Rollkolbenverdichter
Rotary Compressors
Spezifikation
Installation Manual
WHP13300PSDPC8FQ
R 290
54,8 cm3/rev
900 - 6600 min-1
DC / BLDC
RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY
Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de

Advertisement

Table of Contents
loading

Subscribe to Our Youtube Channel

Summary of Contents for Hitachi Highly WHP13300PSDPC8FQ

  • Page 1 Highly  Rollkolbenverdichter Rotary Compressors Spezifikation Installation Manual WHP13300PSDPC8FQ R 290 54,8 cm3/rev 900 - 6600 min-1 DC / BLDC RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de...
  • Page 2: Table Of Contents

    CONTENTS —————— 1~4 WHP13300PSDPC8FQ SPECIFICATION SCOPE SPECIFICATION OF THE MODEL THE PARAMETER OF MOTOR CHARACTERISTICS PARTS AND DRAWING LIST HEAT PUMP Compressor CRITERIA ————— 5~15 ———— 16 CHECK UPON DELIVERY BASIS FOR CHECKING UPON DELIVERY RULE FOR CHECKING UPON DELIVERY DRAWINGS ——————————...
  • Page 3: Scope

    S U B J E C T M o d e l W H P 1 3 3 0 0 P S D P C 8 F Q S P E C I F I C A T I O N PAGE:1/31 SCOPE T h i s s p e c i f i c a t i o n i s a p p l i e d to SHANGHAI HIGHLY Heat pump water heater compressor.
  • Page 4 S P E C I F I C A T I O N PAGE:2/31 *.COP= Heating capacity (W) Motor input *.Rated Capacity and input are measured with HITACHI inverter circuit by secondary Refrigerant calorimeter Methods of JIS B8606 by SHANGHAI HIGHLY Electrical Appliances Co., Ltd. Refrigerant R290 Displacement 54.8ml /rev(Double-cylinder...
  • Page 5: The Parameter Of Motor

    S U B J E C T M o d e l W H P 1 3 3 0 0 P S D P C 8 F Q S P E C I F I C A T I O N PAGE:3/31 3.
  • Page 6: Parts And Drawing List

    S U B J E C T M o d e l W H P 1 3 3 0 0 P S D P C 8 F Q S P E C I F I C A T I O N PAGE:4/31 4.2.
  • Page 7 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE:5/31 COMPRESSOR CRITERIA 1 Strictly observe the specification The compressor should be used in specifications written in this “compressor specification”...
  • Page 8 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A 热 泵 热 水 器 专 用 压 缩 机 使 用 基 准 PAGE:6/31 There should be superheated gas returned to the compressor under all normal operating conditions.
  • Page 9 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE:7/31 raph 1 图 1 Condensing temperature 70℃...
  • Page 10 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A 热 泵 热 水 器 专 用 压 缩 机 使 用 基 准 PAGE:8/31 9 Dust of compressor hermetic terminals Compressor hermetic terminals should be mounted with specified cover in right way to prevent...
  • Page 11 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE:9/31 14 Impurities in refrigerating system (1)The weight of residue on the inside surface of the heat exchanger and tube should be less than 0.01g/m .
  • Page 12 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A 热 泵 热 水 器 专 用 压 缩 机 使 用 基 准 PAGE:10/31 18 Purge parts with dry nitrogen or dry air to remove remains in parts (dust, detergent, etc.) before assembly of system.
  • Page 13 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE:11/31 Moving tubes to the moving parts; minimum clearance 12.7mm(1/2”) Moving tubes to non-moving parts;...
  • Page 14 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE:12/31 (6)The compressor can’t be used in the place with corrosive atmosphere such as hot spring and chemical warehouse.
  • Page 15 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE:13/31 (14) SHEC will not take any responsibility against accident that is caused by the accessories equipped by yourselves.
  • Page 16 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE:14/31 It is necessary to install a dryer to dehumidify the residual moisture mixed in the refrigerant in the cycling system.
  • Page 17 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE:15/31 (27)The fuse or/and breaker should be equipped in the main circuit. (28) The thickness of the refrigerating system using tube the tube thickness as followed External diameter(mm)
  • Page 18: Check Upon Delivery

    C h e c k u p o n D e l i v e r y PAGE:16/31 1. Basis for Checking upon Delivery The Performance test will be carried out in accordance with this “compressor Specification”. The Safety Performance in accordance with GB4706.1 Safety of household and similar electrical appliances General requirements and GB 4706.17 Safety of household and similar electrical appliances Particular requirements for motor-compressor.
  • Page 19 17/31...
  • Page 20 18/31...
  • Page 21 .19/31...
  • Page 22 20/31...
  • Page 23 21/31...
  • Page 24 22/31...
  • Page 25 23/31...
  • Page 26 24/31...
  • Page 27 25/31...
  • Page 28 26/31...
  • Page 29 Attached page 1 WHP13300PSDP Pd 8000 7000 1000 2000 3000 4000 5000 6000 ~Max 6600min Compressor running speed range: Min 900min Rotational speed Pd limit 1.71 2000 3.13 5400 3.13 6600 2.34 27/31...
  • Page 30 Instructions: The pressure ratio(Pcr) should satisfy the following conditions: 1)900~2000rpm:1.5≤Pcr≤8.0 2)2000~6600rpm:2.0≤Pcr≤8.0 If the suction pressure, pressure ratio out of the used envelop under normal operating conditions , the following tips should be considered to make the compressor operating reliability. Condit Condit Condit Condition 1...
  • Page 31 29/31...
  • Page 32 Anwendungshinweise für DC Inverter Kompressoren zur Drehzahlregelung Instruction for DC inverter compressor rotation speed control Drehzahländerung / <= Speed change rate: 133min-1/s Max und Min Drehzahl in den einzelnen Spezifikationen Max and min speed is showed in the specification Vom Start zur gewünschten Drehzahl / From starting to normal running Rotation speed Drehzahl...
  • Page 33: Specification Revision Record

    Specification Revision Record Page in Date Revision Reason Conclusion Date Spec 31/31...
