CyClone Alito SC300 Use And Care Manual

OPERATION INSTRUCTIONS
Fan Operation
Fan Speeds: Three speed settings give the customer total control of their fan at the push of
a button.
Timer: This collection features a time-delay off feature to automatically shut the fan off after
1 to 9 minutes to conveniently clear the smoke and grease after cooking. To program the
time-delay feature, press the button with the clock icon while the machine is on and then use
the lowest speed setting button to toggle between 1 to 9 minutes.
Grease Disposal
WARNING!
Do not remove filters or grease cups immediately after cooking or if grease is
still hot.
Nonstick-coated fan blades will separate grease from the air and the grease will then be
deposited into a grease cup for easy, convenient disposal. You will find the grease cup in a
bag with the bracket and screws in the box. The grease cup can be used in conjunction with
the mesh filters with certain models, while others can only use one or the other.
Tip: Soak all parts in soapy water if there is heavy grease.
Changing Light bulbs
WARNING!
Ensure that all power leading to your range hood has been disconnected
before changing bulbs. As well, ensure that lights have fully cooled before changing bulbs.
To change the light bulb, remove light case from the light socket. The light case can be
accessed from the inside of the body of the machine.
1. Disconnect the connecting wires of the light socket from the motherboard wires.
2. Remove grease filters and push light case outward away from the machine.
3. Replace with a new case.
Baffle Filters
WARNING!
Ensure that all power leading to your range hood has been disconnected
before removing filters and cleaning your fan.
Removal: To remove the baffle filters, locate the latch at the top of the filter and pull downwards
away from the machine.
Disassembly: To disassemble the baffle filter, locate the screw on the back of the filter,
unscrew and remove. Place screw in a safe place. Pull on latch to release the inner portion
from outer portion, then separate the two halves of the filter. The two filters can then be
placed in the bottom rack of the dishwasher or may be cleaned using stainless steel cleaner
or dishwashing detergent and water.
Reassembly: To reassemble the baffle filter, first place the two pieces of the filter against
each other(one inner piece, one outter piece). When placing the filter together, ensure that all
tabs fit into the slots to keep both pieces of the filter attached. Once both halves of the baffle
filters are securely in place, screw the screw back onto the filter.
USE AND CARE GUIDE
MODELS
SC(B)500
SC(B)300
Power/Timer
Fan
Light
Control
Control
Fan Housing
Latch
Front Back
