Homerton 2
Music System
User Manual
H O M E A U D I O • C A M B R I D G E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Homerton 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MAJORITY Homerton 2

Summary of Contents for MAJORITY Homerton 2

  • Page 1 Homerton 2 Music System User Manual H O M E A U D I O • C A M B R I D G E...

  • Page 2: Table Of Contents

    Contents What’s In the Box?......................Controls And Functions…………………………..…………………………………………...... Instructions Guide……………………………………………………………………………......Basic Information…………………………………………………………………………………. Getting Started/Product Set-up…………………………………………………………… Connecting to Network………………………………………………………………………… System Settings…………………………………………..........Internet Radio & Podcasts………………………………………………...…………………. Spotify…………………………………………………………………………………………………. Media Player - USB Playback…………………………………........CD Mode……………………………………………………………………………………………… DAB/DAB+ Radio………………………………………..........FM Radio……………………………………………………………………………………………… Bluetooth…………………………………………………………………………………………..AUX – In Mode…………………………………………………………………………………….. Headphone Jack………………………………………………………………………………….

  • Page 3: What's In The Box

    Box Contents What’s in the Box? Majority Homerton 2 Music System Power Adaptor Remote Control User Guide...

  • Page 4: Controls And Functions

    Controls & Functions Front View VOLUME +/-. Press to Power 1/2/3 – numeric buttons ON/OFF MODE NAVIGATION DIAL/ TUNE/ OK MENU Remote Sensor CD compartment PRESETS Previous INFO/BACK PAIR /CD Eject Play/Pause Next...
  • Page 5 Controls & Functions Back View 16 17 AUDIO IN Jack Headphone Socket USB/5V=1A Output Jack DCIN Jack...
  • Page 6 Controls & Functions Remote Control Power ON/OFF q INTRO/AMS REPEAT BASS +/- USER MENU UP w OK/12 BACK 7 DOWN s STOP 3 CLOCK P +/- Remote numeric keypad buttons INFO INTERNET RADIO/SPOTIFY SLEEP RANDOM TREBLE +/- PROGRAM PAIR NEXT 8 MUTE ! V +/- TIMER...
  • Page 7 Remote Control Power ON/OFF (Rem.1) Turn the unit ON or set in Standby Mode. CD/Eject (Rem.2). Press to eject CD. USB/DAB/FM/AUDIO/PODCAST/ Press the corresponding button to change the audio source/Mode. INTRO/AMS (Rem 3). Press to start browsing audio tracks in CD/USB Mode. While in FM or DAB Mode press this button to initiate an automatic full scan.

  • Page 8: Basic Information

    Extend the radio antenna in full before scanning for DAB/FM radio stations. Connect the unit to a suitable power source using the power cable included in the box. The Majority Homerton 2 will display the 'Welcome' screen and will enter in the last used listening mode.

  • Page 9: Getting Started/Product Set-Up

    Getting Started When powering the Majority Homerton 2 for the first time, the Setup Wizard will be automatically launched. The Setup Wizard guides you through the basic setup parameters such as Language, Time/Date and Network connection. Note: If you choose not to launch the Setup Wizard and skip this step, or if the Setup...
  • Page 10 Getting Started Select the Clock format Select the clock format as '12' for 12-hour display format or '24' for 24-hour display format. If you select the 12-hour format, the display shows 'AM' in the morning or 'PM' in the afternoon hours. Note: 'AM'/ 'PM' displays only if you have chosen the 12-hour time format.

  • Page 11: Connecting To Network

    At the next step you will be asked if you would like to keep the network connected. Select this option if you would like to have the Majority Homerton 2 connected to your network even when the unit is in Standby Mode. To control the device in all operating modes via the UNDOK app and have the unit connecting faster to your Network, select 'YES' to confirm.
  • Page 12 There is the shortcut WPS key on the unit. • Method 1 Using the Push button to connect The Majority Homerton 2 prompts you to press the connect button on your router. It then scans for a ready Push Button Connect to the network and connects with your router within seconds.

  • Page 13: System Settings

    Once saved, select ‘My EQ’ as your EQ. NETWORK Network Wizard Enter this section to manually connect the Majority Homerton 2 with your network. Search AP SSID, then input the WEP / WPA key or choose Push Button/Pin/Skip WPS to connect to the wireless network.
  • Page 14 If you choose to keep network connected, the Wi-Fi will not disconnect even you are in Standby Mode. Otherwise, the connection will only be available in Internet Radio and Music Player Modes. This option allows the Majority Homerton 2 to be ready for DLNA streaming in any operating modes. TIME/DATE Enter this section to set the time/date manually or set to automatic update.
  • Page 15 From time to time, software upgrades may be created with bug fixes and/or additional features. You can either check manually or set the Majority Homerton 2 to check periodically automatically (this is the default). If newer available software is detected, you will be asked if you want to go ahead with an update.

  • Page 16: Internet Radio & Podcasts

    Internet Radio & Podcasts Internet Radio & Podcasts Homerton 2 can play thousands of radio stations and podcasts from all over the world through a broadband Internet Connection. When selecting the Internet Radio or Podcasts, the Majority Homerton 2 directly contacts the Frontier Silicon Internet radio portal (which is supported by Airable) to get the radio stations or podcasts available at your location.
  • Page 17 Internet Radio & Podcasts Saving & Recalling Presets While the stream is playing, to store this as a preset, press and hold the PROGRAM on the remote control (Rem.22) button, or the ‘Preset’ button on the radio (Ref.12) for 2- 3 seconds, until the display shows 'Save to Preset' on the screen.

  • Page 18: Spotify

    Start playing Spotify on your smartphone as usual. The Spotify icon is displayed at the bottom of the phone screen. Press to display the list of the devices available on the network. Now select 'Majority Homerton 2' and the playback will take place on the radio.

  • Page 19: Cd Mode

    Alternatively, press the ‘CD’ button on the remote control (Rem.2) to change in CD. Insert a disc (with printing side facing up) inside. The display will then show 'Loading' while the Majority Homerton 2 is reading the disc. Once read, the CD playback will automatically start.
  • Page 20 CD Mode Programming a CD While playing a CD, to start programming, press the ‘STOP’ button on the remote control (Rem.13), to stop playing and begin programming your CD. Press the ’PROGRAM’ button on the remote control (Rem.22). The display will flash 'T0l P0l' and 'T0l'.

  • Page 21: Dab/Dab+ Radio

    (Rem.2) to change into DAB Mode. Scanning for DAB/DAB+ radio stations The first time you select DAB Radio Mode, or if the station list is empty, the Majority Homerton 2 automatically performs a full scan searching the radio stations available at your location.
  • Page 22 DAB/DAB+ Radio Saving and Recalling DAB/ DAB+ Radio Presets To store a DAB/DAB+ radio station as a preset, press and hold the ‘PROGRAM’ on the remote control (Rem.22) for 2-3 seconds until the display shows 'Save to Preset' on the screen. Select one of the 40 presets to save the current playing radio station then press ‘OK’...

  • Page 23: Fm Radio

    FM Radio FM Radio Mode receives analogue radio from the FM band and displays RDS (Radio Data System) information about the station and where broadcast. Press the ‘MODE’ button on the radio (Ref.9), or press the ‘FM’ button on the remote control (Rem.2) to change into FM Radio Mode.
  • Page 24 FM Radio Now playing information While the FM radio station is playing, the screen shows its frequency. If RDS signal is available, the station name and any further RDS information such as Program Name and Title will be displayed if available. Stereo broadcasts are indicated with an icon which can be seen at the bottom of the screen.

  • Page 25: Bluetooth

    Bluetooth The Majority Homerton 2 can be paired via Bluetooth with devices such as a phone, a tablet, or an MP3 player to play audio from via its speakers. Press the ‘BT’ button on the remote control (Rem.2) to set the radio on Bluetooth or change the mode using the MODE button on the radio (Ref.9).

  • Page 26: Aux - In Mode

    The Aux-In Mode can be used to play audio from an external source such as an MP3 player, a phone, a tablet, or any other similar device via the Majority Homerton 2’s speakers using an audio cable of 3.5 mm (not included).

  • Page 27: Undock App/ Net-Remote

    Undok App - The Net-Remote UNDOK App (Net-Remote) The Majority Homerton 2 supports the Net Remote control from Apple iPhone, iPad and Android using the UNDOK app. The apps are available in Apple App Store and Google Play. The UNDOK app allows you to: •...

  • Page 28: Alarm

    Alarm & Sleep Timer ALARM There are two versatile wake-up alarms with snooze facility. Press the ‘MENU’ button on the remote control (Rem.8) to enter the ‘Main Menu’, rotate the navigation dial (Ref.2), to find ‘Alarm’, and then press ‘OK’ to enter. Select ‘Alarm 1’...

  • Page 29: Troubleshooting

    Troubleshooting Observation Potential Cause/Solution Check it the power adaptor is connected The device does not turn on. properly. Due to ErP2 requirements and environmental protection, the unit Switch automatically off. automatically switches to Standby Mode when no music is played for more than 15 minutes.
  • Page 30 HOMERTON 2 cause crash, reboot HOMERTON 2 and/or your device. The Majority Homerton 2 may process large amount of data after of operation, no matter in which mode, it will cause the system, freeze or malfunction. Reboot the unit if necessary.

  • Page 31: Specification

    All products come with a standard 12-month warranty. All items must be registered within 30 days of purchase on www.majority.co.uk for the warranty to be valid. Once on the web page, use the menu to find 'Register Your Product'. You will also be given the chance to extend your warranty for an additional 24 months, free of charge.

  • Page 32: Safety Information

    Read these instructions. ADDITIONAL WARNINGS Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping, available for download at www.majority.co.uk. splashing or objects filled with water. Heed all warnings. Follow all instructions. The main plug is used to disconnect the device. In Do no clean the apparatus near or with water.
