- Page 1 USER MANUAL DROP-IN HEATED WELLS 423SDW2A 423SDW5H DROP-IN HEATED WELLS Models: 423SDW1A, 423SDW1H, 423SDW2A, 423SDW2H, 423SDW3H, 423SDW4H, 423SDW5H, 423SDW6H RETAIN THIS MANUAL FOR FUTURE REFERENCE. UNIT MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES. REVISED 1/2024...
-
Page 2: Table Of Contents
USER MANUAL TABLE OF CONTENTS Owner's Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Installation Instructions . -
Page 3: Safety Warnings
. The drains are a ¾” NPT drain, allowing for quick draining during end of day cleaning . They are built for tough front and back of house use with rugged stainless steel construction and heavy-duty hardware . ServIt warmers come with robust 18-gauge 304 stainless steel top and well liner and 20-gauge 430 stainless steel exterior, perfect for resistance to corrosion while being easy to clean . - Page 4 USER MANUAL SAFETY WARNINGS (CONTINUED) Electric Shock Hazard: • Hardwire unit into a properly grounded electrical connection of the correct voltage, size, and configuration . If not the right configuration, contact a qualified electrician to determine and install proper voltage and size electrical receptacle . •...
-
Page 5: Operating Instructions
3 . Indicator Power Light NOTE: ServIt Hot Wells utilize Thermostatic controls, so indicator power light may cycle on and off while the unit is powered on with control knob between “MIN” and “MAX” position . This is normal, as heating elements cycle to maintain consistent and even heating . - Page 6 USER MANUAL OPERATING INSTRUCTIONS (CONTINUED) General Operating Instructions: • All food service equipment should be operated by trained personnel . • Do not allow your customers to meet any surface labeled CAUTION HOT . • Where applicable: Never pour cold water into wet heated units . •...
-
Page 7: Installation Dimensions
Total Height Flange Overhang Item # (Including Drains) (Per Edge) Width (F) Depth (G) Width Depth Width Depth Diagram Reference " 423SDW1A (312mm) 16 1/2" 15 1/4" 15 1/2" (419mm) (387mm) (393mm) 423SDW1H 423SDW2A 14 ¾" 29 5/8" 28 3/8"... -
Page 8: Installation Instructions
USER MANUAL INSTALLATION INSTRUCTIONS GENERAL NOTE: All electric units to be connected and installed must comply with NEC and local codes . Consult a qualified plumber for proper trap and drain installation that complies with local plumbing codes . Cut out countertop as specified . NOTE: Unit is designed for installation in stainless steel countertops . -
Page 9: Installation Diagrams
USER MANUAL INSTALLATION DIAGRAMS (Please refer to the Installation Dimensions chart on page 5 for specific model specs and information.) Drop-In Cut Out Diagram - Figure 3: Control Panel Mount Diagram - Figure 4: (10 / ") 4" Min. Metal Table (By Fabricator) Wiring Box (By Fabricator) - Page 10 USER MANUAL INSTALLATION DIAGRAMS (CONTINUED) RIGHT SIDE Right Side View - Figure 7: Top View - Figure 8: FRONT Front View - Figure 9: DROP-IN HEATED WELLS...
-
Page 11: Cleaning Instructions
USER MANUAL CLEANING INSTRUCTIONS GENERAL CLEANING: NOTES: • Never clean any electrical unit by immersing it in water . Turn off unit and unplug before surface cleaning . • Always clean equipment thoroughly before first use . Clean unit daily . Except where noted on charts: Use warm, soapy water . -
Page 12: Troubleshooting
USER MANUAL TROUBLESHOOTING Issue Reason Solution No power to warmer . Circuit breaker off or tripped . Reset circuit breaker . Warmer will not heat . Temperature control not set . Set control to desired setting . Verify flange to counter seal is tight, Wet Insulation .
