Parker 71313 Installation, Operating, & Maintenance Instructions

Fluid Control Division
Parker Hannifin Corporation
95 Edgewood Avenue
New Britain, CT 06051
Telephone (860) 827-2300
INSTALLATION, OPERATING
QUICK EXHAUST, AND DIVERTING SOLENOID VALVES
VALVE TYPES:71313, 71315, 71335, 71385, 71395, 7131V, 7133V
This document is intended for use as a complementary resource to
the User Safety Responsibility Statements located in product
literature and posted to www.parker.com/safety.
WARNING
FAILURE OR IMPROPER SELECTION OR
IMPROPER USE OF THE PRODUCTS
AND/OR SYSTEMS DESCRIBED HEREIN
OR RELATED ITEMS ("Products") COULD
CAUSE DEATH, PERSONAL INJURY AND
PROPERTY DAMAGE.
Possible consequences of failure or improper selection, or improper
use of these Products include, but are not limited to:
• Unintended or mistimed cycling or motion of machine members
or failure to cycle
• Work piece or component parts being thrown off at high speeds
Failure of a device to function properly, for example, failure to
•
clamp or unclamp an associated item or device
Explosion
•
• Sudden moving or falling objects
Release of toxic or otherwise injurious liquids or gases
•
Electrical shorts or burn out of equipment
•
Before selecting or using any of these Products, it is important that
you read and follow the subsequent instructions.
This document and other information from Parker Hannifin
Corporation, its subsidiaries, and authorized distributors provide
Product and/or system options for further investigation by users
having technical expertise. It is important that you analyze all
aspects of the application, follow applicable industry standards, and
follow the information concerning the Product in the current Product
literature and in any other materials provided from Parker or its
subsidiaries or authorized distributors. Due to the variety of
operating conditions and applications for these Products or systems,
the user, through its own analysis and testing, is solely responsible
for making the final selection of the system and components and
assuring that all performance, endurance, maintenance, safety, and
warning requirements of the application are met.
MAINTENANCE INSTRUCTIONS
&
3-WAY N.C., N.O., M.P.,
1/8" AND 1/4" NPT
To the extent that Parker, or its subsidiaries, or authorized distributors provide
component or system options based upon data or specifications provided by
the user, the user is responsible for determining that such data and
specifications are suitable and sufficient for all applications and reasonably
foreseeable uses of the components or systems.
The Products described herein, including without limitation, Product features,
specifications, designs, availability and pricing, are subject to change by Parker
Hannifin Corporation and its subsidiaries at any time without notice. Do not, at
any time, make alterations or modifications to any Product without the express
and written approval of Parker Fluid Control Division. Do not, at any time, make
alterations or modifications to any Product without the express and written
approval of Parker Fluid Control Division.
Page1
IOM7304
(Rev 0324)
