Self-Cleaning Range Hoods
Insert Range Hoods
Models:
BX212, BX215, BX155, BX600, CLX60, BOX2000, SS130
Installation and Operation Instructions
Please read all instructions before installing and operating.
All wiring and installation must be in accordance with CEC, NEC and local electrical codes.
READ AND SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Related Manuals for CyClone BX212
Summary of Contents for CyClone BX212
- Page 1 Self-Cleaning Range Hoods Insert Range Hoods Models: BX212, BX215, BX155, BX600, CLX60, BOX2000, SS130 Installation and Operation Instructions Please read all instructions before installing and operating. All wiring and installation must be in accordance with CEC, NEC and local electrical codes.
- Page 2 Cyclone Insert Installation - English...
-
Page 3: Important Safety Instructions
Not for outdoor use. automatically shut off the motor if it becomes overheated. The motor will restart. If the motor continually shuts off and restarts, contact the Cyclone service department. Ensure that the hood is mounted at the recommended mounting height. -
Page 4: Table Of Contents
SS130 Insert Hood Installation SS130 Installation - Installation Cutout Templates BX212/BX215 Installation - Parts supplied BX212/BX215 Insert Hood Installation BX212/BX215 Installation - Installation Cutout Templates BX600/CLX60 Installation - Parts supplied BX600/CLX60 Insert Hood Installation BX600/CLX60 Installation - Installation Cutout Templates... -
Page 5: Damage Inspection
Before making cutouts make sure there is proper clearance within Side Wall Cap with the ceiling or wall for the exhaust vent. Gravity Damper Additional parts not provided. Cyclone Insert Installation - English... -
Page 6: Mounting Heights And Clearance
Connect the black power wire to the black wire supplied with bottom of the cabinet. the hood. Connect the white neutral wire to the white wire supplied with the hood. Black: Power White: Neutral Green: Ground Cyclone Insert Installation - English... -
Page 7: Tools And Materials Required
Make sure the adapter/damper assembly The round vent of a Cyclone Range Hood is 6” diameter. If enters the ducting. Seal the connection with aluminum tape. the round exhaust duct is not 6” diameter, a connecting duct is necessary to accommodate the different size. -
Page 8: Bx2000/Bx2010 Installation - Parts Supplied
2 × Round Oil Collectors 2 × Halogen Lights (120V, 20W per bulb) BX2010 ONLY: 1 × Halogen Lights BX2010 ONLY: 1 × Rectangular Damper HARDWARE PACKAGE BX2010 ONLY: 4 × Mounting Screws 6 × Damper Screws Cyclone Insert Installation - English... -
Page 9: Bx2000/Bx2010 Insert Hood Installation
Remove the top electrical knockout (Figure 2). Insert a screwdriver into the knockout slot and bend the knockout back and forth (Figure 3a & 3b). Pliers may be used to remove the loosened knockout. Figure 2. Electrical Knockout Figure 3a, 3b. Cyclone Insert Installation - English... - Page 10 Connect the power line ground wire to the green ground wire supplied with the hood (Figure 8). iv. Connect the black power wire to the black wire supplied with the hood. Connect the white neutral wire to the white wire supplied with the hood. Cyclone Insert Installation - English...
-
Page 11: Ss130 Installation - Parts Supplied
1 × Rectangular Oil Collector 1 × Round Adapter 1 × Hood 2 × LED Lights (1.5W per bulb) *Bulb & socket may change. 1 × Plastic Adapter Seal HARDWARE PACKAGE 6 × Adapter Screws Cyclone Insert Installation - English... -
Page 12: Ss130 Insert Hood Installation
(Figure 4). Make sure that the adapter is connected to ductwork. Place mesh filters back into place. Connect the power plug to the junction box. Figure 4. Fasten Screws Cyclone Insert Installation - English... -
Page 13: Ss130 Installation - Installation Cutout Templates
SS130 INSTALLATION - INSTALLATION CUTOUT TEMPLATES SS13024 SS13030 Cyclone Insert Installation - English... -
Page 14: Bx212/Bx215 Installation - Parts Supplied
BX212/BX215 INSTALLATION - PARTS SUPPLIED 1 × Round Adapter INCLUDED IN UNIT 1 × Rectangular Oil Collector 1 × Hood 2 × Halogen Lights (120V, 20W per bulb) 1 × Plastic Adapter Seal HARDWARE PACKAGE 4 × Mounting Screws 6 × Adapter Screws... -
Page 15: Bx212/Bx215 Insert Hood Installation
BX212/BX215 INSERT HOOD INSTALLATION Installing the BX212/BX215 Range Hood This appliance requires 120V 60Hz electrical supply and connection to an individual properly grounded branch circuit protected by a circuit breaker or time delay fuse. Remove outer mesh filters of range hood. -
Page 16: Bx212/Bx215 Installation - Installation Cutout Templates
BX212/BX215 INSTALLATION - INSTALLATION CUTOUT TEMPLATES BX21228/BX21528 BX21234/BX21534 Cyclone Insert Installation - English... -
Page 17: Bx600/Clx60 Installation - Parts Supplied
BX600/CLX60 INSTALLATION - PARTS SUPPLIED 1 × Rectangular Oil Collector PRE-INSTALLED PRE-INSTALLED 1 × Hood 1 × Round Adapter 2 × LED Lights (1.5W per bulb) HARDWARE PACKAGE 8 × Mounting Screws Cyclone Insert Installation - English... -
Page 18: Bx600/Clx60 Insert Hood Installation
18 (Figure 1). Locate the cutout at the center of the bottom of the cabinet. Figure 1. Place baffle filters back into place. Connect the power plug to the junction box. Cyclone Insert Installation - English... -
Page 19: Bx600/Clx60 Installation - Installation Cutout Templates
BX600/CLX60 INSTALLATION - INSTALLATION CUTOUT TEMPLATES BX600/CLX6028 BX600/CLX6034 32” Cyclone Insert Installation - English... -
Page 20: Insert Hoods Specifications
2 × 120V 20W 2 × 120V 1.5 W 2 × 12V 1.5 W LIGHTING Halogen Halogen 120V 120V 120V 120V AC INPUT 60Hz 60Hz 60Hz 60Hz MOUNTING HEIGHT 28”-36” 28”-36” 28”-36” 28”-36” *Bulb & socket may change. Cyclone Insert Installation - English... -
Page 21: Troubleshooting
28” - 36” above the range. Blockage in the duct opening or ductwork. Remove all the blocking from the duct work or duct opening. Using the wrong size of ducting. Use at least 6” duct work. Cyclone Insert Installation - English... -
Page 22: Maintenance
• *Bulb & socket may change. of the machine. To change bulbs for BX2000/BX2010/BX212/BX215/BX600/ Use non-abrasive stainless steel polish to buff out the luster and CLX60 grain. Scrub lightly. -
Page 23: Control Panel
The fan and light are each controlled by a rocker switch. The fan switch has three positions: HIGH, LOW and OFF. The light switch has two positions, ON and OFF. HIGH HIGH speed speed Light Controls Cyclone Insert Installation - English... -
Page 24: Cyclone Range Hoods Limited Warranty
CYCLONE RANGE HOODS LIMITED WARRANTY Cyclone Range Hoods Inc. (hereunder called “The Company”) provides a warranty that its products are free from defects in workmanship and materials for a period of two (2) years from the date of purchase. This warranty includes in-home service (where applicable) for the first year and workshop service for the second year.
