Protecting an Existing Network with the Internet Firewall 25
subscription). This enables your Web Site filter
subscription.
12 Enter the registration code.
a Load management interface again and log in as
described in step 4, except use the new Web address
you assigned to the Internet Firewall
http://172.16.54.16, and the new password that
you set.
b On the Home screen, select Unit Status. The status
screen displays a message stating that the Internet
Firewall 25 is not registered.
c Enter the registration code into this text box, and click
Update. The Internet Firewall 25 is now registered.
13 Obtain the IP address of the mail server.
The Internet Firewall 25 needs the IP address of the mail
server to send out logs and alerts. To find out the IP
address:
a Click Network on the button bar and select the
Diagnostics tab.
b From the drop down list, select DNS Name Lookup.
c When the page has reloaded, in the text box, type the
address of the mailserver, (in this example,
mail.3com.com
d When the IP address of the mail server is displayed,
make a note of it.
14 Set up the logging features.
a Click Log and then select the Log/Alert Settings tab.
b Type the IP address you have noted in the Mail Server
field.
c Type the e-mail addresses you want the logs to be sent
to in the Send log to box, and the Send alerts to box.
You can use the same e-mail addresses. Use the full
e-mail address; for example:
system_administrator@3com.com.
d Click Update when you have finished. The return
address,
,) and click Go.
log@InternetFirewall ,
145
simply identifies the
