OWNER'S /
OPERATOR'S
MANUAL
MODEL NO.'s
ESCG-48S
ESCG-48JD
CAUTION
For Safe Operation
Read Rules And
Instructions Carefully
SI NO LEEINGLES, PIDA AYUDA
A AIGUIEN QUE SI LO LEA
PARA QUE LE TRADUZCA LAS
MEDIDAS DE SEGURIDAD.
THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD
1. Select an area for assembly that is clean and free of any
debris which might cause persons working on the
assembly to trip.
2. Do not lift heavy parts or assemblies. Use crane, jack,
tackle, fork trucks or other mechanical devices.
3. Preview the assembly instructions in your operator's
manual before proceeding further.
4. If the assembly instructions call for parts or assemblies to
be blocked up, use only blocking material that is in good
condition and is capable of handling the weight of the
assembly to be blocked. Also insure that the blocking
material is on a clean, dry surface.
5. Never put hands, or any part of body, under blocked up
assemblies if at all possible.
Electric Grapple Rake
Tractor Front Loaders
Safety Instructions
Tractor Preparation
Operating Instructions
CAUTION
BEFORE ATTEMPTING TO BEGIN ASSEMBLING THIS MACHINE
for Sub-Compact
6. After completing assembly, thoroughly inspect the
machine to be sure that all nuts, bolts, hydraulic fittings
or any other fastened assemblies have been thoroughly
tightened.
7. Before operating the machine, thoroughly read the
operation section of your operator's manual.
8. Before operating, read the maintenance section of your
operator's manual to be sure that any parts requiring
lubrication, such as gearboxes, are full, to avoid any
possible damage.
9. Before operating equipment – If you have any
questions regarding the proper assembly or
operation, contact your dealer or representative.
Assembly & Mounting
Maintenance
Repair Parts
Advertisement
Table of Contents
Related Manuals for Worksaver ESCG-48S
Summary of Contents for Worksaver ESCG-48S
- Page 1 OWNER’S / OPERATOR’S MANUAL MODEL NO.’s ESCG-48S ESCG-48JD CAUTION Electric Grapple Rake For Safe Operation for Sub-Compact Read Rules And Instructions Carefully Tractor Front Loaders SI NO LEEINGLES, PIDA AYUDA Safety Instructions Assembly & Mounting A AIGUIEN QUE SI LO LEA...
-
Page 2: Table Of Contents
Like all mechanical products, it will require cleaning and upkeep. Use only genuine Worksaver, Inc. service parts. Substitute parts will void the warranty and may not meet standards required for safe and satisfactory operation. Record the model and serial number of your Grapple Rake... -
Page 3: Warranty
2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Worksaver have been used in connection with the unit, if, in sole judge- ment of Worksaver such use affects its performance, stability, or reliability. -
Page 4: Safety Information
To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded opera- tor who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and shown in your manual. - Page 5 SAFETY INSTRUCTIONS (continued) EQUIPMENT SAFETY GUIDELINES Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
- Page 6 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY Start tractor only when properly seated in the tractor seat. Starting a tractor in gear can result in injury or death. Do not mount or dismount the tractor while the tractor is moving. Mount or dismount the tractor only when the tractor and all moving parts are completely stopped.
- Page 7 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) Check that this attachment is securely mounted to the loader. Failure to install lock pins or have the latching mechanism engage could result in injury or death. Do not allow children or others to ride on the power unit with an operator. Riders are subject to injury such as being struck by foreign objects or being thrown off.
- Page 8 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) When maneuvering close to buildings or passing through narrow areas, be sure to allow sufficient clearance for the power unit, loader, and load. Drive slowly. Allow for additional length of loader and load on power unit while turning.
- Page 9 SAFETY INSTRUCTIONS (continued) TRANSPORT SAFETY Comply with state and local laws governing highway safety and movement of farm machinery on public roads. The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use. Local laws should be checked for all highway lighting and marking requirements. When driving the tractor and equipment on the road or highway under 20 mph (32 kph) at night or during the day, use flashing amber warning lights and a slow moving vehicle (SMV) identification emblem.
- Page 10 SAFETY INSTRUCTIONS (continued) MAINTENANCE SAFETY Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. Before working on this machine, drive to a level area, disengage the PTO, lower implement or loader (or if working underneath, raise and block securely), shut off the engine, relieve all hydraulic pressure, set the brakes, and remove the ignition keys.
- Page 11 SAFETY INSTRUCTIONS (continued) STORAGE SAFETY Following operation, or when unhooking, stop the tractor, set the brakes, disengage the PTO, shut off the engine and remove the ignition keys. Use extreme care to keep feet and hands from under the unit and clear of any pinch points. Never stand or allow another person to stand between a running tractor and the unit when disconnecting the implement from the tractor.
-
Page 12: Safety Signs
Above Safety Sign ONLY for Models ESCG-48JD REMEMBER: If Safety Signs have been damaged, removed, become illegible or parts replaced without Signs, new Safety Signs must be applied. New Safety Signs are available from your authorized distributor or factory. For Model ESCG-48S only... -
Page 13: Preparation Instructions
The Electric Compact Tractor Grapple Rake is available power unit. Make sure the rear of the tractor is in two models. The models ESCG-48S and ESCG-48JD properly counterbalanced with weights. Always drive are designed to mount on tractor front-end loaders only. - Page 14 INSTRUCTIONS (continued) WIRING (continued) Route the opposite end of the cable and wires so they will not be pinched or where moving parts can rub against them. Locate the battery on the tractor and remove the cover or guarding so you have access to the battery terminals. Route the cable to the loader control lever.
- Page 15 INSTRUCTIONS (continued) WIRING PRE-OPERATION (continued) If the electric power cable provided is too long – coil it When the electric cable is installed, try the rocker up and fasten it to the loader with a plastic tie strap. (See switch to operate the electric actuator. Open and close photos E &...
- Page 16 INSTRUCTIONS (continued) Examples of Wiring of Electric Sub-Compact Grapple...
-
Page 17: Skid Steer Type Mounting
INSTRUCTIONS (continued) MODEL ESCG-48S ATTACHMENT TO PRIME MOVER —————————————————— WARNING Improper attachment of the Grapple Rake could result in injury or death. Do not operate this product until you have positive indication that the attachment is securely mounted. 1. Position the attachment on a level surface. -
Page 18: John Deer Mounting
INSTRUCTIONS (continued) MODEL ESCG-48JD 8. Carefully raise the loader and cycle the rollback/tilt ATTACHMENT TO PRIME MOVER cylinders to check clearances and to ensure that the —————————————————— attachment is securely mounted. The grapple model ESCG-48JD is specifically designed for John Deere 100, 200, and 3E series loaders. NOTE: Procedure is the same for all attachments. -
Page 19: Operating Instructions
OPERATING INSTRUCTIONS PRE-OPERATION CHECKLIST SAFETY INSTRUCTIONS Observe all instruction and safety decals on the (OWNER/OPERATOR RESPONSIBILITY) Grapple Rake. These safety signs are shown for reference. Read them carefully before using the Grapple ____ Review and follow safety rules and safety signs on pages 3 through 11. - Page 20 OPERATING INSTRUCTIONS (continued) HANDLING MATERIAL Grapple Rake Limitations (continued) Approach the material to be handled with the grapple complete burning and final land clearing. The rake frame clamp open, when the rake frame contacts the material, is not designed to bulldoze out stumps or buried rocks. DO NOT turn when tines are in ground.
-
Page 21: Owner Maintenance
OWNER SERVICE CLEANING THE GRAPPLE WARNING At the end of the working season or when the Grapple ■ Do not operate this product until you have posi- Rake will not be used for a long period, it is good practice tive indication that this attachment is securely to clean off any dirt or grease that may have accumulated. -
Page 22: Trouble-Shooting Guide
TROUBLE-SHOOTING GUIDE PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Grapple Rake 1. Bad connection. Check all connections to make sure they clamp will not are clean and tight. operate. 2. Blown fuse. Check fuse and replace if necessary. 3. Tractor battery is low or dead. Charge battery. - Page 23 TROUBLE-SHOOTING GUIDE (continued) PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Excessive rear 1. Tractor too small. Reduce amount handled. tractor tire slip- page. 2. Insufficient traction. Add rear tire weights or add ballast in tire. Use tractor with FWDA. Attach heavy implement on rear of trac- tor for counter weight.
-
Page 24: Parts Lists
SUB-COMPACT TRACTOR FRONT LOADER GRAPPLE Models ESCG-48S & ESCG-48JD Parts Drawing... - Page 25 SUB-COMPACT TRACTOR FRONT LOADER GRAPPLE Models ESCG-48S & ESCG-48JD Parts List...
-
Page 26: Wiring Diagram / Parts List
WIRING DIAGRAM Model ESCG-48 Electric Grapple Parts Drawing... - Page 27 WIRING DIAGRAM Model ESCG-48 Electric Grapple Parts List...
- Page 28 1. PART NUMBER MODEL NO.’s 2. PART DESCRIPTION 3. MODEL NUMBER 4. NAME OF ITEM ESCG-48S ESCG-48JD MAKE EVERY DAY A HOLIDAY FROM ACCIDENTS! APRIL 2020 WORKSAVER, INC. P.O. BOX 100 LITCHFIELD, IL 62056-0100 (217) 324-5973 WEB: http:// www.worksaver.com E-MAIL: sales@worksaver.com WS-TA015-OG...
