Dip Switches - SpaNet Mini 1 Quick Start Manual

Wiring Diagram (Mini 2)
Output Ratings
Model Outlet
SV Mini 2 230V
Pump 1
Pump 2
03/UV
Pump 3
Blower

DIP SWITCHES

The dip switches determine the configuration of pumps connected to the SV Mini controllers. The installer
must correctly configure the dip switches to match the pump(s) connected to the spa controller. The dip
switch bank (illustrated below) has six individual switches. Switches set to the right of the switch bank
(away from the numbers) are in the ON position. Switches set to the left of the switch bank (closest to the
numbers) are in the OFF position. Refer to diagram below for dip switch settings:
SW
1
2
3
4
5
6
* SV Mini 2 models only
NOTE: The dip switches will already be set by your spa manufacturer during production and should not
require adjusting. This information is for reference when installing a new control to an existing spa.
V.2005
Max Current
10A
10A
10A
2A
10A
4.5A
Setting OFF (left)
Not used
Pump 1 Type Single Speed
Pump 3 Fitted * Not Fitted
Not used
Not used
Not used
Output Voltage Hz
230-240V AC 50/60
230-240V AC 50/60
230-240V AC 50/60
230-240V AC 50/60
230-240V AC 50/60
230-240V AC 50/60
ON (right)
- -
Two Speed
Fitted
- -
- -
- -
Typical Accessory
Heat Pump / Stereo
Circ / 2-spd or 1-spd Pump
1-spd Pump
Ozone / UV Sanitiser
1-spd Pump
Air Blower
Notes
Determines if P1 = 1spd/2spd
Determines if P3 is connected
Page | 3
