INSTALLATION USING UAS

UAS or Vehicle Belt? This Infant restraint system can
be safely installed using Vehicle Belts or UAS; never use
both. Use the method that results in the MOST SECURE
installation in your vehicle.
Remove UAS Connectors from storage
1
pockets while lifting up on UAS Release
Lever.
Position Base in forward facing vehicle
2
seat with Recline Foot against seat back.
Adjust Base Angle by pushing Recline
3
Buttons while lifting Base. Angle is correct
when Bubble is between arrows.
Vehicle must be on a level surface for the Bubble
to indicate correctly.
Attach UAS Connectors by pushing
4
them firmly onto vehicle UAS Anchor Bars.
Verify connection is secure by pulling firmly
on UAS straps.
This infant restraint base is designed to be used with lower UAS anchors at the standard
spacing 27.94 cm (11 inches) ONLY! REFER TO VEHICLE OWNER'S MANUAL for
information about UAS and infant restraint system installation positions.
1
2
3
4
20
CLICK!
