1.5 Detailed View of Charger
CSU 3.0 Board
Fan Control board
Relay controler board
Emergency
Button
DC contactor
X1. X3. X4
connector panel
Assistant
switch
EMI Box (optional)
Breaker
AC Contactor
Figure 4. Detailed View of Charger
Display
Push Botton
RFID
LED Control board
DC EVSE Standalone DC Fast Charger 9
Emergency
Button
