USER MANUAL
Heating Holding and
Proofing Cabinets
SERVIT HEATED CABINETS ARE FORHOT FOOD HOLDING APPLICATIONS ONLY.
THIS MANUAL COVERS CABINETS WITH ELECTRICAL RATINGS OF: 120V 60HZ 2000W
Models:
423CC1UFNCF, 423CC2UFNCF, 423CH1UFNCF, 423CH2UFNCF, 423CC1UFICF
423CC1UFISF, 423CC1UFICD, 423CC1UFISD, 423CC2UFISF, 423CH1UFICF, 423CH1UFISF
423CH1UFICD, 423CH1UFISD, 423CH2UFISF
04/2021
Advertisement
Table of Contents
Related Manuals for SERVIT 423CC1UFNCF
Summary of Contents for SERVIT 423CC1UFNCF
- Page 1 USER MANUAL Heating Holding and Proofing Cabinets SERVIT HEATED CABINETS ARE FORHOT FOOD HOLDING APPLICATIONS ONLY. THIS MANUAL COVERS CABINETS WITH ELECTRICAL RATINGS OF: 120V 60HZ 2000W Models: 423CC1UFNCF, 423CC2UFNCF, 423CH1UFNCF, 423CH2UFNCF, 423CC1UFICF 423CC1UFISF, 423CC1UFICD, 423CC1UFISD, 423CC2UFISF, 423CH1UFICF, 423CH1UFISF 423CH1UFICD, 423CH1UFISD, 423CH2UFISF...
-
Page 2: Table Of Contents
..................... Service and Replacement Parts (Circuits) ....9 Servit Cabinets are designed to keep foods at optimum serving temperatures without affecting quality. They are built for tough kitchen duty with rugged metal construction, heavy-duty hardware, fully adjustable universal slides and easy-to-use controls. -
Page 3: Safety Information & Symbols
CAUTION: Water dripping onto the floor from open doors can be a slip hazard. DENTIFYING YOUR CABINET For future reference, note the serial and model number found on the data plate of the cabinet here: Serial number ________________________________ PART NUMBERING: 423CC1UFNCF (120V 60HZ 2000W)IDENTIFYING YOUR CABINET... -
Page 4: Installation And Setup
USER MANUAL INSTALLATION & SETUP 1. Check the packaging and cabinet for shipping damage after unloading the unit, and after removing all the packaging. 2. The receiver of this product is responsible for filing freight damage claims. This equipment must be opened immediately for inspection. -
Page 5: Operating Instructions
USER MANUAL OPERATING INSTRUCTIONS Power/Selector Switch Thermostat Thermometer 1. Fill the stainless pan with water if proofing, or if you desire a small amount of passive humidity while in heated holding mode. 2. Your cabinet has a 3 way power / selector switch that powers the cabinet on and off and also allows dual functionality. For heated holding mode set the switch to “hold”... -
Page 6: Basic Troubleshooting
Regularly inspect the casters. Tighten loose fasteners and replace worn or damaged parts with new SERVIT approved parts. Replace worn or damaged casters immediately. Additionally, periodic tightening of door latch and hinge screws may be required. -
Page 7: Reversing The Door
USER MANUAL REVERSING THE DOOR The door on your cabinet can be reversed to accommodate a right- or left-hand opening. The cabinet has been shipped with the hinges mounted on the right-hand side. To reverse, follow the instructions listed below: 1. -
Page 8: Service And Replacement Parts
USER MANUAL HEATED HOLDING & PROOFING CABINET REPLACEMENT PARTS DIAGRAM... - Page 9 USER MANUAL SERVICE AND REPLACEMENT PARTS WARNING: Only factory approved service agents must attempt to service, repair or replace electrical components, wiring or power cord. *CHECK DATA PLATE ON REAR OF CABINET TO CONFIRM CABINET VOLTAGE BEFORE SELECTING PARTS...
-
Page 10: Service And Replacement Parts (Circuits)
USER MANUAL WIRING DIAGRAM 120V... - Page 11 USER MANUAL This warranty covers ServIt Holding and Proofing Cabinets models only: 423CC1UFNCF, 423CC2UFNCF, 423CH1UFNCF, 423CH2UFNCF, 423CC1UFICF 423CC1UFISF, 423CC1UFICD, 423CC1UFISD, 423CC2UFISF, 423CH1UFICF, 423CH1UFISF, 423CH1UFICD, 423CH1UFISD, 423CH2UFISF...
