password that is no less than 3 characters and no more than 20 characters. Hit [Enter] key to submit. -
Page 43: Boot
BIOS 4.7. Boot "Boot" menu contains the boot settings above. Users can set the boot logo or select the bootup devices, etc. - 33 -... -
Page 44: Setting The Boot Logo
BIOS 4.8. Setting the Boot Logo Enter the Boot menu, select Quiet Boot, and then press F4 to save and exit, the system will take effect after reboot. Setting Description Enabled: Logo will be displayed at boot up. ► Quiet Boot Disabled: Boot up the system and display the self-test screen, no logo, ►... -
Page 45: Setting Boot Option Priority
BIOS 4.9. Setting Boot Option Priority Set the system boot priorities. Enter Boot menu. In "Boot Option Priorities", users can set the order of boot devices. Boot Option #1 is the first priority boot item, Boot Option #2 is the second boot item, and so on. -
Page 46: Save & Exit
BIOS 4.10. Save & Exit The Save & Exit menu displays the way to exit the BIOS setup utility. When users have completed the setup, users must save and exit for the changes to take effect. Setting Description Save Changes Saves the changes and quits the BIOS Setup utility.
