Arbor Technology ASLAN-W812C-2930G2 User Manual

Fanless 10.1/11.6 industrial panel pc with intel bay trail soc processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ASLAN-W810/812C-
2930G2
Fanless 10.1"/11.6" Industrial Panel PC with
Intel
Bay Trail SoC Processor
®
User's Manual
Version 1.1
P/N: 4018080000110P
2019.09
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASLAN-W812C-2930G2 and is the answer not in the manual?

Questions and answers

Related Manuals for Arbor Technology ASLAN-W812C-2930G2

Summary of Contents for Arbor Technology ASLAN-W812C-2930G2

  • Page 1 ASLAN-W810/812C- 2930G2 Fanless 10.1”/11.6” Industrial Panel PC with Intel Bay Trail SoC Processor ® User’s Manual Version 1.1 P/N: 4018080000110P 2019.09...
  • Page 2 Revision History Version Time Description May, 2016 Initial release Sep, 2019 • Revised Operating Temp. in 1.3. Specifications • Remove driver DVD from packing list in 1.4. Inside the Package • Add cutout info to dimension drawing in 2.1. Dimensions • Revised the BIOS provider in Chapter 5 - BIOS...

  • Page 3: Table Of Contents

    Contents Contents Revision History ................II Contents ....................i Preface....................iii Copyright Notice ..................iii Declaration of Conformity ...............iii CE ....................iii FCC Class A ..................iii RoHS ....................iv SVHC / REACH ................iv Important Safety Instructions ..............v Warning ....................vi Lithium Battery Replacement ..............vi Technical Support ..................

  • Page 4: Contents

    Contents 4.4. Mount the Computer ..............47 4.4.1 VESA Mounting ..............47 4.4.2 Panel Mounting ..............47 Chapter 5 - BIOS ................51 5.1. Main ....................54 5.2. Advanced ..................56 5.2.1. Boot Configuration ............... 57 5.2.2. PCI Express Configuration ..........57 5.2.3. USB Configuration ............... 57 5.2.4. LPSS & SCC Configuration ..........58 5.2.5. Video Configuration .............

  • Page 5: Preface

    Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 6: Rohs

    (PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed...

  • Page 7: Important Safety Instructions

    Preface Important Safety Instructions Read these safety instructions carefully 1. Read all cautions and warnings on the equipment. 2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage 3. Make sure the correct voltage is connected to the equipment. 4.

  • Page 8: Warning

    Preface Warning The Box PC and its components contain very delicately Integrated Circuits (IC). To protect the Box PC and its components against damage caused by static electricity, you should always follow the precautions below when handling it: 1. Disconnect your Box PC from the power source when you want to work on the inside.

  • Page 9: Warranty

    Preface Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
  • Page 10 This page is intentionally left blank. - viii -...

  • Page 11: Chapter 1 - Introduction

    Chapter 1 Introduction Chapter 1 - Introduction - 1 -...

  • Page 12: The Computer

    Introduction 1.1. The Computer Product Highlights • High Resolution LCD Display w/ LED Backlight • Flat panel with projected capacitive touchscreen • Front panel compliant with IP65 • Anti-scratch surface: 7H hardness • Slim and Compact Design • Mini PCIe expansion slot support • Fanless cooling system • Cable-less Design • Low power consumption...

  • Page 13: Specifications

    Introduction 1.3. Specifications System Intel® N2930 Quad-Core™ Processor 1.83GHz 2GB DDR3L SO-DIMM RAM module installed Memory 1 x DDR3L SO-DIMM Socket, supporting 1600MHz SDRAM up to 8GB 2 x Intel® I210AT GbE controllers Watchdog Timer 1~255 levels reset Storage 1 x mSATA for SATA interface SSD Device Supports 300MB/s HDD transfer rate Audio...
  • Page 14 Introduction External I/O 1 x Type-A USB 3.0 port USB Ports 1 x Type-A USB 2.0 port 2 x RJ-45 GbE ports 1 x DVI-I connector WiFi 1 x SMA antenna hole for optional WiFi function Mechanical Mounting Type VESA-75 / 100 mounting and panel mounting with bracket Chassis Aluminum front bezel and SECC steel chassis ASLAN-W810C: 255.00 x 175.0.

  • Page 15: Inside The Package

    1 x Accessory Box that contains the following items: • User’s manual • Screws/cable 1.5. Ordering Information 10.1” Intel® N2930 Quad-Core™ Processor ASLAN-W810C-2930G2 industrial panel PC with 2GB Memory 11.6” Intel® N2930 Quad-Core™ Processor ASLAN-W812C-2930G2 industrial panel PC with 2GB Memory - 5 -...
  • Page 16 This page is intentionally left blank. - 6 -...

  • Page 17: Chapter 2 - Getting Started

    Chapter 2 Getting Started Chapter 2 - Getting Started - 7 -...

  • Page 18: Dimensions

    Getting Started 2.1. Dimensions The following illustration shows the dimensions of the computer. ASLAN-W810C 228.00(CUT OUT) 255.00 100.00 75.00 Unit:mm ASLAN-W812C 270.00(CUT OUT) 100.00 306.00 75.00 Unit:mm - 8 -...

  • Page 19: Tour The Computer

    Getting Started 2.2. Tour the Computer Take a look around the computer and find the external controls and connectors. 2.2.1. Front View ASLAN-W810C ASLAN-W812C - 9 -...

  • Page 20: Rear View

    Getting Started 2.2.2. Rear View ASLAN-W810C ASLAN-W812C - 10 -...

  • Page 21: Driver Installation Note

    Getting Started 2.3. Driver Installation Note The computer supports the operating system Windows 7. To install the drivers, please go to our website at www.arbor-technology.com and download the driver pack from the product page.: Windows 7 Device Driver Path Chipset \Chipset\SetupChipset.exe 32Bit: \LAN\Win7\PROWin32.exe Ethernet...
  • Page 22 This page is intentionally left blank. - 12 -...

  • Page 23: Chapter 3 - Engine Of The Computer

    Chapter 3 Engine of the Computer Chapter 3 - Engine of the Computer - 13 -...

  • Page 24: Board Layout

    Engine of the Computer 3.1. Board Layout 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 14 -...

  • Page 25: Jumpers And Connectors

    Engine of the Computer 3.2. Jumpers and Connectors This chapter will explicate each of the jumpers and connectors on the carrier board of the computer. 3.2.1. Jumpers JPIC1 Function: Sets the AT/ATX mode Jumper Type: 2.00mm pitch 2x3-pin header Setting: Description 2-4 AT mode 4-6 ATX mode (default)
  • Page 26 Engine of the Computer JBAT1 Function: Clears/keeps CMOS Jumper Type: 2.00 mm pitch 1x2-pin header Setting: Description Short Clears CMOS Open Keeps CMOS (default) Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 16 -...
  • Page 27 Engine of the Computer JVLCD1 Function: Sets LCD panel voltage Jumper Type: 2.00mm pitch, 1x3-pin header Setting: Description +3.3V (default) Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 17 -...
  • Page 28 Engine of the Computer JINV1 Function: Sets backlight voltage Jumper Type: 2.00mm pitch, 1x3-pin header Setting: Description +12V(default) Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 18 -...

  • Page 29: Connectors

    Engine of the Computer 3.2.2. Connectors INV1 Description: LCD Inverter Connector Connector Type: 1.25mm 1x6-pin box connector Setting: Description INV_VDD 3460_BKLT_EN 3460_BKLT_CTRL Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 19 -...
  • Page 30 Engine of the Computer BTN2 Description: Power Button Connector Type: Onboard 2-pin header Setting: Description EXT_BTN- Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 20 -...
  • Page 31 Engine of the Computer BTN3 Description: Reset Button Connector Type: Onboard 2-pin header Setting: Description RSTBTN# Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 21 -...
  • Page 32 Engine of the Computer LVDS1 Description: Connector for LCD panel. Connector Type: DF-13-30DP-1.25V connector Setting: Pin Description Pin Description LVDS1_VDD LVDS1_VDD LVDS_B_CLK+ LVDS_A_CLK+ LVDS_B_CLK- LVDS_A_CLK-- 10 LVDS_B0+ LVDS_A0+ 12 LVDS_B0- 11 LVDS_A0- 14 GND 13 GND 16 LVDS_B1+ 15 LVDS_A1+ 18 LVDS_B1- 17 LVDS_A1- 20 GND...
  • Page 33 Engine of the Computer SATA1 Description: Serial ATA connector Connector Type: Onboard 9-pin header Setting: Description SATA_TXP1 SATA_TXN1 SATA_RXN1 SATA_RXP1 Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 23 -...
  • Page 34 Engine of the Computer LAN1&2 Function: Ethernet connectors Connector Type: RJ-45 connector that supports 10/100/1000Mbps fast Ethernet Pin Assignment: The pin assignments conform to the industry standard. Bottom Panel ASLAN-W810C ASLAN-W812C - 24 -...
  • Page 35 Engine of the Computer DVI1 Function: DVI-I connector Connector Type: 29-pin DIP-type female connector Pin Assignment: The pin assignments conform to the industry standard. Bottom Panel ASLAN-W810C ASLAN-W812C - 25 -...
  • Page 36 Engine of the Computer USB2 Destription: Connectors for the internal USB ports Connector Type: Pitch 2.00mm 5-pin wafer connectors Pin Assignment: Desc. VCCUSB1 USBLN0 USBLP0 Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 26 -...
  • Page 37 Engine of the Computer PWR1 Destription: Connectors for DC-in power. Connector Type: Onboard 4-pin one-wall wafer connector Pin Assignment: Description DC12V DC12V C-GND C-GND Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 27 -...
  • Page 38 Engine of the Computer PWROUT1 Destription: Connectors for SATA power. Connector Type: Onboard 4-pin one-wall wafer connector Pin Assignment: Description 12VS Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 28 -...
  • Page 39 Engine of the Computer PWBT1 Destription: Power Button Connector Type: LED tact switch with green and red colors Pin Description Description SW1_LED_N SW1_LED_P Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 Top Panel ASLAN-W810C ASLAN-W812C - 29 -...
  • Page 40 Engine of the Computer MIC1 Destription: Mic-in Port Connector Type: Pink 3.5mm audio jack Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 Top Panel ASLAN-W810C ASLAN-W812C - 30 -...
  • Page 41 Engine of the Computer LOUT1 Destription: Line-out Port Connector Type: Lime green 3.5mm audio jack Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 Top Panel ASLAN-W810C ASLAN-W812C - 31 -...
  • Page 42 Engine of the Computer USB3 Function: USB 3.0 connector Connector Type: USB 3.0/2.0 type-A connectors Pin Assignment: 1 2 3 4 The pin assignments conform to the industry standard. Top Panel ASLAN-W810C ASLAN-W812C - 32 -...
  • Page 43 Engine of the Computer USB1 Function: USB 2.0 connectors Connector Type: USB 2.0/1.0 type-A connectors Pin Assignment: The pin assignments conform to the industry standard. Top Panel ASLAN-W810C ASLAN-W812C - 33 -...
  • Page 44 Engine of the Computer Description: Mini-card Full Size socket Connector Type: Onboard 0.8mm pitch 52-pin edge card connector Pin Assignment: The pin assignments conform to the industry standard. Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 34 -...
  • Page 45 Engine of the Computer Function: mSATA socket Connector Type: Onboard 0.8mm pitch 52-pin edge card connector Pin Assignment: 51 52 The pin assignments conform to the industry standard. Board Top 17 15 USB1 USB3 LOUT1 MIC1 PWROUT1 BAT1 INV1 JVLCD1 SATA1 JINV1 - 35 -...
  • Page 46 Engine of the Computer Function: Mini-card half-size socket Connector Type: Onboard 0.8mm-pitch 52-pin edge card connector Pin Assignment: Pin Desc. Pin Desc. 3.3AUX 21 GND 3.3AUX 22 BUF_PLT_RST# COEX1 23 PCIE_RXN3 24 3.3AUX Reserved 25 PCIE_RXP3 1.5VS_MINI 26 GND 3.3AUX 27 GND Reserved 28 1.5VS_MINI...

  • Page 47: Chapter 4 - Installation And Maintenance

    Chapter 4 Installation & Maintenance Chapter 4 - Installation and Maintenance - 37 -...

  • Page 48: Access The Inside Of The Computer

    Installation & Maintenance 4.1. Access the Inside of the Computer To use onboard jumpers/connectors or to install/remove internal hardware, you will need to open the system to access the main board of the computer. The installations of ASLAN-W810C and ASLAN-W812C are similar and the following descriptions will use ASLAN-W810C as example.
  • Page 49 Installation & Maintenance 3. Loosen and remove the eight screws securing the metal plate and the case. Then remove the metal plate. 4. The inside of the computer comes to view. Then you can make connections or configure jumper settings as required. Memory module socket mSATA module socket Mini card socket - 39 -...

  • Page 50: Reassemble The Computer

    Installation & Maintenance 4.1.2. Reassemble the Computer After you make required jumper settings and connections, follow through the guide below to reassemble the computer. 1. Orientate the metal plate as shown below to ensure the LVDS connectors are accessible. Fasten the metal plate to the case by screwing the eight screws.

  • Page 51: Use Onboard Jumpers And Connectors

    Installation & Maintenance 3. Turn over the case and fasten the six screws securing the LCD panel assembly and the case. 4.2. Use Onboard Jumpers and Connectors The computer’s main board comes with some connectors to connect devices and also some jumpers to alter hardware configuration. To access the jumpers and connectors, follow through the guide as described in 4.1.1.

  • Page 52: Install Hardware

    Installation & Maintenance 4.3. Install Hardware The following sections will guide you through the basic hardware installation for the computer. Remember to turn off the panel PC before installing/removing inner hardware. 4.3.1. Install mSATA Storage To install an mSATA storage module to the computer: 1.

  • Page 53: Install Memory Module

    Installation & Maintenance 4. Press down the end of the mSATA card and then fix the card in place using two screws. Secure with two screws Press down the card 5. After you compete the installation, re-assembly the computer as described 4.1.2. Reassemble the Computer on page 40. 4.3.2. Install Memory Module The main board has one dual inline memory module (DIMM) socket. Load the computer with a memory module to make the computer run programs.
  • Page 54 Installation & Maintenance To install a memory module: The computer is pre-installed with a memory module. In case you need to replace or upgrade the module, follow the steps below: 1. Access the inside of the computer as described in 4.1.1.
  • Page 55 Installation & Maintenance By a slanted angle, fully insert the memory module until it cannot be inserted any more. 5. Press down the memory module until it is auto-locked in place. 6. After you compete the installation, reassembly the computer as described in 4.1.2.

  • Page 56: Install Wi-Fi Module

    Installation & Maintenance 4.3.3. Install Wi-Fi Module The computer comes with one Mini-card socket to load the computer with a wireless module of PCI Express Mini-card form factor: • To install the Wi-Fi module, see Appendix A: Wi-Fi Module Hardware Installation.

  • Page 57: Mount The Computer

    Installation & Maintenance 4.4. Mount the Computer 4.4.1 VESA Mounting The computer supports 75mm and 100mm VESA mount so you can attach the computer to a VESA mount kit. The installtions of ASLAN-W810C and ASLAN- W812C are similar and the following descriptions will use ASLAN-W810C as example.
  • Page 58 Installation & Maintenance 1. Loosen and remove the 6 screws as shown below. 2. Using the screws you removed in step 1, secure the mounting brackets to the rear cover by fastening the 4 screws. 3. Put the panel PC into correct-sized opening on a panel or other fixture. - 48 -...
  • Page 59 Installation & Maintenance 4. Attach the provided panel-mounting clamps to the holes of the brackets. 5. Tightly fasten the screw of each clamp to secure the panel PC to the panel. - 49 -...
  • Page 60 This page is intentionally left blank. - 50 -...

  • Page 61: Chapter 5 - Bios

    Installation & Maintenance Chapter 5 BIOS Chapter 5 - BIOS - 51 -...
  • Page 62 BIOS The BIOS Setup utility for the computer is featured by Insyde Software to ® configure the system settings stored in the system’s BIOS ROM. The BIOS is activated once the computer powers on. When the computer is off, the battery on the main board supplies power to BIOS RAM. The BIOS of ASLAN-W810C and ASLAN-W812C are similar and the following descriptions will use ASLAN- W810C as example.
  • Page 63 BIOS Key Commands The BIOS Setup utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and configure the utility. Keystroke Function ← → Moves left/right between the top menus. ↓ ↑ Moves up/down between highlight items. Enter Selects an highlighted item/field. On the top menus: Use Esc to quit the utility without saving changes to CMOS.

  • Page 64: Main

    BIOS 5.1. Main The Main menu features the settings of System Date and System Time and displays some BIOS info and system info. InsydeH20 Setup Utility Rev. 5.0 Advanced Security Power Boot Exit Main Select the current default language InsydeH20 Version ASLAN-W810C R1.00 used by the InsydeH20.
  • Page 65 BIOS Channel A Displays the memory installed on the Channel A SODIMM. Channel B Displays the memory installed on the Channel B SODIMM. Platform firmware Displays the platform firmware Information. Information The featured settings are: Setting Description Language Sets the language used by the BIOS. System Time Sets system time.

  • Page 66: Advanced

    BIOS 5.2. Advanced Access the Advanced menu to manage the computer’s system configuration. InsydeH20 Setup Utility Rev. 5.0 Advanced Security Power Boot Exit Main Configures Boot Settings. Boot Configuration PCI Express Configuration USB Configuration LPSS & SCC Configuration Video Configuration SATA Configuration LM90 Thermal Sensor Help Select Item F5/F6 Change Values Setup Defaults...

  • Page 67: Boot Configuration

    BIOS 5.2.1. Boot Configuration Setting Description Numlock Select Power-on state for Num lock. 5.2.2. PCI Express Configuration Configures PCI Express by the following settings: Setting Description PCI Express Root Port Enables/disables this PCIe port. PCIe Port Speed Options are: Auto (default), Gen 1, Gen 2 PCIe Port ASPM Support PCI Express Root Automatically enable ASPM based on reported capabilities and Port...

  • Page 68: Lpss & Scc Configuration

    BIOS 5.2.4. LPSS & SCC Configuration Setting Description LPSS & SCC Devices Sets LPSS & SCC Devices as ACPI or PCI mode. Mode Sets the OS. Options are Windows (default) /Android. OS Selection Do not select Android as it is not supported by ASLAN-W810/812C. 5.2.5.

  • Page 69: Sata Configuration

    BIOS 5.2.5.3 PTN3460 (eDP to LVDS) Configuration Setting Description Set the Output Format of PTN3460. PTN3460 Output Options are (00) VESA (24bpp) / (01) VESA or JEIDA (18bpp) / (10) Format JEIDA (24bpp) / (11) JEIDA (24bpp) PTN3460 Channel Sets the Channel mode of PTN3460. Control Options are Single/Dual PTN3460 EDID Table...

  • Page 70: Lm90 Thermal Sensor

    BIOS 5.2.7. LM90 Thermal Sensor Displays the LM90 thermal sensor information. Setting Description Local Displays Local Temperature Temperature Remote Displays Remote Temperature Temperature Thermal Status Display Thermal Status - 60 -...

  • Page 71: Security

    BIOS 5.3. Security The Security menu sets up the password for the system’s supervisor account. Once the supervisor password is set up, this BIOS Setup utility is limited to access and will ask for the password each time any access is attempted. InsydeH20 Setup Utility Rev.

  • Page 72: Power

    BIOS 5.4. Power The Power menu sets up the power option of system. InsydeH20 Setup Utility Rev. 5.0 Advanced Security Power Boot Exit Main Determines the action taken when the system power is off Wake on PME <Enabled> Power on after Power Fail <Enabled>...

  • Page 73: Boot

    BIOS 5.5. Boot The Boot menu configures how to boot up the system such as the configuration of boot device priority. InsydeH20 Setup Utility Rev. 5.0 Advanced Security Power Boot Exit Main Select boot type to Dual type. Boot Type <Dual Boot Type> Legacy type or UEFI type Network Stack <Disabled> PXE Boot capability <Disabled>...
  • Page 74 BIOS Legacy Sets boot device priority. Selects Normal Boot Option Priority or Advance Boot Option Priority. Normal Boot Menu Boot Type Order Changes boot type order. Hard Disk Drive Changes CD/DVD-ROM drive boot order. - 64 -...

  • Page 75: Exit

    BIOS 5.6. Exit The Exit menu features a handful of commands to launch actions from the BIOS Setup utility regarding saving changes, quitting the utility and recovering defaults. InsydeH20 Setup Utility Rev. 5.0 Advanced Security Power Boot Exit Main Exit Saving Changes Exit system setup and save Exit Discarding Changes your changes.
  • Page 76 This page is intentionally left blank. - 66 -...

  • Page 77: Appendices

    Appendices Appendices - 67 -...

  • Page 78: Appendix A: Wi-Fi Module Hardware Installation

    Appendices Appendix A: Wi-Fi Module Hardware Installation To use Wi-Fi, hardware-wise the computer needs a Wi-Fi module installed, and software-wise the computer needs the device driver and an application program. This appendix will guide you to install the Wi-Fi module and the device driver. 1.
  • Page 79 Appendices 4. Connect the antenna cable’s connector to the connector on the mini-card labeled “CH1”. CH1 connector Align the Wi-Fi module with the socket; notches of the Wi-Fi module must match the socket keys for a correct installation. Align the notch on the Wi-Fi module with the notch in the mini-card socket.
  • Page 80 Appendices 7. Press down the end of the Wi-Fi mini-card and then fix the card in place using two screws. Secure with two screws 8. Thread the SMA end of antenna cable through the ANT hole. Note that the SMA connector comes in the form of a threaded bolt, with one flat side. Make sure to align the connector’s flat side with the hole’s flat side. Flat side of the connector 9.
  • Page 81 Appendices 10. Restore the mSATA module as described in 4.3.1. Install mSATA Storage on page 42. 11. Reassembly the compuer as described in 4.1.2. Reassemble the Computer on page 40. 12. Prepare the external antenna. Screw and tightly fasten the antenna to the SMA connector.
