OWNER'S /

OPERATOR'S

MANUAL

MODEL NO.'s

FLGR-4062

FLGR-4062S

CAUTION

For Safe Operation

Read Rules And

Instructions Carefully

SI NO LEEINGLES, PIDA AYUDA

A AIGUIEN QUE SI LO LEA

PARA QUE LE TRADUZCA LAS

MEDIDAS DE SEGURIDAD.

THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD

1. Select an area for assembly that is clean and free of any

debris which might cause persons working on the

assembly to trip.

2. Do not lift heavy parts or assemblies. Use crane, jack,

tackle, fork trucks or other mechanical devices.

3. Preview the assembly instructions in your operator's

manual before proceeding further.

4. If the assembly instructions call for parts or assemblies to

be blocked up, use only blocking material that is in good

condition and is capable of handling the weight of the

assembly to be blocked. Also insure that the blocking

material is on a clean, dry surface.

5. Never put hands, or any part of body, under blocked up

assemblies if at all possible.

for Compact Tractor

Safety Instructions

Tractor Preparation

Operating Instructions

CAUTION

BEFORE ATTEMPTING TO BEGIN ASSEMBLING THIS MACHINE

Grapple Rake

Front Loaders

6. After completing assembly, thoroughly inspect the

machine to be sure that all nuts, bolts, hydraulic fittings

or any other fastened assemblies have been thoroughly

tightened.

7. Before operating the machine, thoroughly read the

operation section of your operator's manual.

8. Before operating, read the maintenance section of your

operator's manual to be sure that any parts requiring

lubrication, such as gearboxes, are full, to avoid any

possible damage.

9. Before operating equipment – If you have any

questions regarding the proper assembly or

operation, contact your dealer or representative.

Assembly & Mounting

Maintenance

Repair Parts

Table of Contents

Need help?

Do you have a question about the FLGR-4062 and is the answer not in the manual?

Questions and answers

Summary of Contents for Worksaver FLGR-4062

Page 1 OWNER’S / OPERATOR’S MANUAL MODEL NO.’s FLGR-4062 FLGR-4062S Grapple Rake CAUTION For Safe Operation for Compact Tractor Read Rules And Instructions Carefully Front Loaders SI NO LEEINGLES, PIDA AYUDA Safety Instructions Assembly & Mounting A AIGUIEN QUE SI LO LEA...
Page 2: Table Of Contents
Like all mechanical products, it will require cleaning and upkeep. Use only genuine Worksaver, Inc. service parts. Substitute parts will void the warranty and may not meet standards required for safe and satisfactory operation. Record the model and serial number of your Grapple Rake...
Page 3: Warranty
2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Worksaver have been used in connection with the unit, if, in sole judge- ment of Worksaver such use affects its performance, stability, or reliability.
Page 4: Safety Information
To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded opera- tor who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.
Page 5 SAFETY INSTRUCTIONS (continued) EQUIPMENT SAFETY GUIDELINES Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
Page 6 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY Start tractor only when properly seated in the tractor seat. Starting a tractor in gear can result in injury or death. Do not mount or dismount the tractor while the tractor is moving. Mount or dismount the tractor only when the tractor and all moving parts are completely stopped.
Page 7 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) Check that this attachment is securely mounted to the loader. Failure to install lock pins or have the latching mechanism engage could result in injury or death. Do not allow children or others to ride on the power unit with an operator. Riders are subject to injury such as being struck by foreign objects or being thrown off.
Page 8 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) When maneuvering close to buildings or passing through narrow areas, be sure to allow sufficient clearance for the power unit, loader, and load. Drive slowly. Allow for additional length of loader and load on power unit while turning.
Page 9 SAFETY INSTRUCTIONS (continued) TRANSPORT SAFETY Comply with state and local laws governing highway safety and movement of farm machinery on public roads. The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use. Local laws should be checked for all highway lighting and marking requirements. When driving the tractor and equipment on the road or highway under 20 mph (32 kph) at night or during the day, use flashing amber warning lights and a slow moving vehicle (SMV) identification emblem.
Page 10 SAFETY INSTRUCTIONS (continued) MAINTENANCE SAFETY Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. Before working on this machine, drive to a level area, disengage the PTO, lower implement or loader (or if working underneath, raise and block securely), shut off the engine, relieve all hydraulic pressure, set the brakes, and remove the ignition keys.
Page 11 SAFETY INSTRUCTIONS (continued) STORAGE SAFETY Following operation, or when unhooking, stop the tractor, set the brakes, disengage the PTO, shut off the engine and remove the ignition keys. Use extreme care to keep feet and hands from under the unit and clear of any pinch points. Never stand or allow another person to stand between a running tractor and the unit when disconnecting the implement from the tractor.
Page 12: Safety Signs
SAFETY SIGNS BE CAREFUL! Use a clean, damp cloth to clean safety decals. Avoid spraying to close to decals when using a pressure washer; high-pressure water can enter through very small scratches or under edges of decals causing them to peel or come off. REMEMBER: If Safety Signs have been damaged, removed, become illegible or parts replaced without Signs, new Safety Signs must be applied.
Page 13: Preparation Instructions
The Compact Tractor Grapple Rake is available in two Operators should be familiar with the tractor, loader and models. The models FLGR-4062 and FLGR-4062S are loader attachment, and all safety practices before start- designed to mount on farm tractor front-end loaders only.
Page 14 INSTRUCTIONS (continued) ASSEMBLY – TRACTOR LOADERS Optional pin-on bracket sets available. – PIN ON ATTACHMENT PIN DIAMETER BRACKET SET # .75” ( ”) 811220 Measure the width of your loader arms and figure how to best attach the loader mounting brackets so the front 1.0”...
Page 15 INSTRUCTIONS (continued) MODELS FLGR-4062S ATTACHMENT TO PRIME MOVER —————————————————— WARNING Improper attachment of the Grapple Rake could result in injury or death. Do not operate this product until you have positive indication that the attachment is securely mounted. 1. Position the attachment on a level surface. Figure 3.
Page 16: Operating Instructions
OPERATING INSTRUCTIONS PRE-OPERATION CHECKLIST SAFETY INSTRUCTIONS (OWNER/OPERATOR RESPONSIBILITY) Observe all instruction and safety decals on the Grapple Rake. These safety signs are shown for ____ Review and follow safety rules and safety signs on reference. Read them carefully before using the Grapple Rake.
Page 17 OPERATING INSTRUCTIONS (continued) HANDLING MATERIAL Grapple Rake Limitations (continued) more complete burning and final land clearing. The rake Approach the material to be handled with the grapple frame is not designed to bulldoze out stumps or buried clamp open, when the rake frame contacts the material, rocks.
Page 18: Owner Maintenance & Lubrication
OWNER SERVICE TRANSPORTING WARNING ■ ■ Do not operate this product until you have posi- CAUTION tive indication that this attachment is securely mounted to the loader. Failure to install lock pins or When traveling on public roads, whether at night or have the latching mechanism engaged could result during the day, use accessory light and devices for in injury or death.
Page 19: Trouble-Shooting Guide
TROUBLE-SHOOTING GUIDE PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Grapple Rake 1. No or insufficient oil flow. Remote hydraulic connection fittings not clamp will not compatible. Check for proper fitting. operate. Hydraulic system may not be supplying rated pressure. Consult your dealer. Hydraulic system may not be delivering its rated volume of oil due to wear.
Page 20 TROUBLE-SHOOTING GUIDE (continued) PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Material slips from 1. Clamp arms not positioned cor- Reposition clamp arms. Grapple Rake rectly on material. grasp. 2. Not firmly clamped by hydraulic Operate hydraulic cylinder to clamp cylinder. tighter. 3. Hydraulic system has leak – allow- Find leak and repair (could be O-Ring in ing clamping pressure to back off.
Page 21: Parts Lists
COMPACT TRACTOR FRONT LOADER GRAPPLE PARTS DRAWING Model FLGR-4062...
Page 22 COMPACT TRACTOR FRONT LOADER GRAPPLE PARTS LIST Model FLGR-4062...
Page 23 COMPACT TRACTOR FRONT LOADER GRAPPLE PARTS DRAWING with SS Quick-Attach Model FLGR-4062S...
Page 24 COMPACT TRACTOR FRONT LOADER GRAPPLE PARTS LIST with SS Quick-Attach Model FLGR-4062S...
Page 25 OPTIONAL STAND KIT (#811395)
Page 26 1. PART NUMBER 2. PART DESCRIPTION MODEL NO.’s 3. MODEL NUMBER 4. NAME OF ITEM FLGR-4062 FLGR-4062S MAKE EVERY DAY A HOLIDAY FROM ACCIDENTS! APRIL 2013 WORKSAVER, INC. P.O. BOX 100 LITCHFIELD, IL 62056-0100 (217) 324-5973 WEB: http:// www.worksaver.com E-MAIL: sales@worksaver.com WS-TA011-OG...
