3Com OfficeConnect 3C16771 User Manual page 119

.
Table 4 Address Correspondence in One-to-One NAT
LAN Address
192.168.1.1
192.168.1.2
[...]
192.168.1.16
192.168.1.33
[...]
192.168.1.255
You cannot include the NAT Public IP Address in a range.
Click Advanced, and then select the One-to-One NAT tab.
A window similar to that in
Figure 51 One-to-One NAT Window
Corresponding WAN Address
209.19.28.16
209.19.28.17
[...]
209.19.28.31
No corresponding valid IP
address
[...]
No corresponding valid IP
address
Setting up One-to-One NAT
Accessed Through
Inaccessible: NAT Public IP
Address
Accessed at 209.19.28.17
[...]
Accessed at 209.19.28.31
Inaccessible except as Public
LAN Server
[...]
Inaccessible except as Public
LAN Server
Figure 51 is displayed.
119
