highwood Adirondack AD-ROCCW30-ACE Assembly Manual

Adirondack Collection
Classic Westport Rocking Chair
Assembly Guide
A
BACK
highwood
NATURE'S CLOSEST RIVAL
SEAT
1) With the Back and Seat on Their
Sides, Attach One Side of the Back
to the Seat Using Two "A" Bolts.
1
2) Repeat on Other Side.
For information on Care and Cleaning or to register your
highwood product, please visit www.highwood-usa.com.
HARDWARE
A
1/4"-20 X 1-3/4"
B
1/4"-20 X 2"
IMPORTANT!
DO NOT fully tighten the bolts until all
bolts are started. Once all bolts are inserted,
go back & tighten all the bolts.
Retain these instructions for future reference
INCLUDED TOOLS
5/32" HEX KEY
x 10
x 6
ROCCW30
03.17.2017
PAGE 1 OF 2
