156 A
PPENDIX
b Find out the Ethernet address of the network card. In
Windows 95 or 98, this is done by selecting Run from
the Start menu, and then typing
Note down the value in the Adapter Address box (this
may also be known as the MAC address, and consists of
six pairs of Hex digits).
c Return to DHCP Server Setup.
d In the Static IP Address box, type a unique address for
the syslog server PC, for example,
e In the Ethernet Address box, type the adapter address
value that you noted in step b, separating each pair of
digits with a colon, for example,
Click Update.
11 Set up the logging features.
a Click Log and select the Log/Alert Settings tab.
b In the Syslog Server box, type
not need to change any other settings. Click Update.
12 Set up the web filtering so that users of the network can
only access addresses on the domain 3Com.com.
a Click Filter, and then select the Custom List tab.
b In the Trusted Domains area, Add Domain box, type
3com.com.
c Make sure that the Disable all web traffic except for
Trusted Domains check box is selected and then click
Update.
d To make that users can only access the 3com.com
domain, select the Settings tab, and then make sure
that the Log and Block Access option is checked. Click
Update.
13 Restart the Internet Firewall 25 as described in step 8.
a You must also restart all the PCs on the network so that
the Internet Firewall 25 can assign IP addresses to the
PCs. The Internet Firewall 25 can also assign an IP
address dynamically to the management PC. If you want
to find out what IP address has been assigned to a PC,
use
E: E C
XAMPLE ONFIGURATIONS
as described in step 10.
winipcfg
.
winipcfg
192.168.1.230
12:34:56:78:90:AB
192.168.1.230
.
.
. You do
