For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
The following change was recently made since the owner's manual was printed:
•
Anti-kickback pawl has changed.
Aside from this information, all other content in the owner's manual applies and MUST be read and under-
stood for your own safety. IMPORTANT: Keep this update with the owner's manual for future reference.
For questions or help, contact our Tech Support at (570) 546-9663 or techsupport@grizzly.com.
Revised Parts
REF PART #
DESCRIPTION
93V2 P0603X093V2
ANTI-KICKBACK PAWL V2.06.23
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
READ THIS FIRST
93V2
COPYRIGHT © APRIL, 2023 BY GRIZZLY INDUSTRIAL, INC.
#JM22693 PRINTED IN TAIWAN
Model G0603X
***IMPORTANT UPDATE***
For Machines Mfd. Since 06/23
and Owner's Manual Revised 10/19
