- Page 1 SB-226-1J64 Industrial Fanless PC w/Intel Elkhart Lake ® Celeron J6412 Processor User’s Manual Version 1.0 2024.03...
- Page 2 Revision History Version Date Description 2024.01 Initial release - II -...
-
Page 3: Table Of Contents
Contents Contents Revision History ................II Contents ....................i Preface....................iii Copyright Notice ..................iii Declaration of Conformity ...............iii CE ....................iii FCC Class A ..................iii RoHS ....................iv SVHC / REACH ................iv Important Safety Instructions ..............v Warning ....................vi Lithium Battery Replacement ..............vi Technical Support .................. -
Page 4: Contents
Contents 2.4.2 NPN Input Wiring Method ............. 17 2.4.3 PNP Input Wiring Method ............. 17 2.4.4 Output Connect to External Loading Device ......18 2.4.5 Output PNP Wiring Method ..........18 2.4.6 Output NPN Wiring Method ..........19 2.4.7 Output Connect to PLC Wiring Method ........ 20 Chapter 3 - Engine of the Computer ..........21 3.1 Installation and Maintenance............ -
Page 5: Preface
Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages. -
Page 6: Rohs
(PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed... -
Page 7: Important Safety Instructions
Preface Important Safety Instructions Read these safety instructions carefully 1. Read all cautions and warnings on the equipment. 2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage 3. Make sure the correct voltage is connected to the equipment. 4. -
Page 8: Warning
Preface Warning The Box PC and its components contain very delicately Integrated Circuits (IC). To protect the Box PC and its components against damage caused by static electricity, you should always follow the precautions below when handling it: 1. Disconnect your Box PC from the power source when you want to work on the inside. -
Page 9: Warranty
Preface Warranty This product is warranted to be in good working order for a period of two year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms. - Page 10 This page is intentionally left blank. - viii -...
-
Page 11: Chapter 1 - Introduction
Chapter 1 Introduction Chapter 1 - Introduction - 1 -... -
Page 12: Features
Introduction 1.1 Features Intel Celeron J6412 CPU Elkhart Lake(2.0 GHz/2.6GHz) • ® ® 1 x SDRAM DDR4 3200 MHz (max. 32G) • Support 2 Gigabit LAN • Support M.2 SSD, MiniPCIE, mSATA • 1.2 About this Manual This manual is meant for the experienced users and integrators with hardware knowledge of personal computers. -
Page 13: Specifications
Introduction 1.3 Specifications System ® ® Intel Celeron J6412 CPU Elkhart Lake (2.0 GHz/2.6GHz) 1 x SDRAM DDR4 3200 MHz SO-SIMM slot (max. 32G) Memory 4GB DDR4 SO-DIMM pre-installed*(CTOS) Graphics Intel UHD Graphics for 10 Gen Intel Processors ® ® LAN Chipset 2 x Intel I211 for 10/100/1000 Mbps, colay I210 Watchdog Timer... - Page 14 Introduction Dimension 200 x 130 x 44 mm (W x H x D) Weight (Net) 1.5kg Environmental Operating Temp. -20 ~ 60°C (-4 ~ 140°F) Storage Temp. -40 ~ 85°C (-40 ~ 185°F) Operating 5% ~ 95% (non-condensing) Humidity Random Vibration 5~500Hz, 2Grms operation Operation: 10G@11ms Shock Non-operation: 30G@11ms...
-
Page 15: Inside The Package
1.3 Inside the Package Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: 1 x SB-226-1J64 • User’s manual •... -
Page 16: Chapter 2 - Getting Started
Chapter 2 Getting Started Chapter 2 - Getting Started - 6 -... -
Page 17: Dimensions
Getting Started 2.1 Dimensions 2.2 Overview 2.2.1 Front side View Front Side Panel List Item Item DC-IN USB 3.1 HDMI COM1 Audio - 7 -... -
Page 18: Left Side View
Getting Started 2.2.2 Left Side View Pin Definition Pin Definition COM2/3/4/5 GPIO COM6 2.2.3 DC-IN Power Input Pin Definition Pin Definition +12~36V 2.2.4 HDMI/DP Input Figure 2.2.2-1 HDMI / DP Connector - 8 -... -
Page 19: Serial Port Connector(Com1, Com2)
Getting Started 2.2.5 Serial Port Connector(COM1, COM2) COM1, COM2 Function: RS-232/422/485 Selectable Serial Port Connector Type: External 9-pin D-sub male connector Pin Assignment: Pin Desc. Pin Desc RS-232 RS-422 Data- RS-485 Data+ Note: COM1/2 support RS232/422/485. COM2/3/4/5/6 + GPIO PIN Definition - 9 -... -
Page 20: Usb Port
Getting Started 2.2.6 USB Port Function: USB 3.1/3.0/2.0 Stacked Connectors Connector Type: USB 3.1/3.0/2.0 type A connectors Pin Assignment: The pin assignments conform to the industry standard. USB Ver. Max Speed Speed name Max V/I USB2.0 High-Speed DSR 5V/0.5A USB3.0 5Gbps(500MB/S) Super-Speed USB 5V/900mA USB3.1... -
Page 21: Power Led Status
Getting Started 2.2.9 Power LED Status Description Status ► Off: Power off or system is in hibernate mode ► Green LED Permanently: Ststem is Power LED Status working ► Green LED Blinking: The system is processing data 2.2.10 Antenna Hole There are 2 antenna reserved holes on the rear panel of the product to facilitate users to install the antenna of the wireless module. -
Page 22: Ddr4 So-Dimm Socket
Getting Started Item Printing DDR4 SO-DIMM socket DIMM1 3G/4G SIM socket JSIM1 GPIO voltage switch jumper GPIO_PWR1 M.2_SSD M.2_SSD AT/ATX selection jumper 2.3.1 DDR4 SO-DIMM socket Function: 260-pin DDR4 SO-DIMM memory socket Setting: The Pin assignment conform to the industry standard. 2.3.2 3G/4G SIM socket Function: SIM Card Socket... -
Page 23: Gpio Voltage Switch Jumper
Getting Started 2.3.3 GPIO voltage switch jumper JGPIO Jump 1) Default setting is 3.3V, users is able to set to 5V. 2) Follow the table as below for the GPIO setting GPIO Address GPIO1 GP85 GPIO2 GP84 GPIO3 GP83 GPIO4 GP82 3) Open the RW setting for GPI/GPO settings. - Page 24 Getting Started About High/Low setting: This function is located in IO Space after filling in the starting Register[0xA00], from the upper left Register, i.e., Register [0xA00], from left to right in order Register[0xA01], Register[0xA02]..Register[0xA01], Register[0xA02]. Each Register corresponds to a group of GPIOs (GPIO 1~8); as shown in the figure, the correspondence between Register and GPIO groups, starting from Register [0xA00] <-->...
-
Page 25: M.2_Ssd
Getting Started 2.3.4 M.2_SSD Function: M.2 B-Key Connector Connector Type: M.2 B-Key Connector supporting 22x42 modules Pin Assignment: The pin assignments conform to the industry standard. 2.3.5 AT/ATX Selection Jumper(JP1) Function: AT/ATX selection mode Setting: Description Short 1-2 ATX Mode(Default) Short 2-3 AT mode - 15 -... -
Page 26: Pin Definition For Optional 8Di/8Do Card
Getting Started 2.4 PIN definition for Optional 8DI/8DO card Function: AT/ATX selection mode Setting: Description Short 1-2 ATX Mode(Default) Short 2-3 AT mode 8DI/8DO Channel definition Signal Description Signal Description 5-24V for external Pext VDD Isolated channel 1 power positive Isolated channel 1 Isolated channel 2 Isolated channel 2... -
Page 27: I/O Port Definition & Wiring Method
Getting Started 2.4.1 I/O Port Definition & Wiring Method Features: Compatible with PNP and NPN sensor inputs. The input voltage DC 5-24V. 2.4.2 NPN Input Wiring Method Features: NPN-type device connected to the IO input, DI_COM connected to the NPN-type sensor, the signal line connected to the DI (1-8), resistance according to the requirements of the sensor on the signal line "PULL HIGH"... -
Page 28: Output Connect To External Loading Device
Getting Started NPN Light Sensor Signal 2.4.4 Output Connect to External Loading Device(LED, Buzzer, Relay) The product was designed to meet the power supply range of DC 5-24V, 100mA per channel, programmable NPN and PNP outputs switching, and reverse connection protection.The wiring method is shown below for connecting to loading devices (e.g., relays, LEDs, motors, etc.) and PLC. -
Page 29: Output Npn Wiring Method
Getting Started Note: If inductive loads are to be connected, please make sure there is a reverse drain diode to prevent the reverse electromotive force from damaging the internal parts. 2.4.6 Output NPN Wiring Method DO is connected to "-" of the loading device and "+" of the loading device is connected to EXT. -
Page 30: Output Connect To Plc Wiring Method
Getting Started 2.4.7 Output Connect to PLC Wiring Method PNP PLC Features: VCC connects to EXT, DO_GND connects to PLC GND, and then the input of PLC connects to DO1-8. NPN PLC Features: PLC VCC connects to EXT, DO_GND connects to PLC GND, and then the input of PLC connects to DO1-8. -
Page 31: Chapter 3 - Engine Of The Computer
Chapter 3 Installation & Maintenance Chapter 3 - Engine of the Computer - 21 -... -
Page 32: Installation And Maintenance
Installation & Maintenance 3.1 Installation and Maintenance 1. Remove 12 screws on the 4 sides of the system, as shown below. 2. Remove 6 screws from the board inside, as shown in 3.1.2. - 22 -... -
Page 33: Install M.2 2242 Storage/Thermal Pad
Installation & Maintenance 3.2 Install M.2 2242 Storage/Thermal Pad 1. Remove 12 screws on the bottom cover from the computer as described in 3.1-1 2. Install/Remove the storage and attach the thermal pad to the storage. 3. Attach the accessory hexagonal studs to the screw holes, insert/remove the storage. -
Page 34: Mounting
Installation & Maintenance 3.4 Mounting SB-226-1J64 can support desktop mounting, wall mounting, VESA mounting and DIN-Rail mounting. VESA and DIN-rail mounting require optional mounting brackets. 3.4.1 Desktop & Wall Mounting 1. Take the bracket from the box: 2. Fastern 4 M3x6 screws, then install the device on a flat surface. . -
Page 35: Vesa Mounting (Optional)
2. Fasten the four screws to the device. 3.4.3 DIN-rail Mounting (Optional) 1. Take the VESA bracket from the box and attach it to the SB-226-1J64 with 4 screws. 2. Take the DIN-Rail from the box and attach it to the VESA bracket with 2 screws. - Page 36 This page is intentionally left blank. - 26 -...
-
Page 37: Chapter 4 - Bios
Chapter 4 BIOS Chapter 5 - BIOS - 27 -... - Page 38 BIOS The BIOS Setup utility is to configure the system settings stored in the system’s BIOS ROM. The BIOS is activated once the computer powers on. When the computer is off, the battery on the main board supplies power to BIOS RAM. To enter the BIOS Setup utility, keep hitting the “Delete”...
- Page 39 BIOS Key Commands The BIOS Setup utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and use the utility. Keystroke Function Enter the boot up sequence menu After System Open Ctrl + Alt + DEL Restart the system ←...
-
Page 40: Main - Sets System Time & Date
BIOS 4.1 Main - Sets system Time & Date The Main menu features the settings of System Date and System Time and displays some BIOS info. Note: Actual model name and board information varies according to your model. Select System Date or System Time to modify the system date and system time. The format of system date is "Month/Day/Year". -
Page 41: Advanced
BIOS 4.2 Advanced - 31 -... -
Page 42: Turbo Mode Setting
BIOS 4.2.1 Turbo Mode Setting Enter Advanced menu, select "Power & Performance" -> "CPU-Power Management Control" -> "Turbo Mode". After that users can choose Enabled/ Disabled. After setting, press F4 to save and exit, the system will take effect after reboot. -
Page 43: Com Mode Setting
BIOS 4.2.2 COM Mode Setting - 33 -... - Page 44 BIOS Under the Advanced menu, select "IT8786 Super IO Configuration" -> "Serial Port X Configuration" -> "COM Mode Select". Users can select RS232, RS422 and RS485 for COM mode setting. After setting, press F4 to save and exit, the system will take effect after reboot. - 34 -...
-
Page 45: Usb Power Setting In Power Off / Hibernation Mode
BIOS 4.3 USB Power Setting in Power Off / Hibernation Mode Select "Chipset" menu->"PCH-IO Configuration"-> "USB Power in S5" in order. Users can set the USB power in S5 according to the actual application's requirements and select High or Low to turn it on or off. After setting, press F4 to save and exit, the system will take effect after reboot. -
Page 46: Auto Turn-On (At/Atx)
BIOS 4.4 Auto TURN-ON (AT/ATX) Enter "Chipset" menu, and select "Chipset"->"PCH-IO Configuration"->"State After G3" in order. Users can select "S0 State/S5 State" for power mode on the system. "S0 State" is AT mode, it will power on the system automatically after connecting the power supply, and S5 State is ATX mode.Users need to press the power button to turn on the system after connecting the power supply. -
Page 47: Security
BIOS 4.5 Security Setting Description To set up an administrator password: Select Administrator Password. An Create New Password dialog then pops up Adminstration Password onscreen. Enter your desired password that is no less than 3 characters and no more than 20 characters. Hit [Enter] key to submit. -
Page 48: Boot
BIOS 4.6 Boot "Boot" menu contains the boot settings above. Users can set the boot logo or select the bootup devices, etc. - 38 -... -
Page 49: Setting The Boot Logo
BIOS 4.7 Setting the Boot Logo Enter the Boot menu, select Quiet Boot, and then press F4 to save and exit, the system will take effect after reboot. Setting Description Enabled: Logo will be displayed at boot up. ► Quiet Boot Disabled: Boot up the system and display the self-test screen, no logo, ►... -
Page 50: Setting Boot Option Priority
BIOS 4.8 Setting Boot Option Priority Set the system boot priorities. Enter Boot menu. In "Boot Option Priorities", users can set the order of boot devices. Boot Option #1 is the first priority boot item, Boot Option #2 is the second boot item, and so on. -
Page 51: Save & Exit
BIOS 4.9 Save & Exit The Save & Exit menu displays the way to exit the BIOS setup utility. When users have completed the setup, users must save and exit for the changes to take effect. Setting Description Save Changes Saves the changes and quits the BIOS Setup utility.
