(F4 ADM continued)
Setting
EDIT PORT To help remember which computer is attached to a particular port,
NAMES every port can be given a name. This function allows the Administrator
to create, modify, or delete port names. To Edit a port name:
1. Click the port you want, or use the Navigation Keys to move the
highlight bar to it, then press [Enter].
2. Key in the new Port Name, or modify/delete the old one. The maxi-
mum number of characters allowed for the Port Name is 12. Legal
characters include:
*Case does not matter; the OSD displays the Port Name in all
capitals no matter how they were keyed in.
3. When you have finished editing, press [Enter] to have the change
take effect. To abort the change, press Esc.
RESTORE This function is used to undo all changes and return the setup to the
DEFAULT original factory default settings (see OSD Factory Default Settings,
VALUES
page 64)
Ports, which are saved.
CLEAR THE This function is similar to Restore Default Values. The difference is that
NAME LIST it also clears the Names settings along with undoing all changes and
returning the setup to the original factory default settings.
ACTIVATE Choices are Y (for Yes), or N (for No). When activated, the beeper
BEEPER sounds whenever a Port is changed, when activating the Auto Scan
function (see F7 SCAN, page 44), or an invalid entry is made on an
OSD menu. The default is Y (activated).
All alpha characters: A–Z*
All numeric characters: 0–9
+ - / : . and Space
—
except for the Names settings that were assigned to the
Chapter 4. OSD Operation
Function
(continues on next page)
