Worksaver EPFC-1 Owner's/Operator's Manual

Electric pallet fork clamp for tractor front loaders
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S /
OPERATOR'S
MANUAL
MODEL NO.
MODEL NO.'s
ESCG-48S
EPFC-1
ESCG-48JD
CAUTION
For Safe Operation
Read Rules And
Instructions Carefully
SI NO LEEINGLES, PIDA AYUDA
A AIGUIEN QUE SI LO LEA
PARA QUE LE TRADUZCA LAS
MEDIDAS DE SEGURIDAD.
THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD
1. Select an area for assembly that is clean and free of any
debris which might cause persons working on the
assembly to trip.
2. Do not lift heavy parts or assemblies. Use crane, jack,
tackle, fork trucks or other mechanical devices.
3. Preview the assembly instructions in your operator's
manual before proceeding further.
4. If the assembly instructions call for parts or assemblies to
be blocked up, use only blocking material that is in good
condition and is capable of handling the weight of the
assembly to be blocked. Also insure that the blocking
material is on a clean, dry surface.
5. Never put hands, or any part of body, under blocked up
assemblies if at all possible.
Electric Grapple Rake
Electric PALLET FORK
Tractor Front Loaders
Tractor Front Loaders
Safety Instructions
Tractor Preparation
Operating Instructions
CAUTION
BEFORE ATTEMPTING TO BEGIN ASSEMBLING THIS MACHINE
CLAMP for
for Sub-Compact
6. After completing assembly, thoroughly inspect the
machine to be sure that all nuts, bolts, hydraulic fittings
or any other fastened assemblies have been thoroughly
tightened.
7. Before operating the machine, thoroughly read the
operation section of your operator's manual.
8. Before operating, read the maintenance section of your
operator's manual to be sure that any parts requiring
lubrication, such as gearboxes, are full, to avoid any
possible damage.
9. Before operating equipment – If you have any
questions regarding the proper assembly or
operation, contact your dealer or representative.
Assembly & Mounting
Maintenance
Repair Parts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EPFC-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Worksaver EPFC-1

Summary of Contents for Worksaver EPFC-1

  • Page 1 OWNER’S / OPERATOR’S MANUAL MODEL NO. MODEL NO.’s ESCG-48S EPFC-1 ESCG-48JD CAUTION Electric Grapple Rake Electric PALLET FORK For Safe Operation CLAMP for for Sub-Compact Read Rules And Instructions Carefully Tractor Front Loaders Tractor Front Loaders SI NO LEEINGLES, PIDA AYUDA Safety Instructions Assembly &...

  • Page 2: Table Of Contents

    Like all mechanical products, it will require cleaning and upkeep. Use only genuine Worksaver, Inc. service parts. Substitute parts will void the warranty and may not meet Use only genuine Worksaver, Inc. service parts. Substitute parts will void the warranty and may not meet standards required for safe and satisfactory operation.

  • Page 3: Warranty

    2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Worksaver have been used in connection with the unit, if, in sole judge- ment of Worksaver such use affects its performance, stability, or reliability.

  • Page 4: Safety Information

    To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded opera- tor who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.
  • Page 5 SAFETY INSTRUCTIONS (continued) EQUIPMENT SAFETY GUIDELINES Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
  • Page 6 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY Start tractor only when properly seated in the tractor seat. Starting a tractor in gear can result in injury or death. Do not mount or dismount the tractor while the tractor is moving. Mount or dismount the tractor only when the tractor and all moving parts are completely stopped.
  • Page 7 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) Check that this attachment is securely mounted to the loader. Failure to install lock pins or have the latching mechanism engage could result in injury or death. Do not allow children or others to ride on the power unit with an operator. Riders are subject to injury such as being struck by foreign objects or being thrown off.
  • Page 8 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) When maneuvering close to buildings or passing through narrow areas, be sure to allow sufficient clearance for the power unit, loader, and load. Drive slowly. Allow for additional length of loader and load on power unit while turning.
  • Page 9 SAFETY INSTRUCTIONS (continued) TRANSPORT SAFETY Comply with state and local laws governing highway safety and movement of farm machinery on public roads. The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use. Local laws should be checked for all highway lighting and marking requirements. When driving the tractor and equipment on the road or highway under 20 mph (32 kph) at night or during the day, use flashing amber warning lights and a slow moving vehicle (SMV) identification emblem.
  • Page 10 SAFETY INSTRUCTIONS (continued) MAINTENANCE SAFETY Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. Before working on this machine, drive to a level area, disengage the PTO, lower implement or loader (or if working underneath, raise and block securely), shut off the engine, relieve all hydraulic pressure, set the brakes, and remove the ignition keys.

  • Page 11: Safety Signs

    SAFETY INSTRUCTIONS (continued) STORAGE SAFETY Following operation, or when unhooking, stop the tractor, set the brakes, lower loader, disengage the PTO, shut off the engine and remove the ignition keys. Use extreme care to keep feet and hands from under the unit and clear of any pinch points. Never stand or allow another person to stand between a running tractor and the unit when disconnecting the implement from the tractor.
  • Page 12 SAFETY & INSTRUCTIONAL DECALS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Replace Immediately If Damaged! 1 –– –– 3 4 –– –– 6 – 5 2 – Use a clean, damp cloth to clean safety decals. Avoid spraying too close to decals when using a pressure washer; high-pressure water can enter through very small scratches or under edges of decals causing them to peel or come off.
  • Page 13 SAFETY SIGN LOCATION ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Replace Immediately If Damaged! NOTE: Safety Sign location is similar on all models. - for Models AV20H AV20E only Ref. Part No. Description Req’d. 5WS101122 Safety Sign - Warning (High Pressure) Ref.

  • Page 14: Instructions

    The operator is responsible for the safe operation of this grip and hold the material. REQUIREMENTS AND The model EPFC-1 Pallet Fork Clamp is designed to fit equipment. The operator must be properly trained. A heavy load can cause instability in driving a The Electric Compact Tractor Grapple Rake is available Class I Pallet Forks.
  • Page 15 Route the power cable up the right-hand side of the front loader arm and toward the loader control joystick. Allow some slack in the power cable at the front of the cable INSTRUCTIONS loader to allow the grapple to tilt forward and back with- tione (continued) out putting tension on the power cable.
  • Page 16 Excess cable coiled and fastened with plastic tie straps PHOTO E Locate the switch on the loader control rod (or joystick) so that you can easily operate the switch with an INSTRUCTIONS Excess cable coiled and fastened with plastic tie straps (continued) extended finger as you also control the loader.
  • Page 17 When you hear the clicking or chattering sound, the 12-volt industrial actuator with actuator is at the end of its stroke or has encountered an 8-inch stroke, slip clutch protected INSTRUCTIONS object that prevents further movement, pressing the (continued) other switch will make the actuator move in the opposite PRE-OPERATION direction.
  • Page 18 INSTRUCTIONS (continued) LOCKING / UNLOCKING CLAMP WIRING (continued) Route the opposite end of the cable and wires so they will not be pinched or where moving parts can rub against them. Locate the battery on the tractor and remove the cover LOCKING THE CLAMP UNLOCKING THE CLAMP or guarding so you have access to the battery terminals.

  • Page 19: Operating Instructions

    OPERATING INSTRUCTIONS INSTRUCTIONS OPERATION OPERATION TRACTOR AND FRONT LOADER The operator is responsible for the safe operation of this REQUIREMENTS AND equipment. The operator must be properly trained. PREPARATION Operators should be familiar with the tractor, loader and loader attachment, and all safety practices before start- WARNING Safety is a primary concern in the design and ing operation.

  • Page 20: Operating Instructions

    OPERATING INSTRUCTIONS INSTRUCTIONS (continued) Operation Cont’d Lower the load and open the clamp. Back away TRACTOR AND FRONT LOADER 8. Lower the load and open the grapple. Back away The operator is responsible for the safe operation of this WARNING until the fork tines are clear of the load.
  • Page 21 OPERATING INSTRUCTIONS INSTRUCTIONS (continued) Operation Cont’d TRACTOR AND FRONT LOADER The operator is responsible for the safe operation of this OPERATE LOADER SAFELY REQUIREMENTS AND equipment. The operator must be properly trained. • During transportation, keep the fork tines level, PREPARATION Operators should be familiar with the tractor, loader and •...
  • Page 22 OWNER SERVICE OWNER SERVICE OWNER SERVICE INSTRUCTIONS CLEANING THE PALLET FORK CLAMP TRACTOR AND FRONT LOADER CLEANING THE GRAPPLE CLEANING THE GRAPPLE The operator is responsible for the safe operation of this WARNING WARNING REQUIREMENTS AND equipment. The operator must be properly trained. OWNER SERVICE At the end of the working season or when the clamp will At the end of the working season or when the Grapple At the end of the working season or when the Grapple...

  • Page 23: Trouble-Shooting Guide

    TROUBLE-SHOOTING GUIDE PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Pallet Fork Grapple Rake 1. Bad connection. Check all connections to make sure they clamp will not clamp will not are clean and tight. operate. operate. 2. Blown fuse. Check fuse and replace if necessary. 3. Tractor battery is low or dead. Charge battery.

  • Page 24: Trouble-Shooting Guide

    TROUBLE-SHOOTING GUIDE (continued) PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Excessive rear 1. Tractor too small. Reduce amount handled. tractor tire slip- page. 2. Insufficient traction. Add rear tire weights or add ballast in tire. Use tractor with FWDA. Attach heavy implement on rear of trac- tor for counter weight.
  • Page 25 ELECTRIC PALLET FORK CLAMP PARTS...
  • Page 26 ELECTRIC PALLET FORK CLAMP PARTS (Model EPFC-1) 2500050...

  • Page 27: Wiring Diagram / Parts List

    WIRING DIAGRAM WIRING DIAGRAM Model EPFC-1 Electric Clamp Parts Drawing Model ESCG-48 Electric Grapple Parts Drawing...

  • Page 28: Wiring Diagram / Parts List

    WIRING DIAGRAM WIRING DIAGRAM Model EPFC-1 Electric Clamp Parts List Model ESCG-48 Electric Grapple Parts List NS = Not Shown on page 25 2505844 – Mounting Bracket 2507036 – Switch Enclosure / Wiring Connector Parts used as of 1/1/2022 2505834 – Actuator 2507037 – Wiring, FET Board, 2507038 –...
  • Page 29 This Page left Intentionally Blank...
  • Page 30 This Page left Intentionally Blank...
  • Page 31 This Page left Intentionally Blank...
  • Page 32 2. PART DESCRIPTION MODEL NO. 3. MODEL NUMBER 4. NAME OF ITEM ESCG-48S EPFC-1 ESCG-48JD MAKE EVERY DAY A HOLIDAY WS-EPF001-OG FROM ACCIDENTS! April 2024 MAY 2023 WORKSAVER, INC. P.O. BOX 100 LITCHFIELD, IL 62056-0100 (217) 324-5973 WEB: http:// www.worksaver.com E-MAIL: sales@worksaver.com WS-TA015-OG...
