- Page 1 LYNC-712/715-4200G4 Series Fanless 12.1”/15” Industrial Panel PC with Intel N4200 Quad-Core™ Processor ® User’s Manual Version 1.0 P/N: 4012071004100P 2018.05...
- Page 2 Revision History Version Time Description 2018.05 Initial release - II -...
-
Page 3: Table Of Contents
Contents Contents Revision History ................II Contents ....................i Preface....................iii Copyright Notice ..................iii Declaration of Conformity ...............iii CE ....................iii FCC Class A ..................iii RoHS ....................iv SVHC / REACH ................iv Important Safety Instructions ..............v Warning ....................vi Lithium Battery Replacement ..............vi Technical Support .................. -
Page 4: Contents
Contents 4.1. Use Onboard Jumpers and Connectors ........28 4.2. Install Hardware ................29 4.2.1. Install SSD or HDD .............. 29 4.2.2. Install CFast Card ..............30 4.2.3. Install Wi-Fi Module ............. 31 4.3. Mount the Computer ..............32 4.3.1. Panel Mounting ..............32 4.3.2. -
Page 5: Preface
Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages. -
Page 6: Rohs
(PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed... -
Page 7: Important Safety Instructions
Preface Important Safety Instructions Read these safety instructions carefully 1. Read all cautions and warnings on the equipment. 2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage 3. Make sure the correct voltage is connected to the equipment. 4. -
Page 8: Warning
Preface Warning The Panel PC and its components contain very delicately Integrated Circuits (IC). To protect the Panel PC and its components against damage caused by static electricity, you should always follow the precautions below when handling 1. Disconnect your Panel PC from the power source when you want to work on the inside. -
Page 9: Warranty
Preface Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms. - Page 10 This page is intentionally left blank. - viii -...
-
Page 11: Chapter 1 - Introduction
Chapter 1 Introduction Chapter 1 - Introduction - 1 -... -
Page 12: The Computer
Introduction 1.1. The Computer ARBOR’s LYNC-712 & 715-4200G4 is cost-effective industrial panel PC featuring light weight and slim form factor. The computer comes with rich I/O to meet the demand of the automation and manufacturing process required in modern factories. The system includes four serial ports, five USB ports, one DVI port and two LAN ports. -
Page 13: Specifications
Introduction 1.3. Specifications System Intel N4200 Quad-Core™ Processor 1.10GHz ® Memory Soldered onboard 4GB DDR3L SDRAM 1 x Intel i210IT GbE controller ® 1 x Realtek 8111E GbE controller ® Watchdog Timer 1~255 levels reset Storage 1st Device 1 x outside-accessible CFast slot 2nd Device 1 x 2.5”... - Page 14 Introduction Expansion Expansion Bus 1 x Mini-card socket (Full Size) External I/O 4 x DB-9 connectors for COM1~4 Serial Ports (COM1 ~ COM4 are RS-232/485 configurable) 4 x Type-A USB 2.0 ports (rear) USB Ports 1 x Type-A USB 2.0 port with rubber cover on front bezel 2 x RJ-45 GbE ports 1 x DVI-I connector (support DVI only) WiFi...
-
Page 15: Inside The Package
Introduction 1.4. Inside the Package Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: 1 x LYNC-712 or 715-4200G4 industrial panel PC 1 x Accessory Box that contains the following items:... -
Page 16: Optional Accessories
Introduction 1.5.1. Optional Accessories The following items are normally optional, but some vendors may include them in the standard package, or some vendors may not carry all the items. PAC- 12V/5A 60W AC/DC power adapter kit P060W-02 LYNC-712 VESA-mount bracket kit, w/ 75 x VMB-712 75 mm &... -
Page 17: Chapter 2 - Getting Started
Chapter 2 Getting Started Chapter 2 - Getting Started - 7 -... -
Page 18: Dimensions
Getting Started 2.1. Dimensions LYNC-712-4200G4 Unit: mm LYNC-715-4200G4 Unit: mm - 8 -... -
Page 19: Tour The Computer
Getting Started 2.2. Tour the Computer Take a look around the computer and find the external controls and connectors. The appearance of LYNC-712-4200G4 and LYNC-715-4200G4 are similar. This section will use the image of LYNC-715-4200G4 as the example. 2.2.1. Front View Type-A USB 2.0 port with rubber cover Function keys... -
Page 20: Rear View
Getting Started 2.2.2. Rear View speakers (optional) VMB-712/715 (optional VESA-mount bracket kit) 2.2.3. Bottom View The bottom side of the computer is where the computer’s I/O ports are. ⑦ ⑧ ⑤ ⑥ ⑨ ② ③ ④ ① Description ① Power switch, ②... -
Page 21: Top View
Getting Started 2.2.4. Top View antenna holes w/ SMA connectors 2.3. Driver Installation Windows 10 64-bit Device Driver Path Chipset \Win10\Chipset\SetupChipset.exe \Win10\Ethernet\Intel LAN\PROWinx64.exe Ethernet \Win10\Ethernet\Realtek LAN\Install_Win10_10009_07202016\ setup.exe Graphic \Win10\Graphic\Setup.exe \Win10\Serial IO\SerialIO_30.100.1620.02_APL_PV_Win10\x64\ Serial IO SetupSerialIO.exe \Win10\TXE\SetupTXE.exe \Win10\USB To UART\XRUSB-Windows-DriversOnly-Vers2.2.0.0\ USB TO UART EXE\xrusbser_ver2200_installer.EXE After everything is installed properly, please execute this program to do calibration:... - Page 22 This page is intentionally left blank. - 12 -...
-
Page 23: Chapter 3 - Engine Of The Computer
Chapter 3 Engine of the Computer Chapter 3 - Engine of the Computer - 13 -... -
Page 24: Board Layout
Engine of the Computer 3.1. Board Layout The engine of the computer is constructed by the CPU module EmQ-i2401, the carrier board PBQ-9014 and the optional daughterboard SCDB-141B. 3.1.1. CPU Module (EmQ-i2401) Top View Bottom View 3.1.2. Daughterboard (SCDB-141B, optional) SPKL1 SPKR1 CN16(AUDIO)1 - 14 -... -
Page 25: Carrier Board (Pbq-9014)
Engine of the Computer 3.1.3. Carrier Board (PBQ-9014) JATX1 CN15(TP)3 CN9(SW)1 CN15-TP1 CN21 JBIOS1 CN19(INV)1 JBLON1 JVLCD1 CN16(AUDIO)1 FAN1 JFRT1 NO COMPONENT JBAT1 NO COMPONENT SATA1 PC17 CN11 CN12 CN13 CN22 CN14 - 15 -... -
Page 26: Jumpers And Connectors
Engine of the Computer 3.2. Jumpers and Connectors This chapter will explicate each of the jumpers and connectors on the carrier board of the computer. 3.2.1. Jumpers JATX1 CN15(TP)3 CN9(SW)1 JATX1 Function: AT/ATX MODE CN15-TP1 Selection Jumper Type: 2.00mm-pitch CN21 1x3-pin header Setting: Description... - Page 27 Engine of the Computer JFRT1 JATX1 CN15(TP)3 CN9(SW)1 Function: front panel LED indication CN15-TP1 Jumper Type: 2.54mm-pitch 2x5-pin header CN21 Setting: Description Setting system reset power LED+ JBIOS1 HDD LED+ speaker CN19(INV)1 9-10 power button JBLON1 JVLCD1 CN16(AUDIO)1 JBAT1 Function: COMS setting FAN1 Jumper Type: 2.00mm-pitch JFRT1...
- Page 28 Engine of the Computer JVLCD1 JATX1 CN15(TP)3 CN9(SW)1 Function: LCD power selection Jumper Type: 2.00mm-pitch CN15-TP1 1x3-pin header CN21 Setting: Description Setting JBIOS1 3.3V (default) CN19(INV)1 JBLON1 JBLON1 JVLCD1 CN16(AUDIO)1 Function: LCD backlight activeness selection FAN1 Jumper Type: 2.00mm-pitch JFRT1 1x3-pin header NO COMPONENT Setting:...
- Page 29 Engine of the Computer JATX1 CN15(TP)3 CN9(SW)1 Function: COM1 function selection CN15-TP1 Jumper Type: 2.00mm-pitch CN21 1x3-pin header Setting: Description Setting for factory testing JBIOS1 normal (default) CN19(INV)1 JBLON1 JVLCD1 CN16(AUDIO)1 FAN1 JFRT1 NO COMPONENT JBAT1 NO COMPONENT SATA1 PC17 CN11 CN12 CN13...
-
Page 30: Connectors
Engine of the Computer 3.2.2. Connectors CN19(INV)1 JATX1 CN15(TP)3 CN9(SW)1 Function: inverter connector Connector Type: 2.00mm- CN15-TP1 pitch 1x5-pin 4-wall wafer CN21 connector Setting: Description +12V/+5V BL-ON BL-Control JBIOS1 CN1(Power)1 Function: power input 1 2 3 CN19(INV)1 Connector Type: 5.00mm- JBLON1 pitch 3-pole male-type euro- style terminal block... - Page 31 Engine of the Computer CN21 JATX1 CN15(TP)3 CN9(SW)1 Function: USB 3.0 connectors CN21(USB)1 Connector Type: 1x10-pin CN15-TP1 header CN21 Setting: Desc. Pin Desc. VCC5 JBIOS1 CN22 Function: USB connectors CN22(USB)1 Connector Type: 2.54mm- pitch 1x5-pin header CN19(INV)1 Setting: JBLON1 Description JVLCD1 5VCC CN16(AUDIO)1...
- Page 32 Engine of the Computer CN15(TP)3 JATX1 CN15(TP)3 CN9(SW)1 Function: touch panel connector CN15-TP1 Connector Type: 2.54mm- CN21 pitch 1x5-pin header Setting: Description Sense JBIOS1 LVDS1 Function: LCD connector CN19(INV)1 Connector Type: DF-13- JBLON1 30DP-1.25V connector JVLCD1 CN16(AUDIO)1 FAN1 JFRT1 Setting: Pin Description Pin Description NO COMPONENT JBAT1...
- Page 33 Engine of the Computer CN2~CN5 JATX1 CN15(TP)3 CN9(SW)1 Function: COM1~4 Connector Type: 9-pin CN15-TP1 male-type DSUB connector CN21 Setting: RS-232 Pin Description Pin Description JBIOS1 Setting: RS-485 Pin Description Pin Description 485- 485+ CN19(INV)1 JBLON1 JVLCD1 CN16(AUDIO)1 FAN1 Note: To switch the COM port mdoe, please refer JFRT1 5.2.1.
- Page 34 Engine of the Computer CN7~CN8 JATX1 CN15(TP)3 CN9(SW)1 Function: RJ-45 Ethernet connectors CN15-TP1 Connector Type: CN21 10/100/1000Mbps Fast Ethernet Setting: Pin Description Pin Description MDI0 MDI2 MDI0# MDI2# MDI1 MDI3 MDI1# MDI3# JBIOS1 CN11~CN14 Function: USB2.0 ports Connector Type: double stack USB2.0 type A connector Setting: CN19(INV)1...
- Page 35 Engine of the Computer CN6(MINPCIE)1 JATX1 CN15(TP)3 CN9(SW)1 Function: PCI Express MiniCard socket Connector Type: onboard 0.8mm pitch 52- CN15-TP1 pin edge card connector CN21 JBIOS1 Function: CFast card Type I/II socket Connector Type: 7+17-pin CFast card connector consisting of a SATA compatible 7-pin signal connector and a 17-pin power CN19(INV)1 control connector.
- Page 36 Engine of the Computer JATX1 CN15(TP)3 SPKL1 SPKR1 CN9(SW)1 CN15-TP1 CN21 CN16(AUDIO)1 JBIOS1 CN16(Audio)1 Function: audio connector Connector Type: 2.00mm-pitch 1x9-pin 4-wall wafer connector Setting: CN19(INV)1 Pin Description JBLON1 12VCC 3VCC JVLCD1 HDA_SYNC CN16(AUDIO)1 HAD_SDOUT FAN1 JFRT1 HDA_CLK NO COMPONENT HDA_RST# JBAT1 NO COMPONENT...
-
Page 37: Chapter 4 - Installation And Maintenance
Chapter 4 Installation & Maintenance Chapter 4 - Installation and Maintenance - 27 -... -
Page 38: Use Onboard Jumpers And Connectors
Installation & Maintenance 4.1. Use Onboard Jumpers and Connectors The computer’s carrier board PBQ-9014 comes with some connectors to join some devices and also some jumpers to alter hardware configuration. Follow through the guide below to access these components inside the computer. As LYNC-712 &... -
Page 39: Install Hardware
Installation & Maintenance 4. Adjust the jumpers or use the connectors on the carrier board as described 3.2.1. Jumpers on page 3.2.2. Connectors on page 20. Be noted that the speakers and daughterboard are parts of ADK-712 module. Refer to 1.5.2. -
Page 40: Install Cfast Card
Installation & Maintenance 4.2.2. Install CFast Card The computer comes with a CFast slot to power the computer with a CFast card. To install a CFast card to the computer: 1. Locate the CFast slot. Remove the screw and take off the CFast slot door. 2. -
Page 41: Install Wi-Fi Module
Installation & Maintenance Caution: To eject the CFast card, make sure to push the middle of the card. DO NOT push only one side of the card to prevent the card from getting stuck in the slot. To eject the card properly, always push the middle of the card. -
Page 42: Mount The Computer
Installation & Maintenance 4.3. Mount the Computer Integrate the computer to where it works by mounting it to a wall in the surroundings or to the rear of a display monitor. Similarly, the subsequent illustrations only take LYNC-715 for instance. 4.3.1. -
Page 43: Vesa Mounting
Installation & Maintenance 4.3.2. VESA Mounting To support VESA-mounting, the computer needs a VESA bracket, which is available in 1.5.2. Configure-to-Order Service on page 6, to enable 75 x 75mm and 100 x 100mm VESA applications. 4.3.2.1. Install VESA Bracket Follow the guide below to install the VESA bracket to the computer: 1. - Page 44 Installation & Maintenance VMB-715 4. Fix the VESA bracket to the computer by two screws at each the left and right side of the computer. Use another two screws on the left side. Use two screws on the right side. 4.3.2.2.
- Page 45 Installation & Maintenance 100 x 100mm VESA mounting holes 75 x 75mm VESA mounting holes 3. Attach the VESA arm to the rear of the computer by meeting the mounting holes on the VESA arm and VESA bracket. 4. Fix the assemblage with four screws. - 35 -...
-
Page 46: Wire Dc-Input Power Source
Installation & Maintenance 4.4. Wire DC-Input Power Source Warning Only trained and qualified personnel are allowed to install or replace this equipment. Follow the instructions below to connect the computer to a DC-input power source: 1. Before wiring, make sure the power source is disconnected. 2. -
Page 47: Chapter 5 - Bios
Chapter 5 BIOS Chapter 5 - BIOS - 37 -... - Page 48 BIOS The BIOS Setup utility for the computer is to configure the system settings stored in the system’s BIOS ROM. The BIOS is activated once the computer powers on. When the computer is off, the battery on the main board supplies power to BIOS RAM.
- Page 49 BIOS Key Commands The BIOS Setup utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and configure the utility. Keystroke Function ← → Moves left/right between the top menus. ↓ ↑ Moves up/down between highlight items.
-
Page 50: Main
BIOS 5.1. Main The Main menu features the settings of System Date and System Time and displays some BIOS info and system info. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Set the Date. -
Page 51: Advanced
BIOS 5.2. Advanced Access the Advanced menu to manage the computer’s system configuration including the Super IO chip. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit F81866 Super IO Configuration System ACPI Parameters. -
Page 52: F81866 Super Io Configuration
BIOS 5.2.1. F81866 Super IO Configuration Setting Description Serial Port 1/2 Configuration Serial Port Enable (default) or Disable Serial Port (COM). Select an optimal setting for Super IO device. ► Auto; IO=2F8h; IRQ=3 (default for Serial Port 1); Change Settings IO=3F8h;... - Page 53 BIOS 3. Right-click on the XR21V1412 USB UART Ch A (COM3) or XR21V1412 USB UARhT Ch B (COM4) and then click Property from the context menu. 4. Select the Port Settings tab and check the RS-485 checkbox to enable it. 5.
-
Page 54: Hardware Monitor
BIOS 5.2.2. Hardware Monitor Select this submenu to view the main board’s hardware status. Select it to run a report of various info as depicted below: Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced Enable/Disable CSM Pc Health Status... -
Page 55: Cpu Configuration
BIOS 5.2.3. CPU Configuration Setting Description Socket 0 CPU Information Display Socket specific CPU Information. Enables/disables Intel SpeedStep EIST Enabled is the default. Enables/disables Turbo Mode Turbo Mode Enabled is the default. Select the performance state that the BIOS will set before OS handoff. -
Page 56: Usb Configuration
BIOS 5.2.5. USB Configuration Setting / Info Description Enables/disables legacy USB support. Options available are Enabled (default), Disabled and Auto. Select Auto to disable legacy support if no USB device are Legacy USB Support connected. Select Disabled to keep USB devices available only for EFI applications. -
Page 57: Chipset
BIOS 5.3. Chipset Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Main Advanced Security Boot Save & Exit Chipset LCD Concontrol ► LCD Control ► HD-Audio Configuration ► PCI Express Configuration ► SATA Drives ► USB Configuration →←: Select Screen ↓↑: Select Item Enter: Select +/-: Change Opt. -
Page 58: Lcd Control
BIOS 5.3.1 LCD Control Setting Description Select the video device which will be activated during POST. This has no ffect if external graphics present. Primary IGFX Boot Secondary boot display selection will appear based on your Display selection. VGA modes wil be supported only on primary display. Options: Auto (default), EFP and LFP. -
Page 59: Sata Drives
BIOS 5.3.4 SATA Drives Item Description Enables or disables the chipset SATA controller. Chipset SATA Options: Enabled (default) and Disabled Enables or disables the SATA port Port 0/1 Options: Enabled (default) and Disabled Identify the SATA port is connected to Solid State Drive or Hard Disk Drive. SATA Device Type Options: Hard Disk Driive (default) and Solid State Drive. -
Page 60: Security
BIOS 5.4. Security The Security menu sets up the password for the system’s supervisor account. Once the supervisor password is set up, this BIOS Setup utility is limited to access and will ask for the password each time any access is attempted. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. -
Page 61: Boot
BIOS 5.5. Boot The Boot menu configures how to boot up the system such as the configuration of boot device priority. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset Security Save & Exit Boot Number of seconds to Boot Configuration wait for setup Setup Prompt Timeout... -
Page 62: Exit
BIOS 5.6. Exit The Exit menu features a handful of commands to launch actions from the BIOS Setup utility regarding saving changes, quitting the utility and recovering defaults. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset Security Boot Save &... -
Page 63: Appendices
Appendices Appendices - 53 -... -
Page 64: Appendix A: Wifi-At4550 Hardware Installation
Appendices Appendix A: WIFI-AT4550 Hardware Installation This appendix will guide you to install the Wi-Fi module WIFI-AT4550. A.1. Install WIFI-AT4550 1. Loosen and remove the screws from the computer’s rear panel. LYNC-712-4200G4 LYNC-715-4200G4 2. Loosen and remove the 4 screws from each of the left and rirght side respectively. - Page 65 Appendices by using two screws. 5. Connect the RF antenna’s MHF connector to the Wi-Fi module. Connect the RF antenna’s MHF connector to the Wi-Fi module’s main connector Optionally connect the secondary RF antenna to this connector to enhance WiFi signal reception 6.
- Page 66 Appendices The notch on the Wi-Fi module should meet the break on the connector. 7. From the SMA end of the RF antenna, remove the washer and the nut. Save the washer and nut for later use. Note that the SMA connector is in the form of a threaded bolt, with one flat side.
- Page 67 Appendices Arrange the flat side of the SMA connector to meet the flat side of the antenna hole. 10. Mount the washer first and then the nut to the SMA connector. Make sure the nut is tightened. Mount the washer and the nut to the SMA connector.
-
Page 68: Appendix B: Penmount Utilities
Appendices Appendix B: PenMount Utilities B.1. PenMount Control Panel After everything is installed properly, there will be a touch screen application named PenMount Control Panel in All Programs. Execute this application. 1. The program consists of 3 tabs. The left one is Device, in it, you can find how many devices are detected in your system. - Page 69 Appendices 2. And then another window with Calibrate tab will jump out. Device Calibration Dialog a. The Calibrate Tab This function offers two ways to calibrate your touch screen. ‘Standard Calibration’ adjusts most touch screens while ‘Advanced Calibration’ adjusts aging touch screens. a.1 Standard Calibration The Standard Calibration function lets you match the touch screen to your display so that the point you touch is accurately tracked on screen.
- Page 70 Appendices 1st crosshair a.2 Advanced Calibration The Advanced Calibration function improves the accuracy of calibration by using more involved engineering calculations. Use this function only if you have tried the Standard Calibration and there is still a discrepancy in the way the touch screen maps to the display.
- Page 71 Appendices Turn off Plot Calibration EEPROM Data storage b. The Edge Compensation Tab Under the same level where you calibrate your screen, you may find the tab. This tab is the edge compensation settings for the advanced calibration. You can adjust the settings from 0 to 30 for accommodating the difference of each touch panel.
- Page 72 Appendices 3. Press OK to close former window and back to upper level. As mentioned before, the program consists of 3 tabs, and the central one is Tool, switch to it.and click Draw to test PenMount touch screen operation. - 62 -...
-
Page 73: Penmount Gesture
Appendices B.2. PenMount Gesture 1. Now that this tablet PC supports touchscreen function, you may take advantage of that to set hotkey or do other settings. Single-click a small icon like a monitor in system tray. If it's absent, you can recall it from All Programs. - Page 74 Appendices 2. Check “Enable” and click the upward arrow in red square. You may also disable gesture function by canceling “Enable” box. 3. And then another Gesture Select window will pop up. Each mark in this menu represents your gesture on screen. For example, the upward arrow indicates that you move your finger across the touch screen from bottom to top.
- Page 75 Appendices 4. Then again, choose Hot Key, Action or Application to set each gesture’s corresponding function. You may disable respective gesture, too. And remember to press Apply after all. - 65 -...
- Page 76 Appendices - 66 -...
