POWER PRIME 310 –330
USER MANUAL
BPC521-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWER PRIME 310 and is the answer not in the manual?

Questions and answers

Related Manuals for BPC POWER PRIME 310

Summary of Contents for BPC POWER PRIME 310

  • Page 1 POWER PRIME 310 –330 USER MANUAL BPC521-01...
  • Page 2 Please comply with all warnings and operating instructions in this manual. This equipment should only installed, serviced, maintained by qualified personnel. Do not operate this unit before reading through all safety information and operating instructions carefully. Disclaimer We assume no responsibility or liability for loss or damages, whether direct, indirect, consequential or incidental, which might arise out of the use of such information.

  • Page 3: Table Of Contents

    Table of Contents 1. SAFETY AND EMC INSTRUCTIONS .......................... 1 1-1. T ..........................1 RANSPORTATION AND TORAGE 1-2. P ................................1 REPARATION 1-3. I ................................1 NSTALLATION 1-4. C ............................. 2 ONNECTION ARNINGS 1-5. O .................................. 3 PERATION 1-6. S .................................

  • Page 4: Safety And Emc Instructions

    1. Safety and EMC instructions All safety instructions in this document must be read, understood and followed. 1-1. Transportation and Storage Please transport the UPS system only in the original packaging to protect against shock and damage. The UPS must be stored in a room where the temperature is well regulated. Ambient temperature should not exceed 40°C.

  • Page 5: Connection Warnings

    1-4. Connection Warnings • There is no standard backfeed protection inside of the UPS. However, there are relays on the Input to cut off line voltage and while the neutral is still connected to UPS. Input Rly Main Input Input relay diagram Input relay diagram for dual-input model •...

  • Page 6: Operation

    1-5. Operation Do not disconnect the grounding/earthing conductor cable on the UPS or to the building wiring terminals under any circumstance. The UPS system features its own, internal current source (batteries). The UPS output sockets or output terminal blocks may be electrically live even if the UPS system is not connected to the building mains/live wires.

  • Page 7: Installation And Operation

    2. Installation and Operation 2-1. Unpacking and Inspection Unpack the package and check the package contents. The shipping package should contain: ● One UPS ● One user manual ● One monitoring software CD ● One RS-232 cable (option) ● One USB cable ●...

  • Page 8: Rear System View

    2-2. Rear System View...
  • Page 9 1. RS232 Port – Port is used by Maintenance Service engineer to enable updates to internal firmware of the UPS System. Not for Customer Use 2. USB Port – Communication port for Customer to connect monitoring Software directly to local PC, provides Alarms and functional monitoring.
  • Page 10 21. INPUT DRY PORT Provides up to 8 input functions for operating UPS system Contact Message Description Remote on Remote activation to switch UPS on Remote activation to switch UPS off (to Remote Off bypass) Shutdown - Restore UPS stops and restarts in 1min Generator Detection Activates internal generator functions.

  • Page 11: Single Ups Installation

    2-3. Single UPS Installation Installation and wiring must be carried out in accordance with the local installation regulations by trained professionals. Make sure that the mains cable and breakers of the building are rated for the capacity of the UPS to prevent electric shock or risk of fire.
  • Page 12 NOTE 1: Make sure that the wires are connected tightly with the terminals. Put the terminal block cover back at the rear panel of the UPS. Warning: ● Make sure a DC breaker or other protective device between UPS and the external battery pack is installed.

  • Page 13: Ups Installation For Parallel System

    2-4. UPS Installation for Parallel System If the UPS is being installed for single operation, you may skip this section. 1) Connect the Parallel (dash lines) & Current Share cables as per the following drawings: 2 X SYSTEM IN PARALLEL 3 X SYSTEMS IN PARALLEL 2) Install and cable the UPS according to the section 2-3.

  • Page 14: Operations

    3. Operations 3-1. Initial Operation 1) Before operation, make sure that the two string halves of batteries are connected correctly in order of ”+,GND,-” terminals and the breaker of the battery pack is at “ON” position. 2) Start up UPS system by closing the Input and Bypass breakers, check all settings and configurations before starting up the UPS fully in section 3-4.
  • Page 15 Upon powering on, the LCD will start initialisation after a few seconds as shown below. Main screen After initialisation, the main screen will display as shown below. On the bottom, there are five icons to represent five sub-menus: CONTROL, MEASURE, SETTING, INFO, DATALOG. 3-2-1 Control screen Touch the icon to enter control sub-menu.
  • Page 16 Enter No Or Back Confirm YES Turn ON /OFF UPS ON/OFF UPS Enter No Or Back Confirm YES Do Battery Test HOME CONTROL BATTERY TEST Enter No Or Back Confirm YES Do MUTE ALL MUTE ALL Enter No Or Back Confirm YES Turn ON/OFF CHARGER ON/OFF CHARGER Screen 1.0 «Control»...
  • Page 17 Audio mute ➢ It will show “Mute all” if the audio is active. Touch “Yes” to activate mute. If “Mute all” is active, it will show icon on the top left corner of the main screen. Touch “Back” to return to CONTROL screen immediately or “No”...
  • Page 18 EXIT PARALLEL In the case of multiple machines in parallel, clicking this option will pop up the “Exit Parallel?” interface; Click "Yes" to exit the machine from the current parallel system; Click "No" to cancel this operation and return to the operation interface. In the case of a single machine, clicking this option will pop up the "This mode can’t be SETUP!".
  • Page 19 Measure screen page 2 OUTPUT W: L1, L2 & L3 output power in watt. ➢ OUTPUT VA: L1, L2 & L3 output power in VA. ➢ OUTPUT W (%): L1, L2 & L3 output power watt in percentage. ➢ OUTPUT VA (%): L1, L2 & L3 output power VA in percentage. ➢...
  • Page 20 3-2-4. Setting screen This sub-menu is used to set the parameters of UPS. Touch the icon to enter setting menu page. There are 2 options: General and Advanced. Touch the icon to return to main screen. Touch the icon to go back to previous menu. NOTE: Not all settings are available in every operation mode.
  • Page 21 Service Phone: Set the service phone number. Only 0~9, + and – are accepted. The maximum ➢ length is 14 characters. Service Mail: Set the service email accounts up to two and the maximum length is 36 characters. ➢ General screen page 2 Audio Alarm: There are two events available to mute.
  • Page 22 ADVANCE Advance Password Page It’s required to enter password (4 digits) to access to the “ADVANCE” page. ADVANCE ➔ ➢ To access to the “Advance➔User” Setting menu page, ENTER Password. If entered password is right, the page will jump to setting screen. If the password is wrong, it will ask to enter again.
  • Page 23 ELECTRONIC Electrical Setting Page 1 Output Voltage: Select the output rated voltage. ➢ There are four options, 208V, 220V ,230V and 240V. ◼ Output Frequency: Select output rated frequency. ➢ 50Hz: The output frequency is setting for 50Hz. ◼ 60Hz: The output frequency is setting for 60Hz. ◼...
  • Page 24 Electrical Setting Page 2 Bypass at UPS off: Select the bypass status when manually turning off the UPS. This setting is only ➢ available when “Bypass forbid.” is set to “Disable”. Enable: Bypass enabled. When selected, bypass mode is activated. ◼...
  • Page 25 BATTERY Battery setting page Battery Warning Voltage: ➢ HIGH: High battery warning voltage. The setting range is 14.0V ~ 15.0V. 14.4V is default setting. ◼ LOW: Low battery warning voltage. The setting range is 10.1V ~ 14.0V. 11.4V is default setting. ◼...
  • Page 26 3-2-5. Information screen Touch the icon to enter information page. Touch the icon to browse information. Touch the icon to return to main screen. Touch the icon to go back to previous menu. Basic Information Page1 Basic Information MCU Version: MCU version. ➢...
  • Page 27 Rated Information Page Rated Information Output Voltage: It shows output rated voltage. ➢ Output FRE: It shows output rated frequency. ➢ CVCF Mode: Enable/Disable CVCF mode. ➢ Bypass Forbid: Enable/disable bypass function. ➢ Bypass UPS Off: Enable/disable auto bypass function when UPS is off. ➢...

  • Page 28: Data Log Screen

    Parameter Information Page 2 BATT Mode Work Time: The maximum discharge time in battery mode. ➢ BATT Warning Voltage: ➢ HIGH: High battery warning voltage. ◼ LOW: Low battery warning voltage. ◼ ➢ Shutdown Voltage: If battery voltage is lower this point, UPS will automatically shut down. Shutdown Delay: UPS will shut down in setting minutes.

  • Page 29: Audible Alarm

    3-3. Audible Alarm Description Buzzer status Muted UPS status Bypass mode Beeping once every 2 minutes Battery mode Beeping once every 4 seconds Fault mode Beeping continuously Warning Overload Beeping twice every second Others Beeping once every second Fault Beeping continuously 3-4.
  • Page 30 5) If the overload time is reached in the UPS spec at AC mode, the UPS will automatically transfer to Bypass mode. After the overload is removed, it will return to AC mode. If the overload time is reached in the UPS spec during Battery mode and if bypass is enabled, the UPS will power to the load via bypass.

  • Page 31: Parallel Operation

    10. Operation in warning status 1) When Fault LED illuminates and the buzzer beeps once every second, there are problems for UPS operation. Users can read the warning message(s) from “DATA LOG” menu. Please refer to the Section 3-2-6 for details. 11.

  • Page 32: Fault Code

    2. Add new units into the parallel system 1) You cannot add a new unit into the parallel system when the whole system is running. You must cut off the load and shutdown the system or transfer load to external bypass mode if available. 2) Make sure all of the UPS are parallel models, and follow the wiring refer to section 2-4.

  • Page 33: Warning Code

    Inverter C negative power fault None Bypass O/P line to line short None circuited Battery SCR short circuited None Inverter SCR short circuited None Inverter relay circuited open None BUS voltage drops too fast None Inverter relay short circuited None Current error value detect None Line wiring fault...

  • Page 34: Trouble Shooting

    UPS output. circuit status. Other fault codes are shown on LCD display and alarm beeps A UPS internal fault has occurred. Contact BPC continuously. Charge the batteries for at least 7 hours and then check Batteries are not fully charged.

  • Page 35: Storage And Maintenance

    5. Storage and Maintenance 5-1. Storage Before storing, charge the UPS for at least 7 hours. Store the UPS covered and upright in a cool, dry location. During storage, recharge the battery in accordance with the following table: Storage Temperature Recharge Frequency Charging Duration -25°C - 40°C...

  • Page 36: Specifications

    6. Specifications 400V MODEL PPRIME 10K PPRIME 20K PPRIME 30K CAPACITY* 10KVA / 10KW 20KVA / 20KW 30KVA / 30KW INPUT 110 VAC(Ph-N) ± 3 % at 50% Load Low Line Loss 176 VAC(Ph-N) ± 3 % at 100% Load Voltage Low Line Comeback Low Line Loss Voltage + 10V...

  • Page 37: Options

    7. Options 7-1 SNMP CARD - OPTIONAL MEDA806 is an SNMP (Simple Network Management Protocol) card for monitoring the PowerPrime UPS. The SNMP Card provides the ability to monitor the UPS remotely and provide some control. Features: • Provide SNMP MIB to monitor & control UPS •...

  • Page 38: Netfeeler Environment Monitoring Card

    Provides Shutdown Utilities The computer/server must install the provided shutdown software and the device must be connected to the same network as the SNMP. When the UPS goes into an AC failure condition or Battery Low condition, the software can close all running files of the operating system and shutdown gracefully. This avoids system corruption when a power disconnection happens.
