Summary of Contents for Bel Canto e.One REF600M
- Page 2 Bel Canto Design. The content of this manual is provided for information use only, is subject to change without notice, and should not be construed as a commitment by Bel Canto Design Limited. Bel Canto Design Limited assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
- Page 3 Always ensure the fuse cover is fitted. If the fuse cover is missing do not use the plug. Contact your Bel Canto retailer to obtain a replacement fuse cover. Fuses are for fire protection and do not protect against electric shock.
- Page 4 Power Connection The power supply in the e.One REF600M is preset for the proper power voltage. The power cable should have the correct plug for your local power system. If you believe this to not be true, please contact your dealer immediately. This product, like any electrical component, can be dangerous and cause injury unless correct handling procedures are observed and used.
- Page 5 Rear Panel Connections onnections Never Connect the Positive Speaker Output to Any Ground Contact! Use Class 2 Wiring for all Loudspeaker Connections! Connecting the Positive Speaker Output on the REF600 to Ground will cause the amplifier to go into protection and could damage the amplifier and void the warranty.
- Page 6 LED is not lit, this indicates that the internal fuse may have blown. If this occurs contact your dealer, distributor or Bel Canto for service. There are no user replaceable fuses or other parts.
- Page 7 Specifications Specifications Power Output 1% THD: 600W 4 ohms, 300W 8 ohms Minimum Load: 2 ohms Peak Output Current: 27 amperes Frequency Response: +/-3 dB 0Hz-50KHz, all loads THD+N: 0.003% 1W, 1KHz, 4 ohms IMD (CCIF): 0.0003%, 1W, 14:15KHz, 4 ohms Output noise: 35uVRMS A-weighted 10Hz-20KHz Voltage gain:...
- Page 8 EN 55013:2001 + A1:2003 + A2:2006 EN 55020:2007 EN 61000-3-2:2006 EN 61000-3-3:1995 + A1:2001 + A2:2005 EN 62368-1:2014+A11:2017 Manufacturer: Bel Canto Design, Ltd. 221 1 Street North Minneapolis, MN 55401 USA The equipment identified here conforms to the Directive(s) and Standard(s) specified above.
- Page 9 221 First Street North, Suite 300 Minneapolis MN 55401 P: 612.317.4550 www.belcantodesign.com | info@belcantodesign.com © 2022 Bel Canto Design, LTD e.One™ is a trademark of Bel Canto Design, LTD...
