6.6. HOW TO CHARGE LIFEPO4 BATTERIES
FIG.11
Connect the battery and AC
power. The display shows the
battery's voltage.
NOTE: Batteries with "Under Voltage Protection"
Some LiFePO4 batteries have on-board UVP (under voltage protection) which will disconnect the battery to prevent it becoming too
deeply discharged and dead. This protection will disable the charger from detecting whether there's a battery connected. The lithium
charging function can't work on LiFePO4 batteries if UVP is activated.
6.7. HOW TO BOOST
FIG.14
Connect the battery and AC power.
The display shows battery voltage.
NOTE: The maximum of boosting time is 5 seconds and after each boost, it takes 180 seconds to cool down.
7.

MAINTENANCE

FIG.17
7.1. FUSE REPLACEMENT (fig.17)
7.1.1. Replace the blown fuses, put 2 fuses on the two poles on the back of the charger, and screw them securely.
7.2. Put the plastic cover on the fuses for protection.
© Jack Sealey Limited
FIG.12
Press the button to select
LiFePO4 mode.
FIG.15
Press the button to select 12V
BOOST. During boosting, other lights
go out, and functions are locked.
Original Language Version
FIG.13
Press "START / STOP" button to start charging and the
"Charge" light will turn orange. When the battery is fully
charged, the "Full" light will turn green.
FIG.16
Press "START / STOP" button to boost
your car. The screen displays the
countdown time. The car needs to be
started within 90 seconds.
PART NO NAME
1 Fuse (80A) x2
2 Plastic cover
