- Page 1 USER MANUAL REFRIGERATED DROP-IN WELLS 423SDC5A REFRIGERATED DROP-IN WELLS Models: 423SDC1A, 423SDC2A, 423SDC3A, 423SDC4A, 423SDC5A, 423SDC6A PLEASE READ THE MANUAL THOROUGHLY PRIOR TO EQUIPMENT SETUP, OPERATION, AND MAINTENANCE. REVISED 10/2023...
-
Page 2: Table Of Contents
USER MANUAL TABLE OF CONTENTS Owner's Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Installation Instructions . -
Page 3: Safety Warnings
The drains are large 3/4" sized, allowing for quick defrosting and draining during end of day cleaning . They are built for tough front and back of house use with rugged stainless steel construction and heavy-duty hardware . ServIt refrigerated wells come with robust 18-gauge 304 stainless steel top and well liner and 20-gauge 430 stainless steel exterior, perfect for resistance to corrosion while being easy to clean . -
Page 4: Control Panel
USER MANUAL CONTROL PANEL Use and Caution Your new refrigerator is already factory-set to run at optimum temperatures for food safety and should require no adjustments . Control Panel - Figure 1: Refrigerant LED Defrost LED Front Panel Operation 1 . Set temperature: −... -
Page 5: Operating Instructions
USER MANUAL CONTROL PANEL (CONTINUED) Electrical • Please ensure that the required voltage is being supplied at all times . • The unit should be plugged into a grounded and properly-sized electrical outlet with appropriate over-current protection . Please refer to the electrical requirements on the unit’s nameplate . •... -
Page 6: Installation Instructions
USER MANUAL OPERATING INSTRUCTIONS (CONTINUED) Cleaning the Interior of Unit • When cleaning the cabinet interior, use a solvent of warm water and mild soap . • Do not use steel wool, caustic soap, abrasive cleaners, or bleach that may damage the interior finish . •... -
Page 7: Installation Dimensions
Item # Overhang Condensing (Per Edge) Width Depth Width Depth Width Depth Unit) Diagram Reference 16 1/2" 15 1/4" 15 1/2" 423SDC1A (419mm) (387mm) (393mm) 29 5/8" 28 3/8" 28 5/8" 423SDC2A (752mm) (720mm) (726mm) " " " 423SDC3A (1087mm) -
Page 8: Installation Diagrams
1 / " 1 / " 22 ¼" 12 ⅞" 1" 24 ⅝" USER MANUAL 15 ¼" 22 ¼" 12 ⅞" 24 ⅝" 15 ¼" INSTALLATION DIAGRAMS (Please refer to the Installation Dimensions chart on page 6 for specific model specs and information.) TOP REFRIG Drop-In Cut Diagram - Figure 2: Top View - Figure 3:... -
Page 9: Troubleshooting
USER MANUAL TROUBLESHOOTING Problem Possible Cause Possible Solution Fuse blown or circuit breaker tripped . Replace fuse or reset circuit breaker . Power cord unplugged . Plug in power cord . Compressor not running . Thermostat set too high . Set thermostat to lower temperature .
