- Page 1 USER MANUAL DROP-IN ICE COOLED WELLS 423SDI1A 423SDI3A 423SDI6A DROP-IN ICE COOLED WELLS (NON-REFRIGERATED) Models: 423SDI1A, 423SDI2A, 423SDWI3A, 423SDI4A, 423SDI5A, 423SDI6A RETAIN THIS MANUAL FOR FUTURE REFERENCE. REVISED 10/2023...
- Page 2 USER MANUAL TABLE OF CONTENTS Owner's Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Installation Instructions .
- Page 3 . The drains are large 1” sized, allowing for quick draining during end of day cleaning or when replenishing ice . They are built for tough front and back of house use with rugged stainless steel construction and heavy-duty hardware . ServIt Ice-cooled wells come equipped with robust 304 grade stainless steel with 16-gauge tops and 18-gauge wells, perfect for resistance to corrosion while being easy to clean .
- Page 4 USER MANUAL OPERATING INSTRUCTIONS FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS MANUAL COULD RESULT IN SERIOUS INJURY OR DEATH. General Information: • Always clean equipment thoroughly before first use (see general cleaning instructions) . • Check rating label for your model designation . •...
- Page 5 Item # (Including Overhang Drains) (Per Edge) Width Depth Width Depth Width Depth Diagram Reference 16 ½" 15 1/4" 15 ½" 423SDI1A (419mm) (387mm) (394mm) 29 5/8" 28 3/8" 28 5/8" 423SDI2A (752mm) (721mm) (727mm) " " " 423SDI3A (1087mm)
- Page 6 USER MANUAL INSTALLATION DIAGRAMS FRONT SIDE FRONT SIDE (Please refer to the Installation Dimensions chart on page 5 for specific model specs and information.) 25 ⅞" 16 ½" TOP ICED 25 ⅞" 16 ½" Drop-In Cut Out Diagram - Figure 2: Top View - Figure 3: / "...
- Page 7 USER MANUAL CLEANING INSTRUCTIONS General Cleaning Information: • Always clean equipment thoroughly before first use . Clean unit daily . Except where noted on charts: Use warm, soapy water . Mild cleansers and PLASTIC scouring pads may be used to remove food particles and water scale . •...
