Arbor Technology FPC-7600 Series User Manual

Robust box pc with 3rd generation intel core i5/i3 or celeron processor platform
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FPC-7600 Series
Robust Box PC with 3
Generation Intel
rd
®
Core™ i5/i3 or Celeron
Processor Platform
®
User's Manual
Version 1.2
2017.01
P/N: 4012760000120P
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FPC-7600 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Arbor Technology FPC-7600 Series

Summary of Contents for Arbor Technology FPC-7600 Series

  • Page 1 FPC-7600 Series Robust Box PC with 3 Generation Intel ® Core™ i5/i3 or Celeron Processor Platform ® User’s Manual Version 1.2 2017.01 P/N: 4012760000120P...
  • Page 2 This page is intentionally left blank. - 2 -...
  • Page 3 Revision History Version Release Time Description 2015 August Initial release 2015 October Add FPC-7600 model 2017 January Add "Windows 10" to OS support & driver path - i -...

  • Page 4: Table Of Contents

    Contents Contents Revision History ................i Contents ..................ii Preface.................... v Copyright Notice.................. v Declaration of Conformity..............v CE ....................v FCC Class A ................v RoHS ...................vi SVHC / REACH ................vi Important Safety Instructions .............vii Warning .....................viii Replacing Lithium Battery ..............viii Technical Support................viii Warranty ....................ix Chapter 1 - Introduction ..............

  • Page 5: Contents

    Contents 4.1.3. Install CPU ..............52 4.1.4. Install SATA Storage Devices .......... 53 4.1.5. Install PCI and PCI Express Cards ......... 56 4.1.6. Install Wireless Modules ..........58 4.2. Mount the Computer ..............59 4.3. Ground the Computer ..............60 4.4.
  • Page 6 This page is intentionally left blank. - iv -...

  • Page 7: Preface

    Preface Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such...

  • Page 8: Rohs

    (PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed...

  • Page 9: Important Safety Instructions

    Preface Important Safety Instructions Read these safety instructions carefully Read all cautions and warnings on the equipment. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage Make sure the correct voltage is connected to the equipment. For pluggable equipment, the socket outlet should be near the equipment and should be easily accessible.

  • Page 10: Warning

    Preface Warning The Box PC and its components contain very delicately Integrated Circuits (IC). To protect the Box PC and its components against damage caused by static electricity, you should always follow the precautions below when handling it: Disconnect your Box PC from the power source when you want to work on the inside.

  • Page 11: Warranty

    Preface Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
  • Page 12 This page is intentionally left blank. - x -...

  • Page 13: Chapter 1 - Introduction

    Chapter 1 Introduction Chapter 1 - Introduction - 1 -...

  • Page 14: The Computer

    Introduction 1.1. The Computer • Fanless Design • Wide Range DC Power Input (9~36V) • Triple Independent display (DisplayPort x2 + VGA x 1) supported • Two-mPCIe for Optional WiFi, GPS or I/O Expansion supported • Optional WiFi or HSUPA Wireless Connectivity supported •...

  • Page 15: Specifications

    Introduction 1.3. Specifications System Kernel Generation Intel Core™ i5/i3 or Celeron Processors in ® ® Processor rPGA988 socket, TDP under 35W BIOS AMI UEFI BIOS Chipset Intel HM76 ® Graphics Integrated Intel HD 4000 ® 2 x 204-pin DDR3 SO-DIMM sockets, supporting System Memory 1333/1600MHz SDRAM up to 16GB Serial ATA...

  • Page 16: Inside The Package

    Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: FPC-7600 1 x FPC-7600 Series Robust System FPC-7601/7602/7603 FPC-7604 1 x Driver CD 1 x User’s Manual...

  • Page 17: Ordering Information

    Introduction 1.5. Ordering Information FPC-7600 Fanless system w/o expansion FPC-7601 Fanless system w/ 1 x PCI and 1 x PCIe x16 FPC-7602 Fanless system w/ 1 x PCIe x8 and 1 x PCIe x16 FPC-7603 Fanless system w/ 2 x PCI FPC-7604 Fanless system w/ 1 x PCIe x16 1.5.1.

  • Page 18: Configure-To-Order Service

    Introduction 1.5.2. Configure-to-Order Service Make the computer more tailored to your needs by selecting one or more components from the list below to be fabricated to the computer. 80GB SSD Intel 2.5” 80GB SATAIII SSD kit ® WIFI-AT2300 Atheros AR9462 Wi-Fi module w/ 20cm internal wiring ANT-D11 1 x Wi-Fi Dual-band 2.4G/5G antenna Generation Intel...

  • Page 19: Chapter 2 - System Overview

    Chapter 2 System Overview Chapter 2 - System Overview - 7 -...

  • Page 20: Dimensions

    System Overview 2.1. Dimensions The following illustration shows the dimensions of each FPC-7601/7602/7603 and FPC-7604, with the measurements in width, depth, and height called out. 2.1.1. FPC-7600 4-UNC#6-32 NUT 194.4 ANT. 1 ANT. 2 Optional Port Optional Port Unit:mm - 8 -...

  • Page 21: Fpc-7601/7602/7603

    System Overview 2.1.2. FPC-7601/7602/7603 Unit:mm - 9 -...

  • Page 22: Fpc-7604

    System Overview 2.1.3. FPC-7604 Unit:mm - 10 -...

  • Page 23: Take A Tour

    System Overview 2.2. Take A Tour The computer has some I/O ports and controls on the front and rear panels. The following illustrations show all the components called out for all FPC-7600 Series. 2.2.1. Front Views • FPC-7600 Front ① ②...
  • Page 24 System Overview • FPC-7601/7602/7603 Front ① ② ③ ⑦ ⑥ ⑤ ④ Description ① LAN ports ② Antenna hole ③ Antenna hole ④ Power button ⑤ Reset toggle ⑥ USB 3.0 ports ⑦ USB 2.0 ports - 12 -...
  • Page 25 System Overview • FPC-7604 Front ① ② ③ ⑦ ⑥ ⑤ ④ Description ① LAN ports ② Antenna hole ③ Antenna hole ④ Power button ⑤ Reset toggle ⑥ USB 3.0 ports ⑦ USB 2.0 ports - 13 -...

  • Page 26: Rear Views

    System Overview 2.2.2. Rear Views Take a look at the rear sides of FPC-7600 Series. • FPC-7600 Rear COM Ports DisplayPorts Line out (Selectable) DC-in Mic in • FPC-7601/7602/7603 Rear COM Ports DisplayPorts Line out (Selectable) Mic in DC-in PCI/PCIe slots...
  • Page 27 System Overview • FPC-7604 Rear COM Ports DisplayPorts Line out (Selectable) DC-in Mic in PCIe Slot - 15 -...

  • Page 28: Driver Installation Notes

    System Overview 2.3. Driver Installation Notes The FPC-7600 Series support the operating systems of Windows 7, Windows 8.1 and Windows 10. For Windows O.S., find the necessary device drivers on the CD that comes with your purchase. For different O.S., the installation of drivers/utilities may vary slightly, but generally they are similar.
  • Page 29 System Overview Windows 10 Driver Path Chipset \Chipset\Windows\v10.0.13\SetupChipset.exe 32Bit \Graphic\WIN10_32bit_V_153343_4425\win32_153343.4425.exe 64Bit \Graphic\WIN10_64bit_V_153343_4425\win64_153343.4425.exe 32Bit \Ethernet\Win32bit\PROWin32.exe 64Bit \Ethernet\Win64bit\PROWin32.exe Audio \AUDIO\Win7_Win8_Win81_Win10_R279.exe - 17 -...
  • Page 30 This page is intentionally left blank. - 18 -...

  • Page 31: Chapter 3 - System Configuration

    Chapter 3 System Configuration Chapter 3 - System Configuration - 19 -...

  • Page 32: Board Layout

    Engine of the Computer 3.1. Board Layout The main board FMB-i76M1 forms the engine of the FPC-7600 Series computers. This section will provide an thorough view of this board. FMB-i76M1: Board Top - 20 -...
  • Page 33 Engine of the Computer FMB-i76M1: Board Bottom - 21 -...

  • Page 34: Jumpers And Connectors

    Engine of the Computer 3.2. Jumpers and Connectors The main board FMB-i76M1 comes with some connectors to join cables to other devices and some jumpers and DIP switches to alter hardware configuration. The following in this chapter will explicate each of the components one-by-one.
  • Page 35 Engine of the Computer JME1 Board Top Function: BIOS Programing MODE Selection Jumper Type: Onboard 2.00mm pitch 1x3-pin header Setting: Description Setting BIOS Programing Disable BIOS Programing Enable (default) - 23 -...
  • Page 36 Engine of the Computer Board Top Function: AT/ATX MODE Selection Jumper Type: Onboard 2.00mm pitch 1x3-pin header Setting: Description Setting (default) - 24 -...
  • Page 37 Engine of the Computer JTERM1 Description: COM3 RS422 & RS485 Terminator Selector Jumper Type: Onboard 2.00mm pitch 2x3-pin header Description RS-485 Normal Mode RS-485 120 ohm Terminal Mode 1-3, RS-422 Normal Mode (default) 3-5, RS-422 120 ohm Terminal Mode JTERM2 Description: COM4 RS422 &...

  • Page 38: Connectors

    Engine of the Computer 3.2.2. Connectors SATA1 & SATA2 Description: Serial ATA connectors for storage devices Connector Type: 7-pin Serial ATA connector Description Board Bottom - 26 -...
  • Page 39 Engine of the Computer PWR1 and PWR2 Description: Power connectors for SATA storage devices Connector Type: 2.54mm-pitch 1x4-pin DIP-type connector Pin Desc. +12V Board Bottom - 27 -...
  • Page 40 Engine of the Computer Description: PCI Express MiniCard socket Connector Type: Onboard 0.8mm pitch 52-pin edge card connector Pin Desc. Pin Desc. Pin Desc. Wake 20 W_Disable# 36 USB_D- +3.3V 21 GND 37 GND COEX1 22 PERST# 38 USB_D+ 23 PERn0 39 +3.3V COEX2 24 +3.3V...
  • Page 41 Engine of the Computer Description: PCIe MiniCard socket Connector Type: Onboard 0.8mm pitch 52-pin edge card connector Pin Desc. Pin Desc. Pin Desc. Wake 20 W_Disable# 36 USB_D- +3.3V 21 GND 37 GND COEX1 22 PERST# 38 USB_D+ 23 PERn0 39 +3.3V COEX2 24 +3.3V...
  • Page 42 Engine of the Computer DIO1 Description: Digital I/O connector Connector Type: 25-pin female DB connector Pin Desc. Pin Desc. DIO0 DIO1 DIO2 DIO3 DIO4 DIO5 DIO6 DIO7 DIO8 DIO9 DIO10 DIO11 DIO12 DIO13 DIO14 DIO15 Board Top Rear Panel - 30 -...
  • Page 43 Engine of the Computer PWRIN1 Description: DC-in power receptacle 1 2 3 4 Connector Type: 5.00mm-pitch 4-pole Euro-Type terminal block Pin Desc. PWRINV+ PWRINV- C-GND PWR_IN_SW# Board Top Rear Panel - 31 -...
  • Page 44 Engine of the Computer DP1A&DP1B Description: DisplayPort double stack connectors Connector Type: DisplayPort digital video connector Desc. Desc. DDIC_TXC0_CON DDIC_TXC3#_CON DDIC_TXC0#_CON DDPC_DP_AUX_EN# DDIC_TXC1_CON DDPC_DP_CONFIG2 DDPC_AUXP_CON DDIC_TXC1#_CON DDIC_TXC2_CON DDPC_AUXN_CON DDPC_HPD_CON DDIC_TXC2#_CON DDIC_TXC3_CON Board Top Rear Panel - 32 -...
  • Page 45 Engine of the Computer JPIC1 Description: PIC programming pin header Connector Type: Onboard 2.0mm pitch 6-pin header Desc. Desc. ICSP-CLK ICSP-DAT VCC5_PIC MCU_RST Board Top - 33 -...
  • Page 46 Engine of the Computer LAN2&LAN3 Description: One Ethernet port over double- stacked USB 3.0 ports Connector Type: One 8P8C RJ45 connector w/ two SuperSpeed type-A USB 3.0 connectors 1 2 3 4 LAN (RJ-45) USB (Type-A) Pin Desc. Pin Desc. Pin Desc.
  • Page 47 Engine of the Computer USB1 and USB4 Description: Connectors for the internal USB USB4 USB1 ports (for FPC-7601/7602/7603 only, Configure-to-Order) Connector Type: 1 x 5-pin wafer connector USB1 USB4 Pin Desc. Desc. Board Bottom - 35 -...
  • Page 48 Engine of the Computer COM1&COM2 Description: Serial port 1&2, RS232 ports Connector Type: 9-pin male DB connector Pin Definition: RS232 Desc. Desc. Board Top Rear Panel - 36 -...
  • Page 49 Engine of the Computer COM3&COM4 Description: Serial port 3&4, configurable between RS232, RS422 and RS485. Connector 9-pin male DB connector Type: Pin Definition: RS232 RS485 RS422 Pin Desc. Pin Desc. Desc. Desc. RS485D- RS422 TX- RS485D+ RS422 TX+ RS422 RX+ RS422 RX- To switch between RS232/422/485 mode, refer to BIOS setting: 5.2.7.
  • Page 50 This page is intentionally left blank. - 38 -...

  • Page 51: Chapter 4 - Installation And Maintenance

    Chapter 4 Installation and Maintenance Chapter 4 - Installation and Maintenance - 39 -...

  • Page 52: Install Hardware

    Installation & Maintenance 4.1. Install Hardware The FPC-7600 Series is constructed based on modular design to make it easy for users to add hardware or to maintain the computer. The following sections will guide you to the simple hardware installations for the computer.
  • Page 53 Installation & Maintenance After the said screws are removed, proceed to dismount the top cover. Carefully lift the top cover and then completely part the top cover from the computer. The inside of the computer comes to view. FPC-7600 FPC-7601~04 To adjust jumpers or connect/disconnect cables to/from the main board, 3.2.
  • Page 54 Installation & Maintenance 4.1.1.2. Remove the Bottom Cover The Serial ATA connectors, the power connectors for SATA storage devices, and the internal USB ports (configure-to-order for FPC-7601/7602/7603 only), PCI and PCIe connectors are all built on the bottom side of the main board. To access these connectors, the computer’s bottom cover has to go.
  • Page 55 Installation & Maintenance After the said screws are removed, proceed to dismount the bottom cover. Carefully lift and then completely part the bottom cover from the computer. FPC-7600 FPC-7601~04 The inside of the computer comes to view. FPC-7600 FPC-7601~04 To install internal USB drives, see 4.1.3.

  • Page 56: Install/Uninstall Memory Modules

    The main board has two dual inline memory module (DIMM) sockets. Increase memory capacity to make programs run faster on the system. The memory module for the FPC-7600 Series’ SO-DIMM sockets should be a 204-pin DDR3 with a “key notch” off the centre among the pins, which enables the memory module for particular applications.
  • Page 57 Installation & Maintenance Pull back both latches from the socket. the break latch latch the SO-DIMM socket’s slot connector vertical-type SO-DIMM socket (overview) Confront the memory module’s edge connector side at the SO-DIMM socket. Position the memory module at the SO-DIMM socket, with the memory module’s key notch aligned at the break of the SO-DIMM’s slot connector.
  • Page 58 Installation & Maintenance Install Memory Module with Heat Spreaders Have the heat spreaders. One has the bigger fin and the other has the smaller fin. Each heat spreader comes with a thermal pad. Attach the memory module to the thermal pad side of the heat spreader with bigger fin.
  • Page 59 Installation & Maintenance View from the other side.. Attach the other heat spreader to the other side of the memory module so the two heat spreaders sandwich the memory module. Be sure to align the two heat spreaders properly so as to form the two clip holes. - 47 -...
  • Page 60 Installation & Maintenance Have the two metal clips. Use them to hold the heat spreaders and the memory module together. - 48 -...
  • Page 61 Installation & Maintenance Make sure the heat spreaders are clipped exactly as shown in the pictures below. Fully push the clips until they cannot be pushed any more. See the pictures below. push - 49 -...
  • Page 62 Installation & Maintenance Note: The above mentioned demonstrated one clip only. When you install the memory module with heat spreaders, be sure to use both clips. Remove the top cover from the computer as described in 4.1.1.1. Remove Top Cover on page 40.
  • Page 63 Installation & Maintenance 10. Vertically plug the memory module to the DIMM socket. “Fully” plug the memory module until both latches auto-lock the memory module in place. key notch 11. Attach another thermal pad onto the top of the heat spreaders. Thermal pad 12.

  • Page 64: Install Cpu

    Installation & Maintenance 4.1.3. Install CPU Locate the six screws which secure the Thermal Lump. Use a screwdriver to remove the six screws and keep them safely for later use. The processor socket comes with a screw to secure the CPU. As shown in the picture below, loose the screw first before inserting the CPU.

  • Page 65: Install Sata Storage Devices

    The computer supports two 2.5” SATA storage devices to work inside the computer for RAID. The following will gudie you to install two SATA HDD or SSD. 4.1.4.1. Install SATA Storage Devices for FPC-7600 Series Remove the bottom cover from the computer as described in 4.1.1.2.
  • Page 66 Installation & Maintenance For the 1st storage bracket: Slide an HDD/SSD storage device into the bracket. FPC-7600 FPC-7601~04 Fix the storage device in place by using screws at the four screw holes on both sides of the bracket. FPC-7600 FPC-7601~04 - 54 -...
  • Page 67 Installation & Maintenance Install the bracket and the storage device back into the computer by refastening the four screws. SATA connectors Power connectors for SATA storage devices FPC-7600 FPC-7601~04 Connect the SATA signal cable(s) and power cable(s). FPC-7600 FPC-7601~04 Restore the bottom cover to the computer. - 55 -...

  • Page 68: Install Pci And Pci Express Cards

    Installation & Maintenance 4.1.5. Install PCI and PCI Express Cards The FPC-7600 series supports PCIe x16 slots, PCIe x8 slots, and PCI slots. Different SKUs have different options, please refer to Section 1.5. Ordering Information on page 5. Follow the guide below to install an PCI Express or PCI card to the computer.
  • Page 69 Use the screwdriver to loose the screw securing the lower expansion slot bracket. - 57 -...

  • Page 70: Install Wireless Modules

    Installation & Maintenance 4.1.6. Install Wireless Modules The computer comes with two Mini-card sockets to load the computer with the wireless modules of PCI Express Mini-card form factor. The configure- to-order wireless modules available with the computer is the Wi-Fi moldue WIFI-AT2300: WIFI-AT2300 Atheros AR9462 Wi-Fi module w/ 20cm internal wiring...

  • Page 71: Mount The Computer

    Installation & Maintenance 4.2. Mount the Computer Integrate the computer to where it works by mounting it to a wall in the surroundings. Such integration relies on a wall-mount kit, which is available on option. Follow through the guide below to assemble the kit to the computer: Place the computer upside down on a flat surface.

  • Page 72: Ground The Computer

    Installation & Maintenance 4.3. Ground the Computer Follow the instructions below to ground the computer to land. Be sure to follow every grounding requirement in your place. Warning Whenever the unit is installed, the ground connection must always be made first of all and disconnected lastly. See the illustration below.

  • Page 73: Wire Dc-In Power Source

    Installation & Maintenance 4.4. Wire DC-in Power Source Warning Only trained and qualified personnel are allowed to install or replace this equipment. Follow the instructions below for connecting the computer to a DC-input power source. Before wiring, make sure the power source is disconnected. Find the terminal block in the accessory box.
  • Page 74 This page is intentionally left blank. - 62 -...

  • Page 75: Chapter 5 - Bios

    Chapter 5 BIOS Chapter 5 - BIOS - 63 -...
  • Page 76 BIOS The BIOS Setup utility for the FPC-7600 Series is featured by American Megatrends Inc to configure the system settings stored in the system’s BIOS ROM. The BIOS is activated once the computer powers on. When the computer is off, the battery on the main board supplies power to BIOS RAM.
  • Page 77 BIOS Key Commands The BIOS Setup utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and use the utility. Keystroke Function ← → Moves left/right between the top menus. ↓ ↑ Moves up/down between highlight items.

  • Page 78: Main

    BIOS 5.1. Main The Main menu features the settings of System Date and System Time and displays some BIOS info. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit BIOS Information Choose the system default BIOS Vendor American Megatrends...

  • Page 79: Advanced

    BIOS 5.2. Advanced Access the Advanced menu to manage the computer’s system configuration including the Super IO chip, Fintek 81866. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit ACPI Settings System ACPI Parameters S5 RTC Wake Settings CPU Configuration...

  • Page 80: Acpi Settings

    BIOS 5.2.1. ACPI Settings The submenu ACPI Settings enable users to change the system’s ACPI (Advanced Configuration and Power Interface) configuration by the following settings: Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit ACPI Settings Enables or Disables System ability to Hibernate (OS/S4...

  • Page 81: S5 Rtc Wake Settings

    BIOS 5.2.2. S5 RTC Wake Settings Access this submenu to configure whether and when to awake the system. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced Wake system with Fixed Time [Disabled] Enable or disable System wake on alarm [Disabled] event.

  • Page 82: Cpu Configuration

    BIOS Sets if to awake the system some time in the future. Options available are Enabled and Disabled (default). Enable this feature to awake the system some time from Wake System now. When enabled, the following setting becomes available: with Dynamic Setting Description TIme...

  • Page 83: Sata Configuration

    BIOS 5.2.4. SATA Configuration SATA Configuration manages the system’s SATA configuration and also delivers its status. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced Enable or disable SATA Device. SATA Controller(s) [Enabled] SATA Mode Selection [AHCI] SATA Controller Speed [Gen3] Serial ATA Port 0 INTEL SSDSC2BB (80.0G...

  • Page 84: Intel(R) Anti-Theft Technology Configuration

    BIOS 5.2.5. Intel(R) Anti-Theft Technology Configuration Disabling Intel(R) AT Allow User to login to platform. This is strictly for testing only. This does not disable Intel(R) AT Services in ME. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced Intel(R) Anti-Theft Technology Configuration Enable/Disable Intel...

  • Page 85: Usb Configuration

    BIOS 5.2.6. USB Configuration Select this submenu to view the status of the USB devices and configure USB features. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support. AUTO option disables legacy support if no USB devices are USB Devices: connected.

  • Page 86: F81866 Super Io Configuration

    BIOS 5.2.7. F81866 Super IO Configuration This submenu configures the Super IO chip (Fintek F81866) for the computer’s serial ports 1~4 and the parallel port. The featured submenus are: Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced Set Parameters of Serial Port F81866 Super IO Configuration 1 (COMA)
  • Page 87 BIOS Configures the computer’s COM3 , which is fixed to RS232 and cannot be changed. The featured settings are: Setting Description Enables/disables the serial port. Serial Port 3 Serial Port Enabled is the default. Configuration Change Settings Select an optimal setting for Super IO device. Select RS232, RS422, and RS485 mode Serial Port 1 RS232 is the default.

  • Page 88: F81866 H/W Monitor

    BIOS 5.2.8. F81866 H/W Monitor Select this submenu to view the main board’s hardware status. Select it to run a report of various info as depicted below: Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit PC Health Status CPU temperature : +50 °C...

  • Page 89: Intel Icc

    BIOS 5.2.9. Intel ICC Select this submenu to configure the serial port console redirection configuration. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Use Watchdog Timer for ICC [Disabled] Console Redirection Enable or Turn off unused PCI/PCIe clocks [Enabled] Disable.

  • Page 90: Cpu Ppm Configuration

    BIOS 5.2.10. CPU PPM Configuration Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced CPU PPM Configuration Enable/Disable Intel SpeedStep. Turbo Mode [Enabled] →←: Select Screen ↓↑: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F9: Optimized Defaults F10: Save and Exit ESC: Exit...

  • Page 91: Chipset

    BIOS 5.3. Chipset The Chipset menu controls the system’s chipset. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit PCH-IO Configuration PCH Parameters System Agent (SA) Configuration →←: Select Screen : Select Item Enter: Select +/-: Change Opt.

  • Page 92: Pch-Io Configuration

    BIOS 5.3.1. PCH-IO Configuration Select this submenu to view the RC version, SKU name and revision ID of the Intel PCH. Select this submenu also to configure the PCH: ® Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset...
  • Page 93 BIOS 5.3.1.1. USB Configuration Access this submenu to configure the system’s USB ports. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Chipset Control the USB ECHI (USB 2.0) USB Configuration functions. One EHCI controller must always be enabled. EHCI1 [Enabled] EHCI2...

  • Page 94: System Agent (Sa) Configuration

    BIOS 5.3.2. System Agent (SA) Configuration Select this submenu to view the name and RC version of the System Agent (SA), i.e. the north bridge. Select this submenu also to configure the System Agent (SA) by the following setting and submenus: Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
  • Page 95 BIOS 5.3.2.1. Graphics Configuration Select Graphics Configuration to view graphics info and accesses graphics settings. The featured settings are: Setting Description IGFX VBIOS Version Display the IGFX(internal VGA) VBIOS version. IGFX Frequency Display the IGFX freqency Sets the graphics turbo IMON current values. Graphics Turbo IMON Options available are 14 to 31.
  • Page 96 BIOS 5.3.2.3. Memory Configuration Display the memory information Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Chipset Memory Information Memory RC Version 1.2.0.0 Memory Frequency 1600 Mhz Total Memory 4096 MB (DDR3) DIMM#0 4096 MB (DDR3) DIMM#2 Not Present CAS Latency (tCL) Minimum delay time CAS to RAS (tRCmin)

  • Page 97: Boot

    BIOS 5.4. Boot The Boot menu configures how to boot up the system such as the configuration of boot device priority. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Boot Configuration Number of seconds to wait for Setup Prompt Timeout setup activation key.

  • Page 98: Csm Paramenters

    BIOS Enables/disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect Fast Boot for BBS boot options. Disabled is the default. Boot Option Priority Boot Option #1 Set the system boot priorities. Hard Drive BBS Set the hard drive BBS priorities.
  • Page 99 BIOS The featured settings are: Setting Description Enables/disables launching CSM (capability support module), which provides UEFI with the additional functionality to allow Launch CSM loading a traditional OS or using a traditional OpROM. Options available are: Enabled (default) and Disabled. Defines the devices to boot the system to.

  • Page 100: Security

    BIOS 5.5. Security The Security menu sets up the password for the system’s administrator account. Once the administrator password is set up, this BIOS Setup utility is limited to access and will ask for the password each time any access is attempted.

  • Page 101: Save & Exit

    BIOS 5.6. Save & Exit The Save & Exit menu features a handful of commands to launch actions from the BIOS Setup utility regarding saving changes, quitting the utility and recovering defaults. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Boot Security Save &...
  • Page 102 This page is intentionally left blank. - 90 -...

  • Page 103: Appendices

    Appendices Appendices Appendices - 91 -...

  • Page 104: A: Digital I/O Setting

    Appendices A: Digital I/O Setting Digital I/O can read from or write to a line or an entire digital port, which is a collection of lines. This mechanism helps users achieve various applications such as industrial automation, customized circuit, and laboratory testing. Take the source code below that is written in C for the digital I/O application example.
  • Page 105 Appendices outportb(sioIndex,0x07); Select logic device – GPIO */ outportb(sioData, 0x06); outportb(sioIndex,0x30); Enable GPIO */ outportb(sioData, 0x01); iTemp = iMode & 0x00FF; outportb(sioIndex,0xA0); GPIO 50~57 - Output Enable */ outportb(sioData,iTemp); iTemp = (iMode & 0xFF00) >> 8; outportb(sioIndex,0x88); GPIO 80~87 - Output Enable */ outportb(sioData,iTemp); outportb(sioIndex,0xAA); /* Disable Super I/O */ void SioGPIOData(int iData) int iTemp; outportb(sioIndex,0x87); Enable Super I/O */ outportb(sioIndex,0x87); outportb(sioIndex,0x07); Select logic device –...
  • Page 106 Appendices outportb(sioIndex,0x87); Enable Super I/O */ outportb(sioIndex,0x87); outportb(sioIndex,0x07); Select logic device – GPIO */ outportb(sioData, 0x06); outportb(sioIndex,0xA2); GPIO 50~57 - Status */ iTemp = inportb(sioData); outportb(sioIndex,0x8A); GPIO 80~07 - Status */ iStatus = inportb(sioData); outportb(sioIndex,0xAA); /* Disable Super I/O */ iStatus = (iStatus<<8) + iTemp; return iStatus; - 94 -...

  • Page 107: B: Watchdog Timer (Wdt) Setting

    Appendices B: Watchdog Timer (WDT) Setting WDT is widely used for industry application to monitor the activity of CPU. Application software depends on its requirement to trigger WDT with adequate timer setting. Before WDT time out, the functional normal system will reload the WDT.

  • Page 108: C: Wi-Fi Module Wifi-At2300 Hardware Installation

    Appendices C: Wi-Fi Module WIFI-AT2300 Hardware Installation To use Wi-Fi, hardware-wise the computer needs a Wi-Fi module installed, and software-wise the computer needs the device driver and an application program. This appendix will guide you to install the Wi-Fi module WIFI-AT2300 .
  • Page 109 Appendices Find the Mini-card socket for wireless modules on the board as the illustration above shows. The socket has a break among the connector. connector break Prepare the WIFI-AT2300 Wi-Fi module kit. The module is a half-size module of PCI Express Mini-card form factor, with two U.FL connectors, one is “MAIN“, and the other is “AUX“.
  • Page 110 Appendices In order to make the half-size Wi-Fi module compatible with the Mini- card socket, extend the WiFi module with a “mini half bracket”. Join them together by using two screws. Position the WiFi Join the WiFi module module and the “mini and the “mini half half bracket”...
  • Page 111 Appendices Remove the plastic plug from the computer's rear (or front) panel to make an antenna hole. Keep the plastic plug for any possible restoration in the future. Have the RF antenna. The antenna has an SMA connector on one end and an MHF connector on the other.
  • Page 112 Appendices Connect the RF antenna’s MHF connector to the Wi-Fi module’s “MAIN“ connector. Connect the RF antenna’s MHF connector to the Wi-Fi module’s “MAIN” connector 10. From the other end of the RF antenna, which is an SMA connector, remove the washer and the nut.
  • Page 113 Appendices 11. Pull the SMA connector through the above mentioned antenna hole. Note to meet the aforesaid flat side with the antenna hole's flat side. the flat side of the antenna hole Arrange the flat side of the SMA connector to meet the flat side of the antenna hole.
  • Page 114 Appendices 13. Restore the computer’s top cover. 14. Have an external antenna. Screw and tightly fasten the antenna to the SMA connector. 15. Swivel the antenna to an angle of best signals. - 102 -...

  • Page 115: D: Install Internal Usb Drives

    Appendices D: Install Internal USB Drives Since some critical application programs rely on a USB key to run, an USB drive is necessary to store related encrypted keys and digital certificates. The FPC-7601, FPC-7602 and FPC-7603 allow building one USB port inside the chassis to support one USB drive to work therein for reinforced protection against theft or tamper.
