- Page 1 RF-TI1352P1 CC1352P SimpleLink High- Performance Sub-1G + 2.4 G Multi-band Module With Integrated Power Amplifier Version 1.0 Shenzhen RF-star Technology Co., Ltd. May 25 , 2023 All rights reserved. Those responsible for unauthorized reproduction will be prosecuted.
-
Page 2: Device Overview
1.1 Description RF-TI1352P1 is an RF module based on TI SoC CC1352P with integrated power amplifier. It integrates a 48 MHz and a 32.768 kHz crystal, a 256 kB ROM, a 352 kB Flash, and the half-hole antenna pin to guarantee the external antenna connection. -
Page 3: Applications
– wireless keypads • Gaming – electronic and robotic toys communications – Long-range sensor • Wearables (non-medical) – smart trackers, applications • Other alternative energy – energy harvesting smart clothing Shenzhen RF-star Technology Co., Ltd. Page 2 of 20... -
Page 4: Functional Block Diagram
Reset 1.8 V ~ 3.8 V Figure 1. Functional Block Diagram of RF-TI1352P1 1.5 Part Number Conventions The part numbers are of the form of RF-TI1352P1 where the fields are defined as follows: 1352 RF-STAR Module Version The First PA Version... -
Page 5: Table Of Contents
4.6.3 High Bit Error Rate ..........................15 4.7 Electrostatics Discharge Warnings ......................15 4.8 Soldering and Reflow Condition ......................... 15 5 Optional Package Specification ..........................17 6 Revision History ................................19 7 Contact Us ..................................20 Shenzhen RF-star Technology Co., Ltd. Page 4 of 20... -
Page 6: Module Configuration And Functions
RF-TI1352P1 www.szrfstar.com V1.0 - May, 2023 2 Module Configuration and Functions 2.1 Module Parameters Table 1. Parameters of RF-TI1352P1 Chipset CC1352P Supply Power Voltage 1.8 V ~ 3.8 V, 3.3 V is recommended Frequency 800 MHz ~ 928 MHz, 2402 MHz ~ 2480 MHz Maximum Transmit Power +20.0 dBm... -
Page 7: Module Pin Diagram
25.0 mm × 16.4 mm × 2.2 mm Type of Antenna Half-hole ANT interface -40 ℃ ～ +85 ℃ Operating Temperature -40 ℃ ～ +125 ℃ Storage Temperature 2.2 Module Pin Diagram Figure 3. Pin Diagram of RF-TI1352P1 Shenzhen RF-star Technology Co., Ltd. Page 6 of 20... -
Page 8: Pin Functions
RF-TI1352P1 www.szrfstar.com V1.0 - May, 2023 3.3 Pin Functions Table 2. Pin Functions of RF-TI1352P1 Name Chip Pin Function Description DIO5 DIO_5 Digital GPIO, high-drive capability DIO6 DIO_6 Digital GPIO, high-drive capability DIO7 DIO_7 Digital GPIO, high-drive capability DIO8 DIO_8... - Page 9 V1.0 - May, 2023 DIO25 DIO_25 Digital or Analog GPIO, analog capability DIO26 DIO_26 Digital or Analog GPIO, analog capability DIO27 DIO_27 Digital or Analog GPIO, analog capability Ground Ground External ANT pin Shenzhen RF-star Technology Co., Ltd. Page 8 of 20...
-
Page 10: Specifications
Functional operation does not guarantee performance beyond the limits of the conditional parameter values in the table below. Long-term work beyond this limit will affect the reliability of the module more or less. Table 3. Recommended Operating Conditions of RF-TI1352P1 Items Min. -
Page 11: Application, Implementation, And Layout
RF-TI1352P1 www.szrfstar.com V1.0 - May, 2023 4 Application, Implementation, and Layout 4.1 Module Photos Figure 4. Photos of RF-TI1352P1 4.2 Recommended PCB Footprint Figure 5. Recommended PCB Footprint of RF-TI1352P1 Shenzhen RF-star Technology Co., Ltd. Page 10 of 20... -
Page 12: Schematic Diagram
RF-TI1352P1 www.szrfstar.com V1.0 - May, 2023 4.3 Schematic Diagram Figure 6. Schematic Diagram of RF-TI1352P1 4.4 Antenna 4.4.1 Antenna Design Recommendation 1. The antenna installation structure has a great influence on the module performance. It is necessary to ensure that the antenna is exposed and preferably vertically upward. -
Page 13: External Antenna Design Recommendation Of The Half-Hole Ant Pin
The traces are as short as possible, and 135° or arc traces are used as much as possible. No vias are used to change layers. More GND vias are placed around the RF traces. Figure 8. Reference Design of the External Antenna Figure 9. Reference Design of the External Antenna Traces Shenzhen RF-star Technology Co., Ltd. Page 12 of 20... -
Page 14: Basic Operation Of Hardware Design
5. Assuming that the module is soldered or placed in the Top Layer, it is also wrong to randomly route the Bottom Layer or other layers, which will affect the spurs and receiving sensitivity of the module to some degree. Shenzhen RF-star Technology Co., Ltd. Page 13 of 20... -
Page 15: Trouble Shooting
3. Due to some humidity-sensitive components, please ensure the suitable humidity during installation and application. If there is no special demand, it is not recommended to use at too high or too low temperature. Shenzhen RF-star Technology Co., Ltd. Page 14 of 20... -
Page 16: High Bit Error Rate
3. If the extension wire or feeder wire is of poor quality or too long, the bit error rate will be high. 4.7 Electrostatics Discharge Warnings The module will be damaged by the discharge of static. RF-star suggests that all modules should follow the 3 precautions below: 1. - Page 17 RF-TI1352P1 www.szrfstar.com V1.0 - May, 2023 Figure 11. Recommended Reflow for Lead-Free Solder Shenzhen RF-star Technology Co., Ltd. Page 16 of 20...
-
Page 18: Optional Package Specification
The default package method is . If you need the modules to be shipped by tape & reel, pls contact us in advance. Figure 12. Default Package by Tray Shenzhen RF-star Technology Co., Ltd. Page 17 of 20... - Page 19 RF-TI1352P1 www.szrfstar.com V1.0 - May, 2023 Figure 13. Package by Tape & Reel Shenzhen RF-star Technology Co., Ltd. Page 18 of 20...
-
Page 20: Revision History
1. The document will be optimized and updated from time to time. Before using this document, please make sure it is the latest version. 2. To obtain the latest document, please download it from the official website: www.rfstariot.com and www.szrfstar.com. Shenzhen RF-star Technology Co., Ltd. Page 19 of 20... -
Page 21: Contact Us
RF-TI1352P1 www.szrfstar.com V1.0 - May, 2023 7 Contact Us SHENZHEN RF-STAR TECHNOLOGY CO., LTD. Shenzhen HQ: Add.: Room A503, Podium Building No. 12, Shenzhen Bay Science and Technology Ecological Park, Nanshan District, Shenzhen, Guangdong, China, 518063 Tel.: 86-755-8632 9829 Chengdu Branch: Add.: N2-1604, Global Center, North No.
