Hitachi Highly
Rollkolbenverdichter
Rotary Compressors
Spezifikation
Installation Manual
WHP05600VUKQA7JT6
R 410A, R 32, R 454B, R 454C
14,1 cm3/rev
1000 - 7200 min-1
RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY
Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de
Ausg. 7/24
Advertisement
Related Manuals for Hitachi Highly RIES WHP05600VUKQA7JT6
Summary of Contents for Hitachi Highly RIES WHP05600VUKQA7JT6
- Page 1 Hitachi Highly Rollkolbenverdichter Rotary Compressors Spezifikation Installation Manual WHP05600VUKQA7JT6 R 410A, R 32, R 454B, R 454C 14,1 cm3/rev 1000 - 7200 min-1 RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de...
- Page 2 Table of contents 1.WHP05600VUKQA7JT6 —————1～4 WHP05600VUKQA7JT6 SPECIFICATION SCOPE SPECIFICATION OF THE MODEL THE PARAMETER OF MOTOR PARTS AND DRAWING LIST CHARACTERISTICS 5——————17 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA CHECK UPON DELIVERY BASIS FOR CHECKING UPON DELIVERY RULE FOR CHECKING UPON DELIVERY ———————18～29 DRAWINGS ———————30...
- Page 3 SUBJECT Model WHP05600VUKQA7JT6 PAGE:1/30 SPECIFICATION 1. SCOPE This specification is applied to SHANGHAI HIGHLY Heat pump water heater compressor. SPECIFICATION OF COMPRESSOR 2.1 Model WHP05600VUKQA7JT6 2.2 Power source inp ut to HIGH LY inverter Rated Voltage/Frequency/Phase 220V/50Hz/single 2.3 Application Heat pump water heater 2.4 Refrigerant R410A/R454C/R454B/R32 2.5 Compressor Cooling...
- Page 4 SUBJECT Model WHP05600VUKQA7JT6 PAGE:2/30 SPECIFICATION Heating capacity COP= Motor input 2.8 Allowable frequency range 1000~7200rpm 2.9 Allowable amount of 1250g refrigerant charge 480±20 ml(Initial) 2.10 Amount of oil charge 2.11 Oil HAF68D1/HAF68D1U/ALPHA68HES or equivalent 1200 ml 2.12 Space volume of inner case 9.4kg incl.oil 2.13 Net weight 1/4”quick connect...
- Page 5 SUBJECT Model WHP05600VUKQA7JT6 PAGE:3/30 SPECIFICATION MOTOR PARAMERER project parameter illustrate 6 electrodes 9 slots Rotor Pole(Pole) concentrated winding Mechanical Frequency ， Relating to Rated Frequency Range（Hz） VDCmax of Inverter 16.7-120 Peak Current，at130℃，-5% Demagnetizing Rate Demagnetizing Current（A） 21.6 Inductance Ld（ mH） Sheet 1 ——...
- Page 6 SUBJECT Model WHP05600VUKQA7JT6 PAGE:4/30 SPECIFICATION 4. PARTS AND DRAWING LIST PARTS NAME QTY/SET DRAWING NO. REMARKS Compressor 4CYCD0536 Dimensioned sketch Mounting 4CYC00851 Rubber grommet Parts 4CYC00940 Bolt （M8） Electrical Terminal cover 4CYC01043 Parts Gasket 4CYC01044 Sleeve 4CYC01042 3CYC00004 Rubber washer 4CYC00174 4CYC01426 Lead routing...
- Page 7 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:5/30 SYSTEM COMPRESSOR CRITERIA 1 Strictly observe the specification The compressor should be used in specifications written in this “compressor specification” and not be used in specifications outside it. Moreover, accessories should be specified parts used in specified way, service must use specified parts too.
- Page 8 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:6/30 SYSTEM Table 2 Operating Envelope （see graph 1） Item Refrigerant R410A R454B R454C 4.762 MAX 4.403MAX 2.972 MAX 4.384 MAX Discharge pressure （condensing （condensing （condensing （condensing MPa{kgf/cm temperature: temperature temperature temperature cold℃）...
- Page 9 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:7/30 SYSTEM raph 1(a) ℃ ℃ ℃ ℃ ℃ Condensing temperature ℃ ℃ ℃ ℃ ℃ Evaporation Temperature raph 1(b) 图 1(b) Condensing temperature 65℃ 28℃ 10℃ 47℃ 65℃ Evaporation Temperature 25℃...
- Page 10 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:8/30 SYSTEM 6 Pressure difference between suction and discharge In all allowable rotational speed range, the difference of pressure should be more than 0.39MPa{4kgf/cm }. But if there is no problem of noise when assembled in air conditioner, it can also below this value.
- Page 11 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:9/30 SYSTEM 12 Start-stop frequency The frequency should be less than 6 times per hour. Operating time from start to stop should be more than 3 minutes. Stopping time should be more than 3minutes. But oil level should be met to item 8.
- Page 12 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:10/30 SYSTEM 16 Compressor vacuum operation Compressor should never be operated while under vacuum. Otherwise, internal arcing can caus e damaging parts. 17 The compressor should be operated for more than 20 seconds within 15 minutes after charging refrigerant into the system so proper lubrication results.
- Page 13 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:11/30 SYSTEM 20 Apply for vehicle The compressor should not be used on moving equipment such as automobiles, trains, ships, etc. 20 Installation The rotational axis of compressor should be kept vertical during operation. But in actual application the axis incline must be within 5at all directions during operation.
- Page 14 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:12/30 SYSTEM 24 Miscellany (1) The compressor should be carried carefully to avoid drop, drag ,impact and should not apply partial force on projection parts such as pipe, hermetic terminals, foot during carrying and processing.
- Page 15 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:13/30 SYSTEM (8) The main electric circuit should be equipped with fuse or breaker. (9) Refrigerant should be charged from the end of condenser of refrigerating systems. Never Charge refrigerant to the compressor directly. The refrigerant should always be charged in liquid state.
- Page 16 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:14/30 SYSTEM (16) The pipe and hermetic pens attached to the compressor should not be bent. (17)The dropped compressor can’t be used anymore. (18) Compressor can be used when ambient temperature is higher than -10℃. Confirm the start-up of compressor if the temperature of compressor surface is below -10℃.
- Page 17 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:15/30 SYSTEM (21) Use the refrigerant of specified brand. When the refrigerant not specified used, it will possibly cause trouble of the performance and reliability of the compressor by the impurities in the refrigerant. (22) The lead wires should be connected to hermetic terminals without being touched on the surface of the compressor.
- Page 18 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE PAGE:16/30 SYSTEM 25.3 Eliminate all system contaminants such as trichlorethylene, alkalies, soap, acid, oil & washing fluid used at machining the heat exchanger tubes. 25.4 Purge parts with dry nitrogen or dry air to remove remains in parts (dust, detergent，etc.) before assembly of system..
- Page 19 Check upon Delivery PAGE:17/30 1. Basis for Checking upon Delivery The Performance test will be carried out in accordance with this “compressor Specification”. The Safety Performance in accordance with GB4706.1 Safety of household and Similar electrical appliances General requirements and GB 4706.17 Safety Of household and similar electrical appliances Particular requirements for Motor-compressor.
- Page 20 18/30...
- Page 21 19/30...
- Page 22 20/30...
- Page 23 21/30...
- Page 24 22/30...
- Page 25 23/30...
- Page 26 24/30...
- Page 27 25/30...
- Page 28 26/30...
- Page 29 27/30 ～Max 7200min Compressor running speed range： Min 1000min （MPa） Pd limit Rotational speed (rpm) R410A R454B R454C 1000 2.73 2.51 1.655 2100 4.76 4.384 4.403 2.972 5000 4.76 4.384 4.403 2.972 7200 3.51 3.23 2.078 1000～1800 min...
- Page 30 28/30 WHP SERIES C0MPRESSOR OIL/LIQUID LEVEL C0NFIRMATION 1 COMPRESSOR OIL LEVEL In order to ensure the reliability of the com pressor, the minimum oil level required for each operating frequency is shown in the following chart: 2 Graph 2 30rps-Maximum speed Operating Below Operating frequency Stable operation...
- Page 31 29/30...
- Page 32 30/30 Specification Revision Record Page in Conclusion Date Revision Reason Spec Date...
