Evaluation Board User Guide
5 3 C32, C34, C35
6 1 C38
7 1 C39
8 1 C68
9 1 C98
10 1 D4
11 1 D6, D7
12 3 R3, R12, R26
13 2 R6, R13
14 1 R10
15 1 R49
16 1 Q1
17 1 Q2
18 1 U5
19 1 U6
20 1 U7
HARDWARE: FOR EVALUATION BOARD ONLY
E1, E2, E3, E4,
1 6
E18, E19
E5, E6, E7, E9,
2 10 E10, E11, E12,
E13, E14, E15
3 2 J1, J2
4 2 J3, J4
5 2 J5, J6
6 1 J7
7 1 JP1
MP1, MP2, MP3,
8 4
MP4
9 1 SW1
10 1 XJP1
analog.com
CAP., 1µF, X7R, 6.3V, 10%, 0402
CAP., 1µF, X7R, 50V, 10%, 0603
CAP., 0.01µF, X7R, 25V, 10%, 0603
CAP., 270µF, ALUM POLY HYB, 25V,
20%, 8x10.2mm
CAP., 1µF, X5R, 50V, 10%, 0603
LED, GREEN, DIFFUSED, 0603
LED, RED, DIFFUSED, 0603
RES., 866Ω, 1%, 1/10W, 0603
RES., 4.99kΩ, 1%, 1/10W, 0603
RES., 49.9Ω, 1%, 1/10W, 0603
RES., 10mΩ, 1%, 3W, 6.3 X3.1mm
MOSFET, N-CH, 25V, 70A, Power-SO8
MOSFET, N-CH, 60V, 300mA, SOT-23-3
IC, EEPROM, 2Kb (256x8), TSSOP-8
IC, 2.6A, 2.5V-5.5V IDEAL DIO, 10DFN
IC, 200mA LDO, MSOP-8
TEST POINT, TURRET, 0.064"
TEST POINT, TURRET, 0.094"
BANANA JACK, FEMALE
STUD, FASTENER, #10-32
CONN., RF, BNC, RCPT
CONN., HDR, MALE, 2x6, 2mm
CONN., HDR, MALE, 1x3, 2mm
STANDOFF, NYLON, SNAP-ON, 0.625"
SWITCH, SLIDE, DPDT, 0.3A, 6VDC, PTH C&K, JS202011CQN
CONN., SHUNT, FEMALE, 2-POS, 2mm
EVAL-LT7171-1-AZ
MURATA, GRM155R70J105KA12D
AVX, 06035C105KAT2A
AVX, 06033C103K4Z2A
PANASONIC, EEH-ZK1E271P
TDK, CGA3E3X5R1H105K080AB
BROADCOM INC., HSMG-C190
BROADCOM INC., HSMH-H190
PANASONIC, ERJ3EKF8660V
PANASONIC, ERJ3EKF4991V
PANASONIC, ERJ3EKF49R9V
SUSUMU, KRL6432E-C-R010-F-T1
NEXPERIA, PSMN5R4-25YLDX
VISHAY, 2N7002K-T1-GE3
MICROCHIP, 24LC025-I/ST
ANALOG DEVICES,
LTC4413EDD#PBF
ANALOG DEVICES, LT3063EMS8E-
3.3#PBF
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
PENNENGINEERING, KFH-032-
10ET
AMPHENOL RF, 112404
AMPHENOL, 98414-G06-12ULF
WURTH ELEKTRONIK,
62000311121
KEYSTONE, 8834
WURTH ELEKTRONIK,
60800213421
Rev. A 9 of 13
