CyClone Alito SC510 Use And Care Manual

OPERATION INSTRUCTIONS

Fan Operation

Fan Speeds: Three speed settings give the customer total control of their fan at the push of
a button.
Timer: This collection features a time-delay off feature to automatically shut the fan off after
1 to 9 minutes to conveniently clear the smoke and grease after cooking. To program the
time-delay feature, press the button with the clock icon while the machine is on and then use
the lowest speed setting button to toggle between 1 to 9 minutes.

Grease Disposal

WARNING!
Do not remove grease cups immediately after cooking or if grease is still hot.
Nonstick-coated fan blades will separate grease from the air and the grease will then be
deposited into a grease cup for easy, convenient disposal.
use one or the other.
Tip: Soak all parts in soapy water if there is heavy grease.

Changing Light bulbs

WARNING!
Ensure that all power leading to your range hood has been disconnected
before changing bulbs. As well, ensure that lights have fully cooled before changing bulbs.
To change the light bulb, remove light case from the light socket. The light case can be
accessed from the inside of the body of the machine.
1.
2. Disconnect the connecting wires of the light socket from the motherboard wires.
3.
remove the glass cover of the light case.
4. Detach light bulb and replace with a new bulb.
Removal:
Disassembly:
cleaned in the top rack of the dishwasher.
Reassembly:
the knob into the nut.
USE AND CARE GUIDE
MODELS
SC510
Power
Fan
Light
Control
Control
Fan Housing
