Thermo Scientifi c F1-ClipTip
Single Channel
Multichannel
Instructions for Use
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F1-ClipTip and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Thermo Scientific F1-ClipTip

Summary of Contents for Thermo Scientific F1-ClipTip

  • Page 1 Thermo Scientifi c F1-ClipTip Single Channel Multichannel Instructions for Use...
  • Page 2 The CE mark covers the system containing the CE marked F1-ClipTip pipette and the CE marked ClipTip pipette tips. Product specifi cations are subject to change without prior notice. ClipTip is a registered...

  • Page 3: Table Of Contents

    CONTENTS 1. INTRODUCTION 2. PACKAGE 3. MAIN ILLUSTRATION 4. SAFETY 5. OPERATION 6. CALIBRATION AND ADJUSTMENT 7. MAINTENANCE 8. STERILIZATION 9. TROUBLESHOOTING 10. APPENDICES...

  • Page 4: Introduction

    For improved ergonomics, tips are attached and ejected using minimal application pressure. The F1-ClipTip product offering covers a volume range from 1 μl to 1000 μl and includes variable and fi xed volume single channel pipettes as well as multichannel pipettes. The convenient color coding* system facilitates to identify the correct ClipTip by volume for use.

  • Page 5: Package

    2. Package The F1-ClipTip package contains the following items: F1-ClipTip pipette Service tool Multichannel service tool Tip fi tting tool ClipTip tip sample Tube of grease (Order No. 2203130) Instructions for Use Calibration certifi cate / Warranty Certifi cate Shelf hanger (Order No. 2206040) 10.

  • Page 6: Safety

    The F1-ClipTip is to be used by trained personnel with required laboratory skills. The instructions for use must be read prior to and during the use of the device (pipette and tip). The F1-ClipTip pipette can be used between +4°C and +40°C.

  • Page 7: Operation

    Incorrect dispensing results Performance may vary due to: a. pipetting method (forward pipetting technique recommended) b. temperature (air, liquid, vessel, pipette, and tip) c. pressure d. humidity e. operator, e.g. thumb movement, pipetting angle f. liquid density, viscosity and vapor pressure g.
  • Page 8 Ensure proper functioning of F1-ClipTip 1-10μl multichannel and 1-50 μl single channel pipettes The F1-ClipTip 1-10μl multichannel and 1-50 μl single channel pipettes utilize an innovative super blow-out piston technology to ensure effi cient liquid delivery with small volumes. In pipettes with...

  • Page 9: Calibration And Adjustment

    6. Calibration and Adjustment 6.1 Factory calibration limits F1-ClipTip pipettes are factory calibrated and adjusted to give the volumes as specifi ed with distilled or deionized water using the forward pipetting technique. Manufacturer specifi cations are shown on the pipette calibration certifi cate and in Appendix 2.
  • Page 10 6.3 Procedure to check calibration The pipette is checked at maximum volume (nominal volume) and minimum volume. A new tip is fi rst pre-wetted three to fi ve times and a series of ten pipettings is done at both volumes. A pipette is always adjusted according to the delivery of the selected volume.

  • Page 11: Maintenance

    If the pipette is used daily, it is recommended to service the pipette every three months. When the F1-ClipTip is not in use, make sure it is stored in an upright position. We recommend a pipette stand for this purpose.
  • Page 12 2. Press the tip ejector 4.1. Rotate the tip ejector 10 counterclockwise and pull it out (Picture 11). 3. Turn the tip cone 11 counterclockwise with the service tool 1. There are two slots in the service tool: the smaller one for pipettes under 300 μl and the bigger one for pipettes over 300 μl.
  • Page 13 7.2.3 Cleaning and reassembling single channel pipettes General maintenance instructions can be found on page 11. Clean the piston, the piston spring and the O-rings with a dry napless cloth. Check the tip cone for foreign particles or dirt. Immerse it in a suitable cleaning solution. Dry before assembly.
  • Page 14 7.2.4 Reassembly of tip fi tting 5 and O-rings 5.1 and 5.2 Make sure that the tip fi tting has both o-rings 5.1 and 5.2 in place (Picture 8). Change o-rings during maintenance if needed. Place the tip fi tting onto the star-shaped end of tool 3 so that the screw end is facing upwards.
  • Page 15 7. While the tip ejector 23 is in the down position, open its upper end slightly on both sides and pull downwards. Remove the fastening spring 22. Remove the ejector link 24. Press the piston bar 16 beam into the down position. Finally unfasten the four screws 20/21 and the tip ejector. The ejector slide 25 and two springs 26 can be removed for maintenance.

  • Page 16: Sterilization

    7.2.7 Cleaning and reassembling multichannel pipettes See the cleaning instructions in Section 7.2.2 “Single channel pipettes”. Check the volume-specifi c reassembling of the piston assemblies starting on page 23. The pipette is assembled in the reverse order to disassembling. Note that the ejector link 24 must be in the down position simultaneously with the tip ejector 23 (page 25).

  • Page 17: Troubleshooting

    9. Troubleshooting The table below lists possible problems and their solutions. Defect Possible reason Possible action ►Re-attach/tighten the tip fi tting Leakage • Tip fi tting incorrectly attached or loose or replace with new tip fi tting(s) using the tool. ►Discard the tip.

  • Page 18: Appendices

    10. Appendices Appendix 1. Conversion table Value of the conversion factor Z (μl/mg), as a function of temperature and pressure, for distilled water. Temperature Air pressure °C 101.3 15.0 1.0017 1.0018 1.0019 1.0019 1.0020 1.0020 1.0020 15.5 1.0018 1.0019 1.0019 1.0020 1.0020 1.0020...
  • Page 19 Appendix 2. Manufacturer specifi cation limits Thermo Scientifi c F1-ClipTip Variable Volume Single Channel Compatible Order No. Range Volume Inaccuracy Imprecision ClipTip µl µl SD µl 4641170 1–10 µl ±0.100 ±1.00 0.050 0.50 ±0.025 ±2.50 0.020 2.00 4641180 2–20 µl ±0.20...
  • Page 20 Thermo Scientifi c F1-ClipTip Variable Volume Multichannel Compatible Order No. Range Channel Volume Inaccuracy Imprecision ClipTip µl µl SD µl 4661110 1–10 µl ±0.240 ±2.40 0.160 1.60 ±0.120 ±12.00 0.080 8.00 4661120 5–50 µl ±0.75 ±1.50 0.35 0.70 ±0.25 ±5.00 0.10...
  • Page 21 Appendix 3. ISO8655 calibration specifi cations Thermo Scientifi c F1-ClipTip specifi cations according to ISO8655 standard. Thermo Scientifi c F1-ClipTip Variable Volume Single Channel Compatible Range Volume Inaccuracy Imprecision ClipTip Color code µl µl SD µl 1–10 µl ±0.120 ±1.2 0.080...
  • Page 22 Appendix 4. Assembly and spare parts * Available as a spare part. See model specifi c order numbers on page 27. 1062930 1062800 Service and Multichannel service tool adjustment tool 0300070 Tip fitting tool * 5. Tip fitting * 42. Tip cone assembly * 50.
  • Page 23 1–10μl 2–20μl 5–50μl 10 μl Fixed 20 μl Fixed 25 / 50 μl Fixed 1–300μl 5.2* 5.1*...
  • Page 24 100–1000μl 20–200μl 30–300μl 500 / 1000 μl Fixed 100 / 200 μl Fixed 10–100μl 1–300μl 250μl Fixed 5.2* 5.2* 5.1* 5.1*...
  • Page 25 * 50 5.2* 5.1*...
  • Page 26 5.2* 5.1*...
  • Page 27 F1-ClipTip single channel and multichannel spare part order numbers Single Channel 1–10μl / 10μl Fixed 30–300μl / 250μl Fixed 2216160 4 pcs 2216160 4 pcs 5.1. 2214930 3 pcs 5.1. 2214930 3 pcs 5.2. 1033430 5.2. 1033430 1030380 1033330 1030060...
  • Page 28 Appendix 5. ClipTip ordering information Thermo Scientifi c ClipTip racked and sterile tips Code ClipTip Volume 94410210 ClipTip 20 20 μl 10x96/rack 94410213 ClipTip 20, sterile 20 μl 10x96/rack 94410250 ClipTip 50 50 μl 10x96/rack 94410253 ClipTip 50, sterile 50 μl 10x96/rack 94410310 ClipTip 200...
  • Page 29 Appendix 6. F1-ClipTip and ClipTip compatibility table Non filter tips Filter tips F1 ClipTip 1 10 l F1 ClipTip 2 20 l F1 ClipTip 5 50 l F1 ClipTip 10 100 l F1 ClipTip 20 200 l F1 ClipTip 30 300 l...
  • Page 30 Appendix 7. Pipette accessories Multichannel stand F–stand #9420390 #9420400 Reagent reservoir 100 ml #95128085 Reagent reservoir 25 ml #95128093 Reagent reservoir 25 ml divided #951228095...
  • Page 31 info.pipettes@thermofi sher.com www.thermofi sher.com thermofisher.com © 2016 Thermo Fisher Scientifi c Inc. All rights reserved. All trademarks are the property of Thermo Fisher Scientifi c Inc. and its subsidiaries. Specifi cations, terms and pricing are subject to change. Not all products are available in all countries.
