Back View
Ref. Description
U1
ATSAMD11D14A-MUT USB Bridge
U14 AP2112K-3.3TRG1 0.6 A 3.3 V LDO IC
SM05B-SRSS-TB(LF)(SN) 5-pin Eslov
J5
connector
10 / 24
Nicla Sense ME Back View
Ref. Description
U13 NTS0304EUKZ 4-bit translating transceiver IC
3-pin 1.2mm ACH Battery Connector (BM03B-ACHSS-
J4
GAN-TF)
J7
microUSB connector
Arduino® Nicla Sense ME
Arduino® Nicla Sense ME
