- Page 1 MT8120B User’s Manual V1.0 MT8120B 2D Wireless Scanner User’s Manual Version 1.0 DATE: 2024/06/19...
-
Page 2: Table Of Contents
MT8120B User’s Manual V1.0 Table of Content CHAPTER 1 INTRODUCTION ............................... 6 ................................6 RODUCT EQUIREMENTS .................................... 7 PECIFICATIONS ..................................9 EEPER NDICATION LED I ................................9 CANNER NDICATION ................................9 LED I RADLE NDICATION CHAPTER 2 GENERAL SETTINGS ............................ 10 .................................. - Page 3 MT8120B User’s Manual V1.0 CHAPTER 4 SYMBOLOGIES .............................. 26 ..................................26 ENERAL ETTINGS ..................................27 NVERSE ARCODE .................................. 27 IRRORED ARCODE UPC-A ......................................27 Enable/Disable UPC-A ................................. 27 UPC-A to EAN-13 ................................. 28 Check Digit .................................... 28 System Number ..................................28 Supplement....................................
- Page 4 MT8120B User’s Manual V1.0 Check Digit .................................... 36 2/5 .................................... 36 NDUSTRIAL Enable/Disable Industrial 2/5 .............................. 36 Length ..................................... 37 2/5 ..................................... 37 TANDARD Enable/Disable Standard 2/5 .............................. 37 Length ..................................... 37 39 ....................................... 37 Enable/Disable Code39 ............................... 37 Send Start & Stop ................................. 38 Length .....................................
- Page 5 MT8120B User’s Manual V1.0 CHAPTER 5 CONFIGURATION BARCODE ........................45 ..................................45 UMERIC ARCODE ......................................46 ANCEL ................................47 ASCII B ARCODE ABLE APPENDIX....................................54 A – D ..............................54 PPENDIX EFAULT ABLE VERSION HISTORY ................................58...
-
Page 6: Chapter 1 Introduction
MT8120B User’s Manual V1.0 Chapter 1 Introduction This user’s manual is dedicated to MT8120B 2D Wireless Scanner, featuring 2.4G technology. Effortlessly transmit data to your host device from up to 100-meter away via 2.4G wireless technology with the convenient charging base, instantly enabling your host device with wireless connectivity. -
Page 7: Specifications
MT8120B User’s Manual V1.0 Specifications Optic & Performance 6500K White LED Light Source 617nm Red LED Sensor 640 x 480 Resolution 4Mil/ 0.1mm (1D) Horizontal 34° Scan Angle Vertical 26° Pitch Angle ±60° ±60° Skew Angle Roll Angle 360° Print Contrast Ratio... - Page 8 MT8120B User’s Manual V1.0 Interface / Profile 2.4G (Cradle Mode) / Memory Mode User Environment Operating Temperature -20 ~ 50˚C -30 ~ 60˚C Storage Temperature Humidity 0% ~ 95%RH (Non-condensing) Drop Durability 1.8M Ambient Light 100,000 Lux (Sunlight) UPC-A/UPC-E, EAN-8/EAN-13, ISBN, ISSN,...
-
Page 9: Beeper Indication
MT8120B User’s Manual V1.0 Beeper Indication Beeper Status Good read Single beep i. Wireless disconnection Two beeps (low tune) ii. Charging i. Good read (Memory Mode) Two beeps (high tune) ii. Data transmission failed Three beeps Power up Three beeps... -
Page 10: Chapter 2 General Settings
MT8120B User’s Manual V1.0 Chapter 2 General Settings Factory Default Scanning below configuration barcode will reset all parameters to factory default settings (the ones with asterisk mark). Please note that scanning the left Factory Default (Chapter 2) will reset all General Settings to default, and scanning the right Factory Default (Chapter 3~4) will reset all Reading Mode and Symbologies settings to default. -
Page 11: Wireless Communication
MT8120B User’s Manual V1.0 Wireless Communication Connect to Cradle By default the scanner connects to the charging cradle in 2.4G mode right out of box, please follow below steps: 1. Plug the charging cradle to host device with an USB cable. -
Page 12: Usb Mode
MT8120B User’s Manual V1.0 USB Mode To determine the charging cradle’s USB mode that communicates with the host device, scan either one of the configuration barcodes below. USB HID is recommended. USB HID USB COM HID Speed To determine the speed of charging cradle’s USB HID data transferred to the host device, scan either one of the configuration barcodes below. -
Page 13: Memory Mode
MT8120B User’s Manual V1.0 Memory Mode Memory Mode enables the scanner to store barcode data (4096 barcodes; characters ≤500 /barcode) offline and transmit it in batch to the host device when needed. Memory Mode can be used among all the wireless profiles (2.4G Mode, BT HID, BT SPP, BT BLE). Follow below steps: 1. -
Page 14: Sleep Timeout
MT8120B User’s Manual V1.0 Sleep Timeout Sleep Timeout = 20 seconds Sleep Timeout = 2 minutes* Sleep Timeout = 5 minutes Sleep Timeout = 166 minutes & 44 seconds Sleep Timeout = Never Sleep Timeout = Immediate (Scanner Always On) -
Page 15: Buzzer
MT8120B User’s Manual V1.0 Buzzer Volume (Good Read and Power Up) High Volume* Medium Volume Low Volume Mute Volume (Power Up Only) High Volume* Medium Volume Low Volume Mute... -
Page 16: Frequency
MT8120B User’s Manual V1.0 Frequency High Frequency* Low Frequency Data Format Upper / Lower Case All Lower Case All Upper Case Invert Case As Is* Keyboard Layout English (US)* English (UK) - Page 17 MT8120B User’s Manual V1.0 German French Spanish Italian Swiss (German) Swiss (French) Dutch Belgian Danish Hungarian Swedish Norwegian...
- Page 18 MT8120B User’s Manual V1.0 Finnish Czech Slovak Polish Portuguese Brazilian Serbian Canadian French Croatian Slovene Latin America Universal...
-
Page 19: Terminator
MT8120B User’s Manual V1.0 Terminator Terminator = CR* Terminator = LF Terminator = Tab Terminator = CR + LF Terminator = None Surround GS1 Application Identifiers (AI’s) with Parentheses When enabled, all GS1 AI in barcode(GS1-128, GS1-DataMatrix, UDI…) will be surrounded with parentheses. -
Page 20: Code Id
MT8120B User’s Manual V1.0 Code ID When enabled, an ID will be added to the beginning of a barcode, indicating the type of symbology. Code ID Off* Code ID On Code ID Table Code ID Symbology UPC-A, UPC-E, EAN-8, EAN-13... -
Page 21: Data Editing (Insert/Delete Data)
MT8120B User’s Manual V1.0 Data Editing (Insert/Delete Data) @08900@ @08901@ @08999@ @08998@ Insert Delete Save Setting Clear Setting Scan numeric barcode in the ASCII Barcode Table (see Chapter 5) to define the position @09000@ @09254@ at which the data is... -
Page 22: Insert Data Example
MT8120B User’s Manual V1.0 Insert Data Example If unrelated barcode is scanned during the process, the scanner will exit configuration. Insert data in a Code128 encoded with 123456789 Follow step from top to bottom in each scenario. Scenario 1: Scenario 2:... -
Page 23: Delete Data Example
MT8120B User’s Manual V1.0 Delete Data Example If unrelated barcode is scanned during the process, the scanner will exit configuration. Delete data in a Code128 encoded with 123456789 Follow step from top to bottom in each scenario. Scenario 1: Scenario 2:... -
Page 24: Chapter 3 Reading Mode
MT8120B User’s Manual V1.0 Chapter 3 Reading Mode Trigger Mode In trigger mode, MT8120B starts scanning barcode when trigger is pressed, stops scanning barcode after trigger is released. When a barcode is successfully scanned or LED timeout (3 sec) expires, the scanning stops. -
Page 25: Auto-Sensing Mode - Sensitivity
MT8120B User’s Manual V1.0 Auto-sensing Mode – Sensitivity High* Medium Illumination and Aimer Illumination Normal* Always Off Always On Aimer Normal*... -
Page 26: Chapter 4 Symbologies
MT8120B User’s Manual V1.0 Always Off Always On Flash Not Flash Chapter 4 Symbologies General Settings Enable All Symbologies Disable All Symbologies Enable All 1D Symbologies Disable All 1D Symbologies Enable All 2D Symbologies Disable All 2D Symbologies... -
Page 27: Inverse Barcode
MT8120B User’s Manual V1.0 Inverse Barcode Enable All 1D Inverse Barcodes Disable All 1D Inverse Barcodes* Enable Inverse Data Matrix Disable Inverse Data Matrix* Enable Inverse QR Code Disable Inverse QR Code* Mirrored Barcode Enable Mirrored Data Matrix Disable Mirrored Data Matrix*... -
Page 28: Upc-A To Ean-13
MT8120B User’s Manual V1.0 Enable UPC-A* Disable UPC-A UPC-A to EAN-13 Disable UPC-A to EAN-13* Enable UPC-A to EAN-13 Check Digit Send Check Digit* Not Send Check Digit System Number Send System Number* Not Send System Number Supplement... -
Page 29: Supplement Required
MT8120B User’s Manual V1.0 Disable 2-digit Supplement* Enable 2-digit Supplement Disable 5-digit Supplement* Enable 5-digit Supplement Supplement Required Disable Supplement Required* Enable Supplement Required UPC-E Enable/Disable UPC-E Enable UPC-E* Disable UPC-E UPC-E to UPC-A Disable UPC-E to UPC-A* Enable UPC-E to UPC-A... -
Page 30: Enable/Disable Upc-E1
MT8120B User’s Manual V1.0 Enable/Disable UPC-E1 Enable UPC-E1* Disable UPC-E1 Check Digit Send Check Digit* Not Send Check Digit System Number Send System Number* Not Send System Number Supplement Disable 2-digit Supplement* Enable 2-digit Supplement... -
Page 31: Supplement Required
MT8120B User’s Manual V1.0 Disable 5-digit Supplement* Enable 5-digit Supplement Supplement Required Disable Supplement Required* Enable Supplement Required EAN-8 Enable/Disable EAN-8 Enable EAN-8* Disable EAN-8 Check Digit Send Check Digit* Not Send Check Digit Supplement... -
Page 32: Supplement Required
MT8120B User’s Manual V1.0 Disable 2-digit Supplement* Enable 2-digit Supplement Disable 5-digit Supplement* Enable 5-digit Supplement Supplement Required Disable Supplement Required* Enable Supplement Required EAN-13 Enable/Disable EAN-13 Enable EAN-13* Disable EAN-13 Check Digit Send Check Digit* Not Send Check Digit... -
Page 33: Supplement
MT8120B User’s Manual V1.0 Supplement Disable 2-digit Supplement* Enable 2-digit Supplement Disable 5-digit Supplement* Enable 5-digit Supplement Supplement Required Disable Supplement Required* Enable Supplement Required Bookland EAN (ISBN) Disable Bookland EAN* Enable Bookland EAN... -
Page 34: Issn
MT8120B User’s Manual V1.0 ISSN Disable ISSN* Enable ISSN Code128 Enable Code128* Disable Code128 GS1-128 (UCC/EAN-128) Enable GS1-128* Disable GS1-128 Interleaved 2/5 Enable/Disable Interleaved 2/5 Enable Interleaved 2/5* Disable Interleaved 2/5... -
Page 35: Min/Max Length
MT8120B User’s Manual V1.0 Min/Max Length To configure specific length, please scan Set Length, and scan four numeric barcodes (see Chapter 5). For example, if you want minimum length of 4 digits and maximum length of 20 digits, scan ‘0’, ‘4’, ‘2’, ‘0’ respectively. -
Page 36: Length
MT8120B User’s Manual V1.0 Length To configure specific length, please scan Set Length, and scan four numeric barcodes (see Chapter 5). For example, if you want minimum length of 4 digits and maximum length of 20 digits, scan ‘0’, ‘4’, ‘2’, ‘0’ respectively. -
Page 37: Length
MT8120B User’s Manual V1.0 Length To configure specific length, please scan Set Length, and scan four numeric barcodes (see Chapter 5). For example, if you want minimum length of 4 digits and maximum length of 20 digits, scan ‘0’, ‘4’, ‘2’, ‘0’ respectively. -
Page 38: Send Start & Stop
MT8120B User’s Manual V1.0 Enable Code39* Disable Code39 Send Start & Stop Send Start & Stop Not Send Start & Stop* Length Any Length* Verification Enable Verification Disable Verification* Check Digit Send Check Digit Not Send Check Digit*... -
Page 39: Full Ascii Code39
MT8120B User’s Manual V1.0 Full ASCII Code39 Enable/Disable Full ASCII Code39 Enable Full ASCII Code39 Disable Full ASCII Code39* Code32 Enable/Disable Code32 Disable Code32* Enable Code32 Code32 Preamble (‘A’) Disable* Enable Code93 Enable/Disable Code93 Enable Code93 Disable Code93*... -
Page 40: Length
MT8120B User’s Manual V1.0 Length Any Length* Code11 Enable/Disable Code11 Enable Code11 Disable Code11* Verification Enable Verification 1-Digit Verification 2-Digit Verification Check Digit Send Check Digit Not Send Check Digit*... -
Page 41: Codabar
MT8120B User’s Manual V1.0 Codabar Enable/Disable Codabar Enable Codabar Disable Codabar* Length Any Length* Start & Stop Format Start & Stop = ABCD/ABCD* Start & Stop = ABCD/TN*E Send Start & Stop Send Start & Stop* Not Send Start & Stop... -
Page 42: Msi Plessey
MT8120B User’s Manual V1.0 MSI Plessey Enable/Disable Plessey Enable MSI Plessey Disable MSI Plessey* Length Any Length* GS1 Databar Enable GS1 Databar Disable GS1 Databar* GS1 Composite Enable GS1 Composite Disable GS1 Composite*... -
Page 43: Qr Code (Incl. Micro Qr Code)
MT8120B User’s Manual V1.0 QR Code (incl. Micro QR Code) Enable QR Code* Disable QR Code Data Matrix Enable Data Matrix* Disable Data Matrix PDF417 Enable PDF417* Disable PDF417 Aztec Enable Aztec Disable Aztec*... -
Page 44: Maxicode
MT8120B User’s Manual V1.0 MaxiCode Enable MaxiCode Disable MaxiCode* Chinese Sensible Code (Han Xin) Enable Disable* Not Send ECI* Send ECI Febraban Enable Febraban Disable Febraban*... -
Page 45: Chapter 5 Configuration Barcode
MT8120B User’s Manual V1.0 Chapter 5 Configuration Barcode Numeric Barcode Below configuration barcodes are only applicable for Length configuration. -
Page 46: Cancel
MT8120B User’s Manual V1.0 Cancel To cancel the wrong data input during configuration process (e.g. ), scan Cancel. Cancel... -
Page 47: Ascii Barcode Table
MT8120B User’s Manual V1.0 ASCII Barcode Table Below configuration barcodes are only applicable for Data Editing configuration. NUL/SP Back Space HT/TAB CR/ENTER... - Page 48 MT8120B User’s Manual V1.0 “ & ‘...
- Page 49 MT8120B User’s Manual V1.0 < >...
- Page 50 MT8120B User’s Manual V1.0...
- Page 51 MT8120B User’s Manual V1.0 l_Shift on l_Shift off r_Shift on r_Shift off l_Alt on l_Alt off r_Alt on r_Alt off l_Ctrl on l_Ctrl off r_Ctrl on r_Ctrl off /(KP)
- Page 52 MT8120B User’s Manual V1.0 *(KP) -(KP) +(KP) _(KP) Enter(KP) 0(KP) 1(KP) 2(KP) 3(KP) 4(KP) 5(KP) 6(KP) 7(KP) 8(KP) 9(KP) Inert Delete Home Page Up Page Down Down Left Right Center Insert Delete Home...
- Page 53 MT8120B User’s Manual V1.0 Page Up Page Down Down Left Right Num Lock caps lock scroll lock...
-
Page 54: Appendix
MT8120B User’s Manual V1.0 Appendix Appendix A – Default Table Function Default Remark USB Mode USB HID out of box HID Speed HID-Slow out of box Memory Mode Memory Mode Off Memory Mode – Upload Speed Sleep Timeout 2 minutes... - Page 55 MT8120B User’s Manual V1.0 Check Digit Send System Number Send 2-digit Supplement Disable 5-digit Supplement Disable Supplement Required Disable UPC-E Enable/Disable Enable UPC-E to UPC-A Disable Enable/Disable UPC-E1 Enable Check Digit Send System Number Send 2-digit Supplement Disable 5-digit Supplement...
- Page 56 MT8120B User’s Manual V1.0 Check Digit Not Send Industrial 2/5 Enable/Disable Disable Length Any Length Standard 2/5 Enable/Disable Disable Length Any Length Code39 Enable/Disable Enable Start & Stop Not Send Length Any Length Verification Disable Check Digit Not Send Full ASCII Code39...
- Page 57 MT8120B User’s Manual V1.0 Enable/Disable Enable PDF417 Enable/Disable Enable Aztec Enable/Disable Disable MaxiCode Enable/Disable Disable Chinese Sensible Code (Han Xin) Enable/Disable Disable Febraban Enable/Disable Disable...
-
Page 58: Version History
MT8120B User’s Manual V1.0 Version History Date Description Issued 2024.06.19 Initial Release Shaw...
