Static Routes

If the LAN has internal routers, you must specify their
addresses and network information.
Click Advanced and then select the Static Routes tab. A
window similar to that in
Figure 50 Static Routes Window
Use static routes if the LAN is segmented into subnets,
either for size or practical considerations. For example, you
can create a subnet which only contains an organization's
graphic design shop, isolating it from traffic on the rest of
the LAN.

Static Routes Window Boxes and Controls

I
LAN
The IP Address and Subnet on the Internet Firewall's
LAN port are shown at the top of the window.
Configure these in the Network Settings window (see
Figure 16).
Static Routes
Figure 50 is displayed.
117
