- Page 2 Design. The content of this manual is provided for information use only, is subject to change without notice, and should not be construed as a commitment by Bel Canto Design Limited. Bel Canto Design Limited assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
- Page 3 Explanation of symbols used in this manual or on the TO COMPLETELY DISCONNECT THIS APPARATUS rear/underside of the apparatus: FROM THE AC MAINS, DISCONNECT THE POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE. The Lightning Flash with arrowhead symbol within an equilateral triangle, is intended to THE MAINS PLUG OF THE POWER SUPPLY CORD alert the user to the presence of uninsulated SHALL REMAIN READILY ACCESSIBLE.
- Page 4 Fit a new 10 amp BS1362 approved fuse into the carrier GROUNDED. and push the carrier back into the plug. Bel Canto Design Ltd. declare that this product is in conformance The conformity of the designated product with the provisions of with the Low Voltage Directive 73/23/EEC and Electromagnetic...
- Page 5 If the packing becomes lost or damaged, Bel Canto Design. please contact your dealer or Bel Canto before attempting to transport your unit. This product, like any electrical component, can be...
- Page 6 directly on the REF1000 . This may scratch or mar Because the REF1000 runs cool, it can be placed the chassis finish. Do not use harsh chemicals in many system locations without compromise. We when cleaning the outside of your REF1000 do not recommend placing weights or other objects IMPORTANT! Make all connections before...
-
Page 7: Panel Connections
Panel Connections Never Connect Either the Positive or Negative Speaker Output to Any Ground Contact! Connecting any Speaker Output on the REF1000 to Ground will cause the amplifier to go into protection and could damage the amplifier and void the warranty. 1) Power Switch: Power is on when the switch is 3) Output Connections: Attach your loudspeaker to toggled to the I position and off in the O position. - Page 8 In case there is hum or ground noise, check that the RCA/XLR switch is in the correct position for the type of • connection being used. Ensure that the preamplifier or any source components are not producing hum by setting the preamplifier •...
-
Page 9: Specifications
Specifications Power Output: >1000W into 4 ohms, >500W into 8 ohms Minimum Load: 2 ohms Peak Output Current: 45 amperes Frequency Response: +/-0.5dB 20Hz-20KHz, all loads THD+N: 0.007% 1W, 1KHz, 4 ohms IMD (CCIF): 0.0007%, 1W, 14:15KHz, 4 ohms Output noise: 90uVRMS A-weighted 10Hz-20KHz Voltage gain: 27dB (single ended or balanced input) - Page 10 version 3.0...
