- Page 1 -- FNS-40 -- (40 FT FIELDPRO NETTING SYSTEMS) Installation Instructions Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support. www.jaypro.com Rev: D Page 1 of 9...
- Page 2 3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS. * HARDWARE FOR IS FOR BOTH END POLES AND INTERMEDIATE POLES (NOT ALL HARDWARE WILL BE USED).
-
Page 3: Tools Required
TOOLS REQUIRED: (1) 3/8” Socket Wrench and Box Wrench (1) 7/16” Nut Driver (1) 9/16” Socket Wrench and Box Wrench (1) Cable Cutters SPECIAL NOTES: • Max spacing between poles should not exceed 20 ft. • The net may be broken up into sections to reduce weight and make handling more manageable. - Page 4 Install Sleeves: Dig footings as shown in Figure 2. A six-piece rebar basket is recommended. Pour a 12” concrete pad at the bottom of the footing, allow to cure for 24 hours. Position and plumb the ground sleeve in the footing hole. Support the sleeve to prevent it from shifting during the pour.
- Page 5 POLE (BOTTOM SECTION) ~ BACK SIDE ~ 1/4"-20 x 8 1/2" HEX HD SCREW 1/4-20 ACORN NUT (3X) 1/4" WASHER LOCK 1/4"-20 NYLON LOCK NUT 1/4" FLAT WASHER 6" LONG CLEAT Make up a loop, as shown in Figure 6, on both ends ~ BACK SIDE ~ of the cable.
- Page 6 Pole Splice: 9/16” DRILL THRU BOTTOM SPLICE 1/2" FLAT WASHER 1/2"-13 NYLON LOCK NUT 1/2"-13 x 7 1/2" HEX HD BOLT NOTE: Use the upper pole section to mark the holes with a center punch. It is important that the holes be properly placed to ensure that the poles are parallel to each other.
- Page 7 Net: Lay the net out lengthwise and cut the 3/16” coated aircraft cable to length, extending each end enough to make up the loop. Make up a loop, as shown in Figure 7, on both ends of the cable. Attach a cable to both the top and bottom edges of the net using the cable ties.
- Page 8 Install Net: Lay the net sections out lengthwise along the base of the poles. Attach D-Rings to the net at each intermediate pole location. Attach the hoisting ropes to each cable end and D- Ring. Slowly raise the net up, attaching the sliding cable loops to the net approximately every 5 ft.
-
Page 9: Maintenance
MAINTENANCE: • Before and after each season, thoroughly inspect the net for wear. Repair any holes to prevent them from getting wider. • Remove and store the net after the seasons use. • Remove and or lower and secure all netting if a major storm or extreme winds more than 50 mph are forecasted.
