  • Page 1 BPC224-02 PowerGem Plus RT 6-10kVA USER MANUAL - 0 -...

  • Page 2: Table Of Contents

    CONTENTS PAGE No CHAPTER 1 Safety Safety notes Symbols used in this guide CHAPTER 2 Main Features Summarization Functions and Features CHAPTER 3 Installation Unpack checking UPS Module Outlook LCD control panel Installation notes External Protective Devices Power Cables Power cable connect Battery connection UPS Multi－Module Installation CHAPTER 4 Operation...

  • Page 3: Chapter 1 Safety

    1．Safety 1.1 Safety notes 1. With no connection from utility power, 208/220/230/240VAC voltage may still exist at the UPS outlet terminals 2. For Health & Safety, The UPS system should be correctly grounded before starting. 3. Don’t open or damage battery casing, Internal Acid spilled from the battery is strongly poisonous and harmful to the body 4.

  • Page 4: Main Features

    2．Main Features 2.1 Summarization This BPC PowerGem Plus RT UPS is a single phase in single phase out high frequency online UPS, it is available as either a 6kVA or 10kVA system. The UPS Systems can be connected in parallel and adopt N+X redundancy. The number of UPS modules can be flexibly increased according to the load capacity providing easy installation and gradual investment.

  • Page 5: Chapter 3 Installation

    3．Installation 3.1 Unpack checking 1. Don’t lean the UPS when moving it out from the packaging 2. Complete a visual check to see if the UPS has been damaged during the transportation, do not switch on the UPS if any damage is found. Please contact the dealer right away.

  • Page 6: Lcd Control Panel

    3.3 LCD control panel (1) INVERTER LED (5) LCD display (2) BATTERY LED (6) UP button (3) BYPASS LED (7) DOWN button (4) ALARM LED (8) ESC /OFF button (9) ENTER/ON button 3.4 Installation notes ◆ Please place the UPS in a clean, stable environment, avoid vibration, dust, humidity, flammable gas and liquid, corrosive objects.

  • Page 7: External Protective Devices

    WARNING! Typical battery performance data are quoted for an operating temperature of 20°C. . Operating it above this range will reduce the battery life while operation below this range will reduce the battery capacity.  Should the equipment not be installed immediately it must be stored in a room so as to protect it against excessive humidity and or heat sources.

  • Page 8: Power Cables

    3.6 Power Cables ◆ The cable design shall comply with the voltages and currents provided in this section, Kindly follow local wiring practices and take into consideration the environmental conditions (temperature and physical support media) . WARNING！ UPON STARTING, PLEASE ENSURE THAT YOU ARE AWARE OF THE LOCATION AND OPERATION OF THE EXTERNAL ISOLATORS WHICH ARE CONNECTED TO THE UPS INPUT/BYPASS SUPPLY OF THE MAINS DISTRIBUTION PANEL.CHECK TO SEE IF THESE SUPPLIES...

  • Page 9: Power Cable Connect

    3.7 Power cable connect Once the equipment has been finally positioned and secured, connect the power cables as described in the following procedure. Verify the UPS is totally isolated from its external power source and also all power isolators of the UPS are open. Check to see if they are electrically isolated, and post any necessary warning signs to prevent their inadvertent operation.

  • Page 10: Battery Connection

    3.8 Battery connection The UPS uses a positive and negative double battery framework, total 16 (optional 18/20) pieces in series. A neutral cable is retrieved from the joint between the cathode of the 8 ) and the anode of the 9 ) of the batteries.

  • Page 11: Ups Multi－Module Installation

    3.9 UPS Multi－Module Installation The basic installation procedure of a parallel system comprising of two or more PowerGem Plus RT UPS modules is the same as that of single module system. The following sections introduce the installation procedures specified to the parallel system. 3.9.1 Cabinet installation Connect all the UPS systems needed to be put into parallel system as below picture.
  • Page 12 3.9.2 Parallel cable installation Shielded and double insulated control cables available must be interconnected in a ring configuration between UPS modules as shown below. The parallel control board is mounted on each UPS module. The ring configuration ensures high reliability of the control.

  • Page 13: Chapter 4 Operation

    4．Operation 4.1 Operation Modes The PowerGem Plus RT UPS is a double-conversion on-line UPS that may operate in the following alternative modes ： ◆ Normal mode The rectifier/charger derives power from the AC Mains and supplies DC power to the inverter while floating and boosting charge the battery simultaneously.

  • Page 14: Turn On/Off Ups

    4.2 Turn on/off UPS 4.2.1 Connecting with Utility CAUTION! MAKE SURE GROUNDING IS PROPERLY DONE! Check to see if the load is safely connected with the output of the UPS. If the load is not ready to receive power from the UPS, make sure that it is safely isolated from the UPS output terminals.

  • Page 15: Lcd Display Instruction

    4.2.3 Inverter Off ◆ When the Utility is normal, press “ESC /OFF” button for approx. 1 sec until beep sounds, the inverter LED will extinguish, the bypass LED on, then the UPS turns to bypass supply. ◆ When the UPS is on battery mode or without AC, press “ESC /OFF” button for approx.
  • Page 16 1. When the UPS is connected with the Utility or Battery at cold start mode, it shows as drawing below: (1) Operational Status and mode 1) Operational Status and mode When the UPS at single mode, it shows “NOA” or “ECO”or“CF”, but If the UPS at parallel mode, it shows “PAL”...

  • Page 17: Parameters Setting

    4.4 Parameters setting The setting function is controlled by 4 buttons (ENTER/ON, ESC/OFF, UP,DOWN): ENTER  goes into the setting page and value adjustment; UP & DOWN for choosing different pages. After the UPS is turned ON, press the UP & DOWN buttons for 5 seconds to enter into the setting interface page.
  • Page 18 4.4.3 Output frequency setting Frequency setting (Note: Inside the broken-line is the flashing part.) When under the output voltage setting press DOWN or when under battery capacity setting press UP, it goes to the frequency setting. The frequency line flashes as in above picture.
  • Page 19 4.4.5 Battery quantity setting Battery quantity setting (Note: Inside the broken-line is the flashing part.) When under the battery capacity setting press DOWN or when under bypass voltage upper limit setting press UP, it goes to the battery quantity setting. The battery quantity line flashes as in above picture.
  • Page 20 4.4.7 Bypass Volt-Lo setting Bypass voltage lower limit setting (Note: Inside the broken-line is the flashing part.) When under the bypass voltage upper limit setting press DOWN or when under parallel ID setting press UP, it goes to the bypass lower limit setting. The bypass lower limit line flashes as in above picture.
  • Page 21 4.4.9 Battery Test Setting This page is the introduction to the Battery self-test setting. The default Settings is “OFF” when the UPS has no need of the battery self-test function. When turn to “ON”, batteries can do the self-test automatically per 30 days. Three kinds of Battery Self-test Time can be chose as below.
  • Page 22 4.4.10 Parallel ID setting Parallel ID setting (Note: Inside the broken-line is the flashing part.) When under the bypass voltage lower limit setting press DOWN or when under parallel quantity setting press UP, it goes to the parallel ID setting. The parallel ID flashes as in above picture.

  • Page 23: Appendix 1 Specifications

    4.4.12 Parallel redundancy quantity setting Parallel redundancy quantity setting (NOTE: Inside the broken-line is the flashing part.) When under the parallel quantity setting press DOWN, it goes to the parallel redundancy quantity setting. The parallel redundancy quantity flashes as in above picture. ...
  • Page 24 Output type Single phase + Ground ±1.0%； Output precision ≤2% at 100% liner load Voltage distortion （THD） ≤5% at 100% non-liner load Rating voltage 208/220/230V/240Vac Frequency precision ±0.1% Rating Frequency 50Hz/60Hz Freqency track speed 1Hz/s 105%~110%，10min Overload 110%~130% 1min ≥130% 200ms Peak value factor ≥93% Efficiency at normal...

  • Page 25: Communication Port Definition

    Appendix 2 Communication port definition USB communication port: Definition of Male port： Pin 1 VCC , Pin 2 D- pin 3 D+ , Pin 4 GND Application: UPSilon2000 Power Management software Available functions of the USB ■ Monitor UPS power status ■...
  • Page 26 Item UPS Alarm Warning Buzz Reserve Beep continuously Fault LED lit Auxiliary power fault Beep continuously Fault LED lit Initialization fault Beep continuously Fault LED lit P-Battery Charger fault Beep continuously Fault LED lit N-Battery Charger fault Beep continuously Fault LED lit DC Bus over voltage Beep continuously Fault LED lit...
