- Page 1 SB-244-1J64 Industrial Fanless PC w/Intel Elkhart Lake ® Celeron J6412 Processor User’s Manual Version 1.0 2024.07...
- Page 2 Revision History Version Date Description 2024.07 Initial release - II -...
-
Page 3: Table Of Contents
Contents Contents Revision History ................II Contents ....................i Preface....................iii Copyright Notice ..................iii Declaration of Conformity ...............iii CE ....................iii FCC Class A ..................iii RoHS ....................iv SVHC / REACH ................iv Important Safety Instructions ..............v Warning ....................vi Lithium Battery Replacement ..............vi Technical Support .................. -
Page 4: Contents
Contents 3.3. Install/Remove HDD ..............26 3.4. Install/Remove WIFI / 4G module and SIM card ......27 Chapter 5 - BIOS ................29 4.1. Main - Sets system Time & Date............ 32 4.2. Advanced ..................33 4.2.1. Turbo Mode Setting ............. 34 4.2.2. -
Page 5: Preface
Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages. -
Page 6: Rohs
(PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed... -
Page 7: Important Safety Instructions
Preface Important Safety Instructions Read these safety instructions carefully 1. Read all cautions and warnings on the equipment. 2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage 3. Make sure the correct voltage is connected to the equipment. 4. -
Page 8: Warning
Preface Warning The Box PC and its components contain very delicately Integrated Circuits (IC). To protect the Box PC and its components against damage caused by static electricity, you should always follow the precautions below when handling it: 1. Disconnect your Box PC from the power source when you want to work on the inside. -
Page 9: Warranty
Preface Warranty This product is warranted to be in good working order for a period of two year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms. - Page 10 This page is intentionally left blank. - viii -...
-
Page 11: Chapter 1 - Introduction
Chapter 1 Introduction Chapter 1 - Introduction - 1 -... -
Page 12: Features
Introduction 1.1. Features Intel Celeron J6412 CPU Elkhart Lake(2.0 GHz/2.6GHz) • ® ® 1 x SDRAM DDR4 3200 MHz (max. 32G) • Support 4 Gigabit LAN • Support DP/HDMI video output • • Support SATA/M.2 SSD, M.2 WiFi, Mini-PCIe 1.2. About this Manual This manual is meant for the experienced users and integrators with hardware knowledge of personal computers. -
Page 13: Specifications
Introduction 1.3. Specifications System ® ® Intel Celeron J6412 CPU Elkhart Lake (2.0 GHz/2.6GHz) 1 x SDRAM DDR4 3200 MHz SO-SIMM slot (max. 32G) Memory 4GB DDR4 SO-DIMM pre-installed*(CTOS) Graphics Intel UHD Graphics for 10 Gen Intel Processors ® ® 1 x Intel I210AT GbE controller LAN Chipset 3 x Intel I226-V 2.5GbE controllers... - Page 14 Introduction Internal I/O 1 x Mini-PCIe slot (PCIe/ USB2.0 signal supported) 1 x E-Key M.2 2230 slot (PCIe/USB2.0 signal supported) Expansion Slot 1 x M.2 2242 SSD slot(SATA signal supported) 1 x SIM Card socket for 3G/4G module SIM Card Mechanical Button 1 x Power button...
-
Page 15: Inside The Package
1.4. Inside the Package Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: 1 x SB-244-1J64 • User’s manual •... - Page 16 This page is intentionally left blank. - 6 -...
-
Page 17: Chapter 2 - Getting Started
Chapter 2 Getting Started Chapter 2 - Getting Started - 7 -... -
Page 18: Dimensions
Getting Started 2.1. Dimensions - 8 -... -
Page 19: Overview
Getting Started 2.2. Overview 2.2.1. Front and Rear side View Front Side Connector List Item Item DC-IN Power button LAN3/4 USB2.0 LAN1/2 COM1 HDMI COM2 COM3 USB2.0 COM4 USB3.0 Audio - 9 -... -
Page 20: Dc-In Power Input
Getting Started 2.2.2. DC-IN Power Input Pin Definition Pin Definition +12~24V 2.2.3. HDMI/DP Output Figure 2.2.3-1 HDMI / DP Connector - 10 -... -
Page 21: Serial Port Connector(Com1, Com2)
Getting Started 2.2.4. Serial Port Connector(COM1, COM2) COM1, COM2 Function: RS-232/422/485 Selectable Serial Port Connector Type: External 9-pin D-sub male connector Pin Assignment: Pin Desc. Pin Desc RS-232 RS-422 Data- RS-485 Data+ Note: COM1/2 support RS232/422/485. 2.2.5. USB Port Function: USB 3.1/3.0/2.0 Stacked Connectors Connector Type: USB 3.0/2.0 type A connectors Pin Assignment:... -
Page 22: Lan Port
Getting Started 2.2.6. LAN Port Function: RJ-45 port for Giga Lan Connector Type: 4 x RJ-45 connectors that support 10/100/1000Mbps fast Ethernet Pin Assignment: The pin assignments conform to the industry standard. LED Indicators Indicator Function Status Off: not working Networking Status Green: Working Off: 10Mbps... -
Page 23: Antenna Hole
Getting Started 2.2.9. Antenna Hole There are 2 antenna reserved holes on the rear panel of the product to facilitate users to install the antenna of the wireless module. 2.2.10. 8DI-8DO DO Ports Definition Item Description DO_GND External power supply(-) Export with isolated 8 Export with isolated 7 Export with isolated 6... - Page 24 Getting Started DI Ports Definition Item Description DI_COM Import with isolated Import with isolated 8 Import with isolated 7 Import with isolated 6 Import with isolated 5 Import with isolated 4 Import with isolated 3 Import with isolated 2 Import with isolated 1 2.2.10.1.
- Page 25 Getting Started 2.2.10.3. Input PNP wiring method Features: PNP type device is connected to IO input, DI_COM is connected to GND of NPN type sensor, signal line is connected to DI (1-8), and resistor is PULL DOWN resistor on signal line according to sensor requirements. - 15 -...
- Page 26 Getting Started 2.2.10.4. Output Loading Method Features: Designed to meet the power supply range of DC 5-24V, current driving capacity of each channel 100mA, programmable switching between NPN and PNP outputs, with reverse connection protection function. The wiring methods for connecting to loads (such as relays, LED lights, motors, etc.) and PLCs are shown below.
- Page 27 Getting Started Note: 1. If you need to connect an inductive load, please make sure there is a reverse discharge diode to prevent the reverse electromotive force from breaking down the internal parts. 2.2.10.7. Export PLC wiring method PNP PLC characteristics: VCC connects to EXT, DO_GND connects to PLC GND, and PLC input connects to DO1-8.
-
Page 28: Internal Connector / Jumper
Getting Started NPN PLC characteristics: PLC VCC connects to EXT, DO_GND connects to PLC GND, and PLC input connects to DO1-8. 2.3. Internal Connector / Jumper - 18 -... -
Page 29: Clear Cmos
Getting Started Pin Definition Printing M.2_2230 M.2 2230 M.2_SSD M.2 2242 MINIPCIE1 Mini-PCIe Wi-Fi/4G module/CAN bus JSIM1 3G/4G SIM slot DIMM1 DDR4 SO-DIMM slot JPWR1 12-24 DC IN ATX_AT AT/ATX selection mode Function Reset, LED, Power Button Pin Head JFP1 COM Port GPIO_V GPIO voltage jumper... -
Page 30: Jfp1 Pin Definition(Pin 2.0)
Getting Started 2.3.3. JFP1 Pin definition(PIN 2.0) Description Description PWR_SW HWRST_N PWR_LED- SATA_LED- PWR_LED+ SATA_LED+ 2.3.4. JGPIO Jump JGPIO Jump JGPIO Definition Pin Definition Printing GPIO_DUAL GPIO_DUAL JGPIO8 JGPIO1 JGPIO7 JGPIO2 JGPIO6 JGPIO3 JGPIO5 JGPIO4 Note: Default setting is 3.3V, users is able to set to 5V. - 20 -... - Page 31 Getting Started Follow the table as below for the GPIO setting GPIO Memory GPO High GPO Low GPI Setting GPO Setting Address Voltage Voltage Bit 8=1 Bit 8=0 JGPIO1 0xFD6D0980 Bit 0=1 Bit 0=0 Bit 9=0 Bit 9=1 Bit 8=1 Bit 8=0 JGPIO2 0xFD6D0990 Bit 0=1...
- Page 32 Getting Started 0x44000200 represents GPO1 Low • 03 position 44 represents GPIO voltage is 3.3V, 84 represents GPIO • voltage is 5.0V 01 position 02 represents the GPIO pin is GPO state • 01 position 01 represents the pin of GPIO is GPI state, GPI can only read, •...
- Page 33 This page is intentionally left blank. - 23 -...
-
Page 34: Chapter 3 - Engine Of The Computer
Chapter 3 Installation & Maintenance Chapter 3 - Engine of the Computer - 24 -... -
Page 35: Installation And Maintenance
Installation & Maintenance 3.1. Installation and Maintenance 1. Remove 6 screws from the bottom cover, as shown as below. - 25 -... -
Page 36: Install M.2 2242 Storage/Thermal Pad
Installation & Maintenance 3.2. Install M.2 2242 Storage/Thermal Pad 1. Remove 7 screws on the bottom cover from the computer as described in 3.1-1 2. Install/Remove the storage from the slot and attach the thermal pad to the storage. 3. Attach the accessory hexagonal studs to the screw holes, insert/remove the storage. -
Page 37: Install/Remove Hdd
Installation & Maintenance 3.3. Install/Remove HDD 1. Remove six M3x4 screws and the bottom cover; 2. Place the HDD and bracket in the direction as shown in the figure, and secure them with four I-head M3*4 screws on the sides; 3. -
Page 38: Install/Remove Wifi / 4G Module And Sim Card
Installation & Maintenance 3.4. Install/Remove WIFI / 4G module and SIM card 1. Insert/remove the SIM card into the SIM card slo 2. Insert the MINI-PCIE interface into the /WIFI/CAN card/4G module and lock it with L-head M2*3 screws; 3. Fix the 6-corner studs of the accessory on the screw hole, connect the 2230 wireless network card to the M.2 2230 interface, and after installing the M.2 2242 SSD, tighten it with P-head M3*6 screws. - Page 39 This page is intentionally left blank. - 29 -...
-
Page 40: Chapter 5 - Bios
Chapter 4 BIOS Chapter 5 - BIOS - 30 -... - Page 41 BIOS The BIOS Setup utility is featured by American Megatrends Inc to configure the system settings stored in the system’s BIOS ROM. The BIOS is activated once the computer powers on. When the computer is off, the battery on the main board supplies power to BIOS RAM.
- Page 42 BIOS Key Commands The BIOS Setup utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and use the utility. Keystroke Function Enter the BIOS Setup menu After System Open Enter the boot up sequence menu Ctrl + Alt + DEL Restart the system ←...
-
Page 43: Main - Sets System Time & Date
BIOS 4.1. Main - Sets system Time & Date. The Main menu features the settings of System Date and System Time and displays some BIOS info. Note: Actual model name and board information varies according to your model. Setting Description System Date Sets system date. -
Page 44: Advanced
BIOS 4.2. Advanced - 34 -... -
Page 45: Turbo Mode Setting
BIOS 4.2.1. Turbo Mode Setting Enter Advanced menu, select "Power & Performance" -> "CPU-Power Mangement Control" -> "Turbo Mode". After that users can choose Enabled/ Disabled. After setting, press F4 to save and exit, the system will take effect after reboot. -
Page 46: Com Mode Setting
BIOS 4.2.2. COM Mode Setting - 36 -... - Page 47 BIOS Enter the Advanced menu, select IT8786 Super IO Configuration->Serial Port X Configuration->COM Mode Select, you can choose RS232, RS422, RS485 to set the COM mode. After the setting is completed, press F4 to save and exit. The setting will take effect after the system restarts. - 37 -...
-
Page 48: Usb Power Setting In Power Off / Hibernation Mode
BIOS 4.3 USB Power Setting in Power Off / Hibernation Mode Select "Chipset" menu->"PCH-IO Configuration"-> "USB Power in S5" in order. Users can set the USB power in S5 according to the actual application's requirements and select High or Low to turn it on or off. After setting, press F4 to save and exit, the system will take effect after reboot. -
Page 49: Gpio Setting
BIOS 4.4. GPIO Setting Select "Chipset" -> "PCH-IO Configuration", and select "Enable". Users can set a single GPIO pin as "GPI" or "GPO-High" or "GPO-Low". After setting, press F4 to save and exit, the system will take effect after reboot. - 39 -... -
Page 50: Auto Turn-On (At/Atx)
BIOS 4.5. Auto TURN-ON (AT/ATX) Enter "Chipset" menu, and select "Chipset"->"PCH-IO Configuration"->"State After G3" in order. Users can select "S0 State/S5 State" for power mode on the system. "S0 State" is AT mode, it will power on the system automatically after connecting the power supply, and S5 State is ATX mode.Users need to press the power button to turn on the system after connecting the power supply. -
Page 51: Security
BIOS 4.6. Security Setting Description To set up an administrator password: Select Administrator Password. An Create New Password dialog then pops up Adminstration Password onscreen. Enter your desired password that is no less than 3 characters and no more than 20 characters. Hit [Enter] key to submit. -
Page 52: Boot
BIOS 4.7. Boot "Boot" menu contains the boot settings above. Users can set the boot logo or select the bootup devices, etc. - 42 -... -
Page 53: Setting The Boot Logo
BIOS 4.8. Setting the Boot Logo Enter the Boot menu, select Quiet Boot, and then press F4 to save and exit, the system will take effect after reboot. Setting Description Enabled: Logo will be displayed at boot up. ► Quiet Boot Disabled: Boot up the system and display the self-test screen, no logo, ►... -
Page 54: Setting Boot Option Priority
BIOS 4.9. Setting Boot Option Priority Set the system boot priorities. Enter Boot menu. In "Boot Option Priorities", users can set the order of boot devices. Boot Option #1 is the first priority boot item, Boot Option #2 is the second boot item, and so on. -
Page 55: Save & Exit
BIOS 4.10. Save & Exit The Save & Exit menu displays the way to exit the BIOS setup utility. When users have completed the setup, users must save and exit for the changes to take effect. Setting Description Save Changes Saves the changes and quits the BIOS Setup utility.
