Have soap and plenty of fresh water nearby for use if battery acid contacts skin,clothing or eyes. If battery acid contacts skin or clothing,
9
wash immediately with soap and water.
Avoid touching your eyes while working with a battery. Acid particles (corrosion) may get into your eyes! If acid enters your eye,
9
immediately rinse eye with running cold water for at least 10 minutes. Get medical attention immediately.
Remove personal metal items such as rings, bracelets, necklaces, and watches when working with a lead-acid battery. A lead-acid battery
9
can produce a short-circuit current high enough to weld a ring or the like to metal, causing a severe burn.
Take care not to drop a metal tool or other metal onto the battery. Metal may cause sparking or short circuit the battery or another
9
electrical devise. Sparking may cause an explosion.
1.4. SPECIFIC BATTERY CHARGING INSTRUCTIONS
Familiarise yourself with the application and limitations of the charger as well as the potential hazards. Also refer to the vehicle
9
manufacturer's hand book. IF IN ANY DOUBT CONSULT A QUALIFIED ELECTRICIAN.
Ensure the charger is in good order and condition before use. If in any doubt do not use the unit, contact your Sealey Dealer.
9
Use the charger in the upright position only and ensure it is placed on a stable surface which will adequately support its weight.
9
Ensure the charger is disconnected from the mains supply before attaching/detaching the power clamps to/from the battery.
9
Keep tools and other items away from the engine and ensure you can see the battery and working parts of engine clearly.
9
Ensure the output of the charger is the same voltage as the battery.
9
Ensure that during charging, the charger is placed in a location where there is sufficient ventilation to prevent the build up of explosive
9
gases from a lead acid battery, and DO NOT cover or obstruct the charger ventilation louvres.
If battery has caps to access the battery fluid, remove the caps and check the fluid level before connecting the power clamps.
9
If necessary top-up the battery with distilled water by referring to the battery manufacturer's instructions. (Apply personal safety
precautions described in 1.3).
If the charger receives a sharp knock or blow the unit must be checked by a qualified service agent before using.
9
If the battery terminals are corroded or dirty clean them before attaching the power clamps.
9
Keep children and unauthorised persons away from the working area.
9
DO NOT dis-assemble the charger for any reason. The charger must only be checked by qualified service personnel.
8
DO NOT try to charge a non-rechargeable battery.
8
DO NOT try to charge battery if battery fluid is frozen.
8
WARNING! To prevent the risk of sparking, short circuit and possible explosion DO NOT drop metal tools in the battery area, or allow
‰
them to touch the battery terminals.
DO NOT allow power clamps to touch each other or to make contact with any metallic part of the vehicle.
8
DO NOT cross connect power leads from charger to battery. Ensure positive (+/RED) is to positive and negative (-/BLACK) is to negative.
8
DO NOT pull the cables or clamps from the battery terminals.
8
DO NOT use the charger outdoors, or in damp, or wet locations and DO NOT operate within the vicinity of flammable liquids or gases.
8
DO NOT use charger inside vehicle or inside engine compartment.
8
Ensure there is effective ventilation to prevent a build-up of explosive gases, and do not cover or obstruct charger ventilation louvres.
9
DO NOT use the charger for a task for which it is not designed.
8
WARNING! DO NOT simultaneously charge batteries of different capacities or discharge levels.
‰
WARNING! If a fuse blows, ensure it is replaced with an identical fuse type and rating. Use only Sealey genuine parts.
‰
When not in use, store the charger carefully in a safe, dry, childproof location.
9
WARNING! Life-threatening danger to infants and children! Never leave children unsupervised with the packing material as this can
‰
cause suffocation. Do not allow children to play with cables – strangulation hazard! Do not allow children to play with the components or
fasteners, as they could be swallowed and result in suffocation.
WARNING! Explosive gases. When a battery is charged, it can produce hydrogen gas which is explosive. Charging should be carried out
‰
in a well-ventilated area and away from sources of heat flames and sparks.
Store and use indoors only. Do not expose to rain or moisture.
9
DO NOT cover the charger. Allow air to the charger, as it will overheat.
8
Wear safety goggles and acid-proof safety gloves. Before charging maintenance type battery, the electrolyte (battery acid) must be filled to
9
the maximum marked levels. Never use tap water. Distilled water or electrolyte must be used.
Never attempt to charge non-rechargeable batteries.
9
Never attempt to charge a frozen battery as well as a damaged or distorted battery.
9
2. INTRODUCTION
Automatic battery charger and starter designed for charging and boosting a variety of AGM (stop/start), GEL, Lead Acid and Lithium
lifepo4 batteries up to 600ah. Intuitive digital display and 200A peak engine start function, makes this unit ideal for every workshop.
Features overcharge, short circuit, and reverse polarity protection. Dedicated charging programs for AGM, GEL, conventional Lead Acid
and Lithium batteries with fully automated charging algorithms. Three charging rates for both 12v and 24v systems makes this ideal for
whatever job comes through the workshop. Portable design with handle means you can easily manoeuvre the unit around the workshop.
3.

SPECIFICATION

MODEL NO
Battery Range
Battery Support /DC Mode
Battery Type
Cable & Clamp Length
Charger Type
Max Size Size Battery (AH) Full
Charge in 12hrs from Discharged
© Jack Sealey Limited
SUPERSTART200D
10Ah-600Ah
No
GEL, AGM, LEAD ACID,
LITHIUM (12V ONLY), LEISURE
2m
Intelligent (HF)
600Ah
Original Language Version
Output Charge Peak
Output Charge Rates
Plug Type
Power Supply Cable Length
Start Peak
Supply Voltage / Current
SUPERSTART200D
60A 12V, 30A 24V Twelve battery
cell max
12V - 60A, 30A, 10A 24V - 30A,
15A, 5A 12V 10A, LiFePO4
3-Pin
1.9m
200A
230V / 13A
Issue 2 24/04/24
