- Page 1 HP-100 SERIES UNINTERRUPTIBLE POWER SUPPLIES ( 1 Phase Input & Output ) HP-115 ( NS151A ) USER MANUAL...
-
Page 3: Table Of Contents
CONTENTS SAFETY........................... 1 II. INTRODUCTION ........................2 2.1 System Description ......................2 2.2 Technical Specifications....................4 III. INSTALLATION........................6 3.1 Unpacking ........................6 3.2 Location Selection......................6 3.3 Cable Connections ......................6 3.4 Start-Up ..........................8 IV. OPERATING PROCEDURE ....................9 4.1 Turn On procedure...................... -
Page 5: Safety
I. SAFETY This manual contains important instructions for HP-100 series UPS that should be followed during installation and maintenance. IMPORTANT NOTICES 1. Read instructions carefully before operating the UPS 2. All warnings in the manual should be adhered to. 3. All operating instructions should be followed. 4. -
Page 6: Introduction
II. INTRODUCTION Thank you for selecting this uninterruptible power supply (UPS). To choose the HP-100 series as your equipment protector was a wise investment. It includes many features to protect your critical equipments. The HP-100 series UPS system is connected between mains and critical loads, such as computer systems, telecommunication systems, computerized instruments etc. - Page 7 Mechanical Transfer Switch Static Transfer Switch Static By-Pass Input Output Inverter Rectifier Battery Group Battery Charger Figure 2.1 UPS Block Diagram Rectifier : The first stage of the UPS. It supplies the DC bus voltage, which is necessary for operating the inverter by rectifying line voltage.
-
Page 8: Technical Specifications
2.2 Technical Specifications HP-115 Power 15 kVA Power Factor Automatic Battery Test Optional Alarm Relays RS 232 INPUT Input Voltage 220 or 230 VAC 1Ph + N Input Voltage Tolerance + 15%, -20% 220 or 230 VAC ±10% By-pass Voltage... - Page 9 Figure 2.2 Front View RS232 and Alarm Contact Outputs On / Off Switch AC Output Connections F1 - AC Input Fuse F2 – Batt. (+) Fuse F3 – Batt. (-) Fuse Rear View...
-
Page 10: Installation
UPS. 2. Carefully open the carton and take the UPS out. 3. Retain the carton and packing material for future use. Unit package contents : HP-115 User Manual Guarantee Certificate Battery Cabinet... - Page 11 The safety earth cable must be connected to the earth bus bar and bonded to each cabinet in the system. All cabinets should be earthed in accordance with local regulations. The UPS itself has no effect on the earthing quality i.e. it doesn’t change the unwanted voltage difference between the earth and neutral lines.
-
Page 12: Start-Up
3.4 Start-Up 1. Turn on the Main Switch on the rear panel. (In this case, there is line voltage at the output and battery charger board is active) 2. Turn the On-Off Switch PK1 on the rear panel to "1" position. In a few seconds the cooling fan will start to operate, then the red LED "by-pass"... -
Page 13: Operating Procedure
IV. OPERATING PROCEDURE 4.1 Turn On procedure 1. Turn on the Main Switch on the rear panel to "1" position. (There is line voltage at the output.) 2. Turn on the On-Off Switch PK1 on the rear panel to the "1" position. Turn on the power switches on your critical load after the "Inverter"... -
Page 14: Front Panel
V. FRONT PANEL WARNING! The messages in this section are applicable for equipments having software version Y12C. If the version changes, the messages and functions will change as well. 5.1 Introduction The front panel of UPS, consisting of a 2 lines alphanumeric display, 2 status lamps, plus 3 function keys, allows the complete monitoring of the UPS status. -
Page 15: Main Menu
SAMPLE menu selection : If you want to go to MEASURES menu use DOWN keys and find MEASURES MENU, press ENTER key, now you can move on MEASURES menu subitems by DOWN keys. At the end of sub menus ENTER (EXIT) message is available and while reading this message, if you press ENTER key you can go back to MAIN menu. -
Page 16: Measures Menu Items
Submenu item Function The purpose of this submenu to check dry contact connections. Normally to check line failure contact you must turn off mains power. This is not necessary with this utility. 3 options are available. SIMULATION OFF simulation mode is off SIM:LINE FAILURE if you press ENTER key for 3 seconds the line failure lamp SIMULATION:OFF on interface board is turned on. -
Page 17: User Options Menu Items
5.3.4 USER OPTIONS Menu items From this menu the user selects some important parameters and apply them. Submenu item Function 4 Operating modes can be selected using up and down buttons. ONLINE: normal operating mode. PARALLEL: Symmetric parallel operation mode of 2 UPS’s. MOD:ONLINE HOT STANDBY: 1 UPS is master and 1 UPS is redundant operating mode. -
Page 18: Time Menu Items
5.3.5 TIME Menu items You can see date and time of RTC (real time clock) on UPS. And you can adjust date and time. Submenu item Function TIME: 00:00 time DATE: XX-XX-20XX date SET HOURS: (+) and (-) adjust hours (0-23) SET MINS : (+) and (-) adjust minutes (0-59) SET DAY :... -
Page 19: Fault Messages And Quick Troubleshooting
5.4 Fault messages and quick troubleshooting All alarms contained in Y12C version are listed in the following table. ALARM POSSIBLE CAUSE A1 BYP FAILURE Bypass system failure. Bypass elements may be broken. A2 INV FAILURE Inverter digital start system is failed. Call the service. Overtemperature in UPS repeated 3 times in 30 min. -
Page 20: Status Messages
ALARM POSSIBLE CAUSE In parallel operation the slave device tries to operate as the same mode as the master device, If the modes are different this message will appear. A23 MODE FAILURE Change the mode of the slave UPS from USER OPTION MENU. Press ENTER button for 3 seconds after mode selection, then restart the UPS. -
Page 21: Optional Equipment
VI. OPTIONAL EQUIPMENT 6.1 Software Options The UPS can send digital data (optional) to the computer thought the RS232 port. No additional card is needed. It also has two alarm relays: Line failure and battery low. Computer systems require time to perform an orderly shutdown, without corrupting or losing data In an extended power failure, a computer system protected by a UPS eventually will lose power when the battery is exhausted. -
Page 22: Snmp Module
6.2 SNMP Module Using the SNMP module, your UPS is seen as a network device in your WAN or LAN applications, and with this way it can be monitored more than one UPS’s connected to your network through SNMPVIEW Software supplied with the module or it is possible to monitor the UPS through an Internet Browser. -
Page 23: Remote Monitoring Panel (Rmp)
6.4 Remote monitoring panel (RMP) You can see UPS status and parameters without using a computer up to 200 meters ( via RS485 interface). And you can connect more than one remote panel in cascade for monitoring your UPS system from several different locations at the same time. - Page 25 ( T-MON ) COM1 Connection Diagram Of The RMP...
-
Page 26: Customer Service
VII. CUSTOMER SERVICE WARNING! There are no customer serviceable components inside. DO NOT open the cover or attempt to service the unit. High voltage may remain when the unit is shut down. Unauthorized service will void the warranty and could cause serious injury. 7.1 Maintenance The unit is designed for easy maintenance. -
Page 27: Limited Warranty
VIII. LIMITED WARRANTY The UPS is warranted against all defects in workmanship and materials under normal use for a period of one ( ) year from the date of shipment to the original user. The conditions of this warranty and the extent of responsibility of ………………………………………………………………………………………………………………………….. - Page 28 AGKK8480 06/2009...
