Arbor Technology EPC-20X0-2610UE User Manual

Fanless embedded computer with intel i7-i2610ue platform
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EPC-20x0-2610UE
Fanless Embedded Computer with
Intel® i7-i2610UE Platform
User's Manual
Version 1.0
2015.03
P/N: 4012200002100P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EPC-20X0-2610UE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arbor Technology EPC-20X0-2610UE

Summary of Contents for Arbor Technology EPC-20X0-2610UE

  • Page 1 EPC-20x0-2610UE Fanless Embedded Computer with Intel® i7-i2610UE Platform User’s Manual Version 1.0 2015.03 P/N: 4012200002100P...
  • Page 2 This page is intentionally left blank.

  • Page 3: Table Of Contents

    1.5 Power Information .............7 1.6 Dimensions ..............8 1.7 Locating Controls and Connectors ......10 1.8 Connecting Peripherals ..........12 Chapter 2 - The Engine of EPC-20x0-2610UE ......19 2.1 Board Layout ............20 2.2 Jumpers and Connectors ........24 Chapter 3 - Installation and Maintenance ......35 3.1 How to Install HDD, CFast, PCI/PCIe Card ....36...
  • Page 4 Index 4.7 Beep Sound codes list ..........74 4.8 AMI BIOS Checkpoints ..........76 Appendix .................87 Appendix A: I/O Port Address Map ......88 Appendix B: Memory Mapping ........91 Appendix C: Watchdog Timer (WDT) Setting ....93 - II -...
  • Page 5 Revision History Version Release Time Description March, 2015 Initial release - III -...

  • Page 6: Copyright Notice

    Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 7 RoHS ARBOR Technology Corp. certifies that all components in its products are in compliance and conform to the European Union’s Restriction of Use of Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive 2002/95/EC.

  • Page 8: Important Safety Instructions

    Important Safety Instructions Read these safety instructions carefully. 1. Read all cautions and warnings on the equipment. 2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage 3. Make sure the correct voltage is connected to the equipment. 4.

  • Page 9: About This User's Manual

    About This User’s Manual This User’s Manual is intended for experienced users and integrators with hardware knowledge of personal computers. If you are not sure about any description in this User’s Manual, please consult your vendor before further handling. Warning The Box PC and its components contain very delicately Integrated Circuits (IC).

  • Page 10: Warranty

    Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.

  • Page 11: Chapter 1 - General Information

    General Information Chapter 1 General Information - 1 -...

  • Page 12: Introduction

    General Information 1.1 Introduction EPC-20X0-2610UE is targeted at many different application fields. By adopting it, you can pinpoint specific markets, such as Automatic Optical Inspection, SMT/PCB Industry, In-Vehicle, environment-critical and space-critical applications. • All-In-One Platform The CPU, DRAM and even software are integrated to provide a plug- and-play machine.

  • Page 13: Packing List

    Accessory Box (Driver CD/User’s Manual/Screws/ Cable/Terminal Block) 1 x Wall-mount kit for EPC-20X0-2610UE Options: The following items are normally optional, but some vendors may include them as a standard package, or some vendors may not to carry all the items.
  • Page 14 General Information Optional Configuration (CTOS* Kit) 80GB SSD ® Intel 2.5" 80GB SATAIII SSD kit MM-3C-2G DDR3-1600 2GB SDRAM - 4 -...

  • Page 15: The Installation Paths Of Cd Driver

    General Information 1.3 The Installation Paths of CD Driver Windows 2000 & XP Driver Path CHIPSET \XP\INF\Setup.exe \XP\LAN\PROWin32.exe \XP\GRAPHICS\Setup.exe AUDIO \XP\AUDIO\XP_2000 WDM_R261 32_64 bit.exe \ME\Setup.exe Windows 7 Driver Path CHIPSET \Win7\INF\Setup.exe 32bit: \Win7\LAN\PROWin86.exe 64bit: \Win7\LAN\PROWin64.exe 32bit: \Win7\GRAPHIC\32bit\Setup.exe 64bit: \Win7\GRAPHIC\64bit\Setup.exe 32bit: \Win7\AUDIO\Win7_R261-32_64 bit .exe AUDIO 64bit: \Win7\AUDIO\Vista_Win7_R261-32_64 bit .exe \Win7\ME\Setup.exe...

  • Page 16: Specifications

    General Information 1.4 Specifications System Kernel Soldered onboard Intel® Core® Processor Processor i7-2610UE 1.5GHz BIOS AMI Flash BIOS Chipset Intel® QM67 PCH Graphics Integrated with Intel HD Graphics 3000 2 x DDR3 SO-DIMM sockets, Support SDRAM up to System Memory 16GB 1 x 2.5"...

  • Page 17: Power Information

    General Information Safety Class A certified Certified Environment Operating Temp. -20 ~ 60ºC (-4 ~ 140ºF), ambient w/ air flow Storage Temp. -40 ~ 85ºC (-40 ~ 185ºF) Relative Humidity 10 ~ 90% @ 60 C (non-condensing) Vibration 3Grms/5 to 500Hz/random operation, with SSD Operating 40G, 11ms Shock &...

  • Page 18: Dimensions

    General Information 1.6 Dimensions EPC-2020-2610UE • Dimension (W x D x H): 164 x 192 x 120 mm (6.46" x 7.56" x 4.72") 120.00 164.00 Unit:mm - 8 -...
  • Page 19 General Information EPC-2030-2610UE • Dimension (W x D x H): 164 x 192 x 140 mm (6.46" x 7.56" x 5.51") 140.00 164.00 Unit:mm - 9 -...

  • Page 20: Locating Controls And Connectors

    General Information 1.7 Locating Controls and Connectors Both EPC-2020-2610UE and EPC-2030-2610UE have the same I/O ports and connectors at the front panel. Please take a moment to identify those controls and connectors shown in the following figures. Front Panel EPC-2020-2610UE Power On/Off Power LED USB1~4...
  • Page 21 General Information Front Panel EPC-2030-2610UE Power On/Off Power LED USB1~4 HDD LED Line-out LAN1, 2 Mic-in COM3 LVDS COM4 2 x PCIe COM1 1 x PCI COM2 Power Input KB/MS - 11 -...

  • Page 22: Connecting Peripherals

    General Information 1.8 Connecting Peripherals The user can use the I/O interfaces located at the front side of the chassis to connect to external peripheral devices, such as a mouse, a keyboard, a monitor, serial devices or parallel printer, etc. Before connection, make sure that the computer and the peripheral devices are turned off.
  • Page 23 General Information To connect to any serial device, follow the steps below: 1. Turn off the BOX PC system and the serial devices. 2. Attach the interface cable of the serial device to the serial connector. Be sure to fasten the retaining screws. 3.
  • Page 24 General Information EPC-2020-2610UE EPC-2030-2610UE 1.8.4 USB Ports Both EPC-2020-2610UE and EPC-2030-2610UE have four USB ports on the front panel to connect to external USB devices. USB ports and devices are hot-pluggable. Therefore, any USB device can be connected at all time without turning off your system.
  • Page 25 General Information 1.8.5 Keyboard and Mouse Both EPC-2020-2610UE and EPC-2030-2610UE have one PS/2 keyboard/ mouse connector located at the front panel. EPC-2020-2610UE EPC-2030-2610UE To connect an AT keyboard, an adapter between the PS/2 interface and the AT Keyboard is needed. - 15 -...
  • Page 26 General Information 1.8.6 Expansion PCI/PCIe Slots EPC-2020-2610UE has one PCIe slot and one PCI slot while EPC-2030- 2610UE provides two PCIe slots and one PCI slot. EPC-2020-2610UE EPC-2030-2610UE EPC-2020 EPC-2030 PCIe 1.8.7 Audio Line-out/Mic-in Two audio jacks for Line-out and Mic-in located at the front panel. EPC-2020-2610UE EPC-2030-2610UE - 16 -...
  • Page 27 General Information 1.8.8 DC Power Input and Power ON/OFF Button For DC power input, the computer is equipped with a 3-pin terminal block receptacle on the front panel. The “S/W” button located on the front panel is used to power ON/OFF the computer. EPC-2020-2610UE EPC-2030-2610UE - 17 -...
  • Page 28 This page is intentionally left blank. - 18 -...

  • Page 29: Chapter 2 - The Engine Of Epc-20X0-2610Ue

    The Engine of EPC-2020/2030-2610UE Chapter 2 The Engine of EPC-2020/2030-2610UE - 19 -...

  • Page 30: Board Layout

    The Engine of EPC-2020/2030-2610UE 2.1 Board Layout The engine of EPC-2020-2610UE / EPC-2030-2610UE is constructed by the com- bination of PCBA boards. To be specific, EmETXe-i67M1, PBE-1902-2610UE, SCDB-1283, PBR-3SA and PBR-4SA mainly. Such a combination makes sys- tem customization feasible. Therefore, this and next sections will introduce these two main boards in detail.
  • Page 31 The Engine of EPC-2020/2030-2610UE SCDB-1283 PLED1 HDDLED1 AUDIO1 AUDIO2 LVDS1 LVLCD1 JGPI2 JGPI1 JVIN1 VGA1 BLON1 - 21 -...
  • Page 32 The Engine of EPC-2020/2030-2610UE PBR-3SA (for EPC-2020-2610UE) PCI1 PCIE1 PWRIN1 KBM1 - 22 -...
  • Page 33 The Engine of EPC-2020/2030-2610UE PBR-4SA (for EPC-2030-2610UE) PCI1 PCIE2 PCIE1 PWRIN1 KBM1 - 23 -...

  • Page 34: Jumpers And Connectors

    The Engine of EPC-2020/2030-2610UE 2.2 Jumpers and Connectors 2.2.1 Jumpers & Connectors List Jumpers Label Function SW1~4 COM 3/4 RS-232/RS-422/RS-485 Function Select Jumpers JV1~4 RI/5V/12V Selection For COM Ports JCP1 COM Port Power Selection JBAT1 Clear CMOS Setup JRST1 Reset Pin Header JPWR1 AT/ATX Power Mode Selection BLON1...
  • Page 35 The Engine of EPC-2020/2030-2610UE 2.2.2 Jumper Setting JCP1: COM Port Power Selection (13) Pin Description +5V (default) +12V JV1~4: RI/5V/12V D-sub Pin 9 Selection for COM Ports (9, 10, 11, 12) Pin Description RI (default) 5V or 12V (depends on JCP1) JBAT1: Clear CMOS Setting (14) Pin Description Keep CMOS (default)
  • Page 36 The Engine of EPC-2020/2030-2610UE JVIN1: Inverter Power Selection (22) Pin Description INV_VDD = +5V INV_VDD = +12V (default) LVLCD1: LCD Power Selection (23) Pin Description LCD_VDD = +5V LCD_VDD = +3.3V (default) SW1~2: COM3 RS-232/RS-422/RS-485 Function Selection (5, 6) SW1 Setting COM3 RS-232 (default) RS-422&485...
  • Page 37 The Engine of EPC-2020/2030-2610UE SW2 Setting COM3 RS-232 (default) RS-422 RS-485 1-16 2-15 3-14 4-13 5-12 6-11 7-10 × × × 16 15 14 13 12 11 10 9 16 15 14 13 12 11 10 9 16 15 14 13 12 11 10 9 16 15 14 13 12 11 10 9 16 15 14 13 12 11 10 9 16 15 14 13 12 11 10 9...
  • Page 38 The Engine of EPC-2020/2030-2610UE SW4 Setting COM4 RS-232 (default) RS-422 RS-485 1-16 2-15 3-14 4-13 5-12 6-11 7-10 × × × 16 15 14 13 12 11 10 9 16 15 14 13 12 11 10 9 16 15 14 13 12 11 10 9 16 15 14 13 12 11 10 9 16 15 14 13 12 11 10 9 16 15 14 13 12 11 10 9...
  • Page 39 The Engine of EPC-2020/2030-2610UE 2.2.3 Pin Assignments for Connectors COM A: RS-232 Serial Port Connector (1) Connector type: Double stacked D-Sub 9-pin male. Description Description COM2 DSR# DCD# RTS# CTS# DTR# COM1 COM B: RS-232/RS-422/RS-485 Serial Port Connectors (2) Connector type: Double stacked D-Sub 9-pin male. Description Description COM4...
  • Page 40 The Engine of EPC-2020/2030-2610UE LAN1, 2: Ethernet Connectors (includes USB Connectors) (3, 4) Connector type: RJ-45 + double stacked USB type A connector. LAN (RJ-45) Description MDI0+ MDI0- MDI1+ MDI1- MDI2+ MDI2- 8 7 6 5 4 3 2 1 MDI3+ 1 2 3 4 MDI3-...
  • Page 41 The Engine of EPC-2020/2030-2610UE SATA1: Serial ATA and Power Connectors (17) Description Description Description +3.3VDC +5VDC +3.3VDC +3.3VDC +12VDC +12VDC +5VDC +12VDC +5VDC VGA1: Analog RGB Display Connector (26) Connector type: Three-row/15-pin VGA Connector Pin Description Pin Description Pin Description GREEN VDDAT BLUE...
  • Page 42 The Engine of EPC-2020/2030-2610UE LVDS1: LVDS Display Connector (31) Connector type: D-Sub 26-pin male. Pin Description Pin Description Pin Description TX1_2+ TX0_CLK+ TX0_3+ TX1_2- TX0_CLK- TX0_3- TX1_3+ TX0_0+ TX1_CLK+ TX1_3- TX0_0- TX1_CLK- INV_VDD TX0_1+ TX1_0+ BLON TX0_1- TX1_0- BKLTCTL TX0_2+ TX1_1+ TX0_2- TX1_1-...
  • Page 43 The Engine of EPC-2020/2030-2610UE CF1: CFast Slot (32) CFast Card Type I/II slot Connector type: 7+17-pin CFast Card connector consisting of a SATA compatible 7-pin signal connector and a 17-pin power and control connector. Description Description PC17 LED1 LED2 PC10 IO1 PC11 IO2 PC12 IO3 PC13 PWR...
  • Page 44 This page is intentionally left blank. - 34 -...

  • Page 45: Chapter 3 - Installation And Maintenance

    Installation and Maintenance Chapter 3 Installation and Maintenance - 35 -...

  • Page 46: How To Install Hdd, Cfast, Pci/Pcie Card

    Installation and Maintenance 3.1 How to Install HDD, CFast, PCI/PCIe Card EPC-2020-2610UE / EPC-2030-2610UE is designed to be modular, slim and lightweight for easier maintenance. The following sections describe simple hardware installations. 3.1.1 Removing Top Cover 1. Locate the two screws on front panel which secure the top cover. 2.
  • Page 47 Installation and Maintenance - 37 -...
  • Page 48 Installation and Maintenance 3.1.2 HDD/SSD Installation 1. Before installing a CFast card, you should follow steps 1-2 in section 3.1.1 to remove the top cover of chassis. 2. Locate the thumbscrew securing the HDD holder bracket to the main unit. 3.
  • Page 49 Installation and Maintenance 5. Press the HDD holder bracket back to the SATA connector and then fasten the thumbscrew. 6. Fasten the two screws that secure the top cover. - 39 -...
  • Page 50 Installation and Maintenance Install CFast 3.1.3 Card Make sure you have turned off the power before inserting or ejecting the CFast card (if OS is installed on CFast card). 1. Before installing a CFast card, you should follow steps 1-2 in section 3.1.1 to remove the top cover of chassis.
  • Page 51 Installation and Maintenance 4. To remove the CFast card, follow the steps to remove the top cover and then push card inward to pop-out it from the slot. 5. Fasten the two screws that secure the top cover. - 41 -...
  • Page 52 Installation and Maintenance Install PCI/PCIe Card 3.1.4 Before installing a PCI/PCIe card, you should remove the top cover of chassis first. 1. Use a screwdriver to loose the screw that secures the expansion slot bracket. After removing the bracket, you can install a PCIe card to this expansion slot.

  • Page 53: Wall Mounting

    Installation and Maintenance 3.2 Wall Mounting 1. Find the wall-mount bracket and screws included in the accessory kit. 2. Select either the rear side or the right side to secure the wall-mouting bracket. 3. Locate the 4 screw holes on the rear side or the right side. 4.

  • Page 54: Din-Rail Mounting

    Installation and Maintenance 3.3 Din-rail Mounting 1. Please use the accompanying DIN rail kit to mount your computer to a standard DIN rail. 2. Select either the rear side or the right side to secure the bracket. 3. Locate the 4 screw holes on the rear side or the right side. 4.
  • Page 55 Installation and Maintenance Removing the Box PC from the DIN Rail 1. Make sure that power is removed from the computer, and disconnect all cables from the computer. 2. Hold the Box PC in both hands and push downwards. As the clip releases, lift the bottom of Box PC slightly.

  • Page 56: Wiring The Dc-Input Power Source

    Installation and Maintenance 3.4 Wiring the DC-Input Power Source Warning Only trained and qualified personnel are allowed to install or replace this equipment. Follow the instructions below for connecting the box PC to a DC-input power source. 1. Before wiring up, make sure the power source is disconnected. 2.

  • Page 57: Chapter 4 - Bios

    BIOS Chapter 4 BIOS - 47 -...
  • Page 58 BIOS The BIOS Setup utility is featured by AMI BIOS to configure the system settings stored in the system’s BIOS ROM. AMI BIOS is activated once the computer powers on. After entering the utility, use the left/right arrow keys to navigate between the top menus and use the down arrow key to access one.

  • Page 59: Main

    Main BIOS Information Set the Date. Use Tab to BIOS Vendor American Megatrands switch between Data elements. Core Version 4.6.5.3 BIOS Name EPC-20X0-2610UE BIOS Version 1.01 Build Date and Time 01/23/2014 19:12:03 System Language [English] System Date [Fri 12/26/2014] Select Screen...

  • Page 60: Advanced

    BIOS 4.2. Advanced The Advanced menu controls the system’s CPU, IDE, Super IO, AHCI and USB. It also helps users to monitor hardware health. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Chipset Boot Security Save & Exit Main Power On After Power Fail [Power Off]...
  • Page 61 BIOS 4.2.1. ACPI Settings Access this submenu to configure the system’s ACPI (Advanced Configuration and Power Interface). Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Power-supply Type ACPI Setting Power-Supply Type [ATX] : Select Screen : Select Item Enter : Select : Change Opt.
  • Page 62 BIOS 4.2.2. S5 RTC Wake Settings Access this submenu to enable/disable the system to wake up on a specified time. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Enables or Disables System Wake system with Fixed Time [Disabled] wake on alarm event.
  • Page 63 BIOS Sets if to awake the system some time in the future. Options available are Enabled and Disabled (default). Enable this feature to awake the system some time from now. When enabled, the following setting becomes available: Wake System with Dynamic Setting Description TIme...
  • Page 64 BIOS 4.2.3. CPU Configuration Access this submenu to identify the CPU and its capabilities by running a report listing the CPU’s model name, processor speed, microcode revision, max./min. processor speeds, processor cores, Intel Hyper-Threading Technology support ® and so on. This submenu also features the following settings to configure the CPU: Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
  • Page 65 BIOS Configures the number of cores to enable in each processor package. Active Processor Cores Available options are: All and 1. All is the default. Sets whether the processor should limit the maximum CPUID input value to 03h when the operating system queries it upon startup.
  • Page 66 BIOS 4.2.4. SATA Configuration Access this submenu to view SATA device(s) information and also to configure SATA device(s). Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Enable or Disable SATA Device. SATA Controller(s) [Enabled] SATA Mode Selection [IDE] Serial ATA Port 1 Empty...
  • Page 67 BIOS Features the following settings: Setting Description Enables/disables the SATA port. Port 0 Enabled is the default. Sets whether to make the SATA port an hot pluggable Hot Plug one. Disabled is the default. Enables/disables external SATA support. External SATA Disabled is the default.
  • Page 68 BIOS 4.2.5. AMT Configuration Intel Active Management Technology (Intel AMT) is a hardware-based solution ® ® that uses out-of-band communication for basic management of client systems, which allows a system administrator to monitor and manage the computers and other network equipment by remote control even if the hard drive is crashed, the system is turned off or the operating system is locked.
  • Page 69 BIOS 4.2.6. USB Configuration Access this submenu to view the USB device(s) enabled in the system. It also configures USB-related features. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced USB Devices: Enables Legacy USB support. AUTO option disables legacy 1 Keyboard, 2 Hubs support if no USB devices are connected.
  • Page 70 BIOS 4.2.7. Super IO Configuration This submenu opens in context with the system’s four serial ports, COM1 and COM2, to configure the Super IO chipset. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Super IO Configuration Set Parameters of Serial Port 1 (COMA) Super IO Chip Fintek F81216...
  • Page 71 BIOS Configures the system’s serial port (COM port). The featured settings are: Setting Description Enables/disables the serial port. Serial Port Enabled is the default. Sets the optimal IO address for the serial port. Serial Port 2 I/O Settings Options available are: Configuration 3F8h, 2F8h, 3E8h, 2E8h Sets the optimal IRQ info for the serial port.
  • Page 72 BIOS 4.2.8. Hardware Monitor Access this submenu to view the system’s hardware health status. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Pc Health Status CPU temperature : +35 ˚C System Temperature : +42 ˚C +3.3V : +3.348V VCore : +0.910V : +5.244V...
  • Page 73 BIOS 4.2.9. CPU PPM Configuration Access this submenu to control processor’s power management. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced CPU PPM Configuration Turbo Mode. Turbo Mode [Enabled] : Select Screen : Select Item Enter : Select : Change Opt.

  • Page 74: Chipset

    BIOS 4.3. Chipset Access this Chipset menu to configure the system’s chipset. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Chipset Boot Security Save & Exit Main PCH Parameters PCH-IO Configuration System Agent (SA) Configuration : Select Screen : Select Item Enter : Select...
  • Page 75 BIOS 4.3.1. PCH IO Configuration Access this submenu to configure PCH parameters. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Chipset Intel PCH RC Version 1.2.0.1 PCI Express Configuration Intel PCH SKU Name QM67 settings Intel PCH Rev ID 05/B3 PCI Express Configuration USB Configuration...
  • Page 76 BIOS 4.3.1.1. PCI Express Configuration Access this submenu to configure the system’s PCIe configuration. The featured settings are: Setting Description Configures PCI Express by the following settings: Setting Description PCI Express Enables/disables LAN1 port. PCI Express LAN #1 LAN1 82583 Enabled is the default.
  • Page 77 BIOS 4.3.1.2. USB Configuration Access this submenu to configure the system’s USB ports. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Chipset Control the USB ECHI (USB 2.0) USB Configuration functions. One EHCI controller must always be enabled. EHCI1 [Enabled] EHCI2...
  • Page 78 BIOS 4.3.2. System Agent (SA) Configuration Access this submenu to configure the south bridge. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Chipset System Agent Bridge Name SandyBridge Check to enable VT-d fucntion System Agent RC Version 1.2.0.0 on MCH.
  • Page 79 BIOS 4.3.2.1. Display Control Access this submenu to configure the system’s display feature. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Chipset Display Control Display Control Boot Display [CRT+LVDS] LCD Panel Type [1024x768 Panel] Select Screen Select Item Enter Select Change Opt.
  • Page 80 BIOS 4.3.2.2. Memory Configuration Access this submenu to view the system’s memory information that includes memory RC version, memory frequency, total memory and the presence/ absence of memory module. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Chipset Memory Information Memory RC Version 1.2.0.0...

  • Page 81: Boot

    BIOS 4.4. Boot Access this menu to change system boot settings. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Chipset Boot Security Save & Exit Main Boot Option Priorities Select the keyboard NumLock Bootup NumLock State [On] state Quiet Boot [Disabled]...

  • Page 82: Security

    BIOS Enables/disables the boot option for legacy network devices. Launch PXE OpROM Disabled is the default. Sets the very 1st boot device among the available device types. Boot Option Priority Option(s) available are the available device type(s). 4.5. Security The Security menu sets up the administrator password. Once an administrator password is set up, this BIOS Setup utility is limited to access and will ask for the password each time any access is attempted.

  • Page 83: Save & Exit

    BIOS 4.6. Save & Exit The Exit menu features a handful of commands to launch actions from the BIOS Setup utility regarding saving changes, quitting the utility and recovering defaults. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Chipset Boot...

  • Page 84: Beep Sound Codes List

    BIOS 4.7 Beep Sound codes list 4.7.1 Boot Block Beep Codes Number of Beeps Description Insert diskette in floppy drive A: ‘AMIBOOT.ROM’ file not found in root directory of diskette in A: Flash Programming successful Floppy read error Keyboard controller BAT command failed No Flash EPROM detected Floppy controller failure Boot Block BIOS checksum error...
  • Page 85 BIOS 4.7.3 Troubleshooting POST BIOS Beep Codes Number of Beeps Description Reseat the memory, or replace with known good 1, 2 or 3 modules. Fatal error indicating a serious problem with the system. Consult your system manufacturer. Before declaring the motherboard beyond all hope, eliminate the possibility of interference by a malfunctioning add-in card.

  • Page 86: Ami Bios Checkpoints

    BIOS 4.8 AMI BIOS Checkpoints 4.8.1 Bootblock Initialization Code Checkpoints The Bootblock initialization code sets up the chipset, memory and other components before system memory is available. The following table describes the type of checkpoints that may occur during the bootblock initialization portion of the BIOS (Note) Checkpoint...
  • Page 87 BIOS Both key sequence and OEM specific method is checked to determine if BIOS recovery is forced. If BIOS recovery is necessary, control flows to checkpoint E0. See Bootblock Recovery Code Checkpoints section of document for more information. Restore CPUID value back into register. The Bootblock- Runtime interface module is moved to system memory and control is given to it.
  • Page 88 BIOS 4.8.2 Bootblock Recovery Code Checkpoints The Bootblock recovery code gets control when the BIOS determines that a BIOS recovery needs to occur because the user has forced the update or the BIOS checksum is corrupt. The following table describes the type of checkpoints that may occur during the Bootblock recovery portion of the BIOS (Note) Checkpoint...
  • Page 89 BIOS Erase the flash part. Program the flash part. The flash has been updated successfully. Make flash write disabled. Disable ATAPI hardware. Restore CPUID value back into register. Give control to F000 ROM at F000:FFF0h. - 79 -...
  • Page 90 BIOS 4.8.3 POST Code Checkpoints The POST code checkpoints are the largest set of checkpoints during the BIOS pre-boot process. The following table describes the type of checkpoints that may occur during the POST portion of the BIOS (Note) Checkpoint Description Disable NMI, Parity, video for EGA, and DMA controllers.
  • Page 91 BIOS Early CPU Init Exit Initializes the 8042 compatible Key Board Controller. Detects the presence of PS/2 mouse. Detects the presence of Keyboard in KBC port. Testing and initialization of different Input Devices. Also, update the Kernel Variables. Traps the INT09h vector, so that the POST INT09h handler gets control for IRQ1.
  • Page 92 BIOS Initializes different devices through DIM. See DIM Code Checkpoints section of document for more information. USB controllers are initialized at this point. Initializes DMAC-1 & DMAC-2. Initialize RTC date/time. Test for total memory installed in the system. Also, Check for DEL or ESC keys to limit memory test.
  • Page 93 BIOS Takes care of runtime image preparation for different BIOS modules. Fill the free area in F000h segment with 0FFh. Initializes the Microsoft IRQ Routing Table. Prepares the runtime language module. Disables the system configuration display if needed. Initialize runtime language module. Display boot option popup menu.
  • Page 94 BIOS 4.8.4 DIM Code Checkpoints The Device Initialization Manager (DIM) gets control at various times during BIOS POST to initialize different system busses. The following table describes the main checkpoints where the DIM module is accessed (Note) Checkpoint Description Initialize different buses and perform the following functions: Reset, Detect, and Disable (function 0);...
  • Page 95 BIOS 0 = func#0, disable all devices on the BUS concerned. 1 = func#1, static devices initialization on the BUS concerned. 2 = func#2, output device initialization on the BUS concerned. 3 = func#3, input device initialization on the BUS concerned. 4 = func#4, IPL device initialization on the BUS concerned.
  • Page 96 This page is intentionally left blank. - 86 -...

  • Page 97: Appendix

    Appendix Appendix - 87 -...

  • Page 98: Appendix A: I/O Port Address Map

    Appendix Appendix A: I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device. The following table lists the I/O port addresses used. Address Device Description 0x000003F8-0x000003FF Communications Port (COM1) 0x000002F8-0x000002FF...
  • Page 99 Appendix 0x0000004E-0x0000004F Motherboard resources 0x00000061-0x00000061 Motherboard resources 0x00000063-0x00000063 Motherboard resources 0x00000065-0x00000065 Motherboard resources 0x00000067-0x00000067 Motherboard resources 0x00000092-0x00000092 Motherboard resources 0x000000B2-0x000000B3 Motherboard resources 0x00000680-0x0000069F Motherboard resources 0x00000200-0x0000020F Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x00000400-0x00000453 Motherboard resources 0x00000458-0x0000047F Motherboard resources 0x00000500-0x0000057F Motherboard resources 0x0000164E-0x0000164F...
  • Page 100 Appendix 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x0000F040-0x0000F05F SM Bus Controller 0x0000F0B0-0x0000F0B7 Standard AHCI 1.0 Serial ATA Controller 0x0000F0A0-0x0000F0A3 Standard AHCI 1.0 Serial ATA Controller 0x0000F090-0x0000F097...

  • Page 101: Appendix B: Memory Mapping

    Appendix Appendix B: Memory Mapping Address Device Description 0xF7A00000-0xF7BFFFFF Ethernet Controller 0xF7B00000-0xF7B1FFFF Ethernet Controller 0xF7B20000-0xF7B23FFF Ethernet Controller 0xF7C00000-0xF7C03FFF High Definition Audio Controller 0xFED00000-0xFED003FF High precision event timer 0xF7800000-0xF79FFFFF Intel(R) 82574L Gigabit Network Connection 0xF7940000-0xF795FFFF Intel(R) 82574L Gigabit Network Connection 0xF7960000-0xF7963FFF Intel(R) 82574L Gigabit Network Connection 0xFF000000-0xFFFFFFFF Intel(R) 82802 Firmware Hub Device...
  • Page 102 Appendix 0xF7A00000-0xF7BFFFFF PCI standard PCI-to-PCI bridge 0xF7800000-0xF79FFFFF PCI standard PCI-to-PCI bridge 0xF7C05000-0xF7C050FF SM Bus Controller 0xF7C06000-0xF7C067FF Standard AHCI 1.0 Serial ATA Controller 0xF7C07000-0xF7C073FF Standard Enhanced PCI to USB Host Controller 0xF7C08000-0xF7C083FF Standard Enhanced PCI to USB Host Controller 0xF7400000-0xF77FFFFF Standard VGA Graphics Adapter 0xE0000000-0xEFFFFFFF Standard VGA Graphics Adapter 0xA0000-0xBFFFF...

  • Page 103: Appendix C: Watchdog Timer (Wdt) Setting

    Appendix Appendix C: Watchdog Timer (WDT) Setting WDT is widely applied to industry computers to monitor activities of CPU. The programmed application triggers WDT with adequate timer setting depending on its requirement. Before WDT counts down to zero, the functional system will reset the counter.
